Peerless-AV DS-LEDTK-8S Käyttöohje

Lue alta 📖 käyttöohje suomeksi merkille Peerless-AV DS-LEDTK-8S (28 sivua) kategoriassa Ei luokiteltu. Tämä opas oli hyödyllinen 2 henkilölle ja sai 4.5 tähden keskimäärin 2 käyttäjältä

Sivu 1/28
12020-07-13 #:146-9054-2 (2020-08-03)
ENG
DS-LEDTK Series
*Actual conguration may vary
22020-07-13 #:146-9054-2 (2020-08-03)
ENG - This product is designed to be installed on plywood walls. Hardware is included for plywood installation.
This product is designed to be installed on at, unobstructed, vertical walls. Do not install on curved or angled
walls. Before installing make sure the supporting surface will support the combined load of the equipment and
hardware. Screws must be tightly secured. Do not overtighten screws or damage can occur and product may fail.
Never exceed the Maximum Load Capacity. Always use an assistant or mechanical lifting equipment to safely lift
and position equipment. This product is intended for indoor use only. Use of this product outdoors could lead to
product failure or personal injury. Be careful not to pinch ngers when operating the mount. For support please
call customer care at 1-800-865-2112.
WARNING
Symbols
ENG
WARNING
ENG
#
Skip to step.ENG
Do not overtighten screws.
ENG
1
2
ENG To properly tighten screws: Tighten until screw
head makes contact, then tighten another 1/2
turn. Do not overtighten screws.
4
+1/2
3
32020-07-13 #:146-9054-2 (2020-08-03)
Tools Needed for Assembly.
ENG
5/32"
(4mm)
3/8"
(10mm)
1
2
ENG To properly tighten screws: Tighten until screw
head makes contact, then tighten another 1/2
turn. Do not overtighten screws.
4
+1/2
3
1/4"
(6mm)
