Late 2015 to 2016 Land Rover vehicles with InControl, Version 4 radio .
InControl touch screen navigaon radio Version 4. s,
Please note that the given informaon must be veried by the installer. Crux Interfacing assumes
no liability for changes in wire color or pin assignments made by the vehicle manufacturer.
Funcon
Pin-No.
CAN-HIGH (Yellow)
Pin 3 (chamber B)
CAN-LOW (Blue)
Pin 9 (chamber B)
+12V Constant (Red)
Pin 13
Ground (Black)
Pin 11
VIMLR- Interface Module 89B
LR- Harness 89B
rev.0315 16
1 /2
Version 1
Version 4
DIP Switch Seng
Vehicle/ Navigaon
Dip 1
Dip 2
Dip 3
Dip 4
Dip 5
Dip 6
Land Rover rear-view camera without
ON*
OFF
OFF
OFF
ON
ON
Land Rover rear-view camera with
ON*
ON
OFF
OFF
ON
ON
*With DIP1 set to OFF, the Green wire is used to acvate the video- -moon funcon. in
Note: Dip switch funcons of the VIMLR-89B
Dip 1 Acvaon VIM
Dip 2 Factory Rear-view camera present
Dip 3 no funcon
Dip 4 no funcon
Dip 5 CAN-bus terminaon resistor on the vehicle side
Dip 6 CAN-bus terminaon resistor on the head-unit side
Acvaon of the Video-In-Moon funcon
The Video- -Moon can be acvated and deacvated by DIP 1 or by the loose green wire on the In
harness when connected to a +12V ACC source.
Video- -Moon permanent In
With DIP1 set to ON, the video- -moon funcon is acvated permanently without disturbing the in
navigaon performance.
Video- -moon selecve in
With DIP1 set to OFF, the green wire is used to acvate and deacvate the video- -moon funcon. in
Connect a toggle switch between the green wire and +12V ACC.
+12V = Video- -moon is acvated in
0V = Video- -moon is not acvatedin
InControl Touch Screen
Navigaon radio, Version 4
031516
2 2 /
