JSR 625

AUDIO AND

VIDEO RECEIVER

OWNER'S

MANUAL

JSR

625

The lightning flash with arrowhead

symbol, within an equilateral triangle, is

intended to alert the user to the presence

of uninsulated "dangerous voltage" within

the product's enclosure that may be of

sufficient magnitude to constitute a risk

of electric shock to persons.

The exclamation point within an

equilateral triangle is intended to alert

the user to the presence of important

operating and maintenance (servicing)

instructions in the literature accom-

panying the appliance.

JBL JSR 625

Date of purchase ________________________

Purchased from _________________________

Address of business purchased from_________

______________________________________

Installed by _____________________________

Date Installed ___________________________

Serial No. ______________________________

NOTE TO CATV SYSTEM INSTALLER:

This reminder is provided to call the CATV

system installer’s attention to Article 820-

40 of the NEC that provides guidelines for

proper grounding and, in particular, speci-

ﬁes that the cable ground shall be con-

nected to the grounding system of the

building, as close to the point of cable

entry as practical.

Thank you for choosing a JBL Audio/Video Receiver.

Your new Unit is an exceptionally well-engineered product that will

give you years of superb performance.

Save all packing material.

It is essential for shipping should you move, or in the event the

unit ever needs repair.

U.S. and Canadian customers should use 120 volt AC only. Other

customers should use voltages appropriate to their area.

Connecting the unit to an outlet supplying a higher voltage may

create a ﬁre hazard.

CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH

WIDE BLADE OF PLUG TO WIDE SLOT, FULLY

INSERT.

ATTENTION: POUR EVITER LES CHOCS ELEC-

TRIQUES, INRODUIRE LA LAME LA PLUS LARGE DE

LA FICHE DANS LA BORNE CORRESPONDANTE DE

LA PRISE ET POUSSER JUSQU’AU FOND.

HANDLE THE POWER CORD GENTLY

■To disconnect the plug from the AC outlet, pull on the plug

itself, not on the cord.

■Disconnect the plug from the AC outlet whenever the unit is to

be left unused for an extended period of time.

■Do not place furniture or other heavy objects on the cord, and

avoid dropping heavy objects on it. Also do not make a knot in

the cord.

PLACE THE UNIT ON A FIRM AND LEVEL SURFACE

Avoid installing it:

■In moist or humid places

■Close to heating equipment or in places exposed to direct

sunlight

■In a direct draft from an air conditioner or in other very cold

locations

■In places subject to excessive vibration or dust

■In poorly ventilated places

MOVING THE UNIT

Before moving the unit, be sure to unplug the power cord from

the AC outlet and disconnect all wires to antennas and other

components.

DO NOT OPEN THE CABINET

Do not attempt to service this unit. Tampering with internal compo-

nents can cause ﬁre or shock, and may void your guarantee. If

water or a small object enters the unit, unplug the power cord

immediately and consult an authorized JBL service center. Using

the unit under such conditions may cause a ﬁre or shock hazard.

CLEANING

Remove dust by wiping the unit with a soft, dry cloth. If necessary,

use a soft cloth lightly dampened with mild soapy water; then wipe

with a dry cloth. Never use benzene, thinner, alcohol or other

volatile agents, and avoid spraying insecticides near the unit.

FCC INFORMATION

This equipment has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does

cause harmful interference to radio or television reception, which

can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the

following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from

that to which the receiver is connected.

• Consult the dealer or an experienced radio TV technician for

help.

CAUTION: Any changes or modiﬁcations in construction of this

device which are not expressly approved by the party responsible

for compliance could void the user’s authority to operate the

equipment.

CONTENTS

FRONT PANEL CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

REAR PANEL CONNECTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

SURROUND SOUND EFFECTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

JSR 625 SYSTEM REMOTE CONTROL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

TROUBLE-SHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
