Sivu 1/15
PD82000/PD70101
User Guide
PDX16DPU-13v12 DPU RPF CARD
April 2018
PDX16DPU-13v12 DPU RPF CARD
Microsemi Proprietary and Confidential. PD82000/PD70101 User Guide Revision 1.0
Contents
1 Revision History ............................................................................................................................. 1
1.1 Revision 1.0 ........................................................................................................................................
1.2 Revision 0.3 ........................................................................................................................................
1.3 Revision 0.2 ........................................................................................................................................
1.4 Revision 0.1 ........................................................................................................................................
2 About This Guide ........................................................................................................................... 2
2.1 Related Documentation ..................................................................................................................... 2
2.2 Acronyms and Symbols ...................................................................................................................... 3
3 Introduction ................................................................................................................................... 4
3.1 Functional Blocks ................................................................................................................................
3.2 Main Features .....................................................................................................................................
4 Physical Description ....................................................................................................................... 6
4.1 DPU Top and Bottom View ................................................................................................................. 6
4.2 Input Connector .................................................................................................................................
4.3 Output Connector ...............................................................................................................................
4.4 LEDs Indication ...................................................................................................................................
4.5 Class Control ..................................................................................................................................... 1
5 Installation ................................................................................................................................... 11
5.1 I2C Interface Connection .................................................................................................................. 1
5.2 Software Download .......................................................................................................................... 1
PDX16DPU-13v12 DPU RPF CARD
Microsemi Proprietary and Confidential. PD82000/PD70101 User Guide Revision 1.0 1
1 Revision History
The revision history describes the changes that were implemented in the document. The changes are
listed by revision, starting with the most current publication.
1.1 Revision 1.0
Revision 1.0 was published in April 2018. The following is the summary of changes made in this revision.
The document was migrated to latest template.
Descriptions in are edited.
Table 1 (see page 2)
Installation steps are edited in .Software Download (see page 11)
1.2 Revision 0.3
Revision 0.3 was published in Feb 2017. In revision 0.3 of this document, Ordering Information (see page
was updated. 2)
1.3 Revision 0.2
Revision 0.2 was published in Jan 2017. In revision 0.2 of this document, "Preliminary" was added in the
document title.
1.4 Revision 0.1
Revision 0.1 was published in Feb 2016. It was the first publication of this document.
