Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
Manual Revision: October 6, 2021 5:50 PM
Product Diagram (LAPTOP-ARM-TRAY)
Component Function
1Laptop Tray • Mount a to a Laptop VESA Monitor Arm, Mount, or
Stand
2Laptop Arms • Holds the securelyLaptop
3Laptop Arm Clips • Attach the to the Padded Clamps Laptop Tray
4Anti-slip Pads • Prevent the from sliding from side-to-sideLaptop
5Ventilation Slots • Promote airow around the base of the Laptop
6Stoppers • Rotate from the horizontal position to vertical
depending on the thickness of the Laptop
VESA Compatible Laptop Tray with Adjustable Padded Arms
Package Contents
• Laptop Tray x 1
• Laptop Arm x 2
• Laptop Arm Clips x 2
• Mounting Screws x 4
• Quick-Start Guide x 1
Requirements
For the latest manuals, product information, technical specications, and declarations of
conformance, please visit:
www.StarTech.com/LAPTOP-ARM-TRAY
• VESA Compatible Arm, Mount, or Stand
• 75x75mm and 100x100mm Mounting Hole Patterns
• Phillips Head Screwdriver
3
46
2
1
5
Component Function
1VESA Compatible
Mounting Points
• Attach the (not included) to the VESA Bracket
75x75mm and100x100mm VESA Mounting Holes on
the VESA Plate
1
Front view Back view
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of
third-party companies not related in any way to StarTech.com. Where they occur these references are for illustrative
purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. StarTech.com hereby acknowledges that
all trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual
and related documents are the property of their respective holders.
PHILLIPS® is a registered trademark of Phillips Screw Company in the United States or other countries.
Warranty Information
This product is backed by a 5-year warranty.
For further information on product warranty terms and conditions, please refer to .
www.startech.com/warranty
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or
agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of
prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price
paid for the product. Some states do not allow the exclusion or limitation of incidental or consequential damages. If such
laws apply, the limitations or exclusions contained in this statement may not apply to you.
FR: startech.com/fr
DE: startech.com/de
ES: startech.com/es
NL: startech.com/nl
IT: startech.com/it
JP: startech.com/jp
StarTech.com Ltd.
45 Artisans Crescent
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Road
Brackmills,
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
4490 South Hamilton
Road
Groveport, Ohio
43125
U.S.A.
StarTech.com Ltd.
Siriusdreef 17-27
2132 WT Hoofddorp
The Netherlands
Attaching the Laptop Arms to the Laptop Tray
1. Position the under the right and left-hand sides of the Laptop Arms Laptop Tray
( . Figure 1)
2. Locate the four on the .Rectangular Slots Laptop Arms
3. Align the on the with the edge of the Rectangular Slots Laptop Arms Laptop Tray
and the long as shown in (Figure 1)Ventilation Slot
Note: Place the Laptop onto the Laptop Tray to determine if the current position of
the Padded Clamps will impede the use of the Laptop Ports. Make adjustments to the
locations of the Laptop Arms as necessary. Remove the Laptop after completing the
adjustments.
4. Align from the top of the the four clips of the with the Laptop Tray Laptop Arm Clip
four on the .Rectangular Slots Laptop Arms
5. Install the by pushing it into the . Laptop Arm Clip Laptop Arm Rectangular Slots
Ensure all four clips have engaged.
6. Repeat steps 4 - 5 to install the second on the . Laptop Arm Clip Laptop Arm
Warnings
• Ensure the weight of the equipment does not exceed the weight capacity of this
product. If the weight capacity is exceeded, you may experience personal injury or
damage to the equipment. This product can support the following weight: up to 9.9
lb (4.5 kg).
• The monitor arm, mount, or stand must support the weight of the Laptop and Laptop
Tray.
• Ensure the mounted laptop is properly secured and stable before and after adjusting
the laptop tray position.
Attaching the Laptop Tray to a VESA Bracket
1. Align the on the back of the VESA Compatible Mounting Points Laptop Tray
with the top row VESA mounting points located on the of an arm, VESA Bracket
mount, or stand.
2. Insert the through the and into the Mounting Screws VESA Bracket VESA
Compatible Mounting Points Laptop Tray Laptop Trayon the . Secure the by
tightening the using a . Mounting screws Phillips Head Screwdriver
Mount the Laptop to the Laptop Tray
1. To prevent the from falling without being secured to the tray, adjust the Laptop
Laptop Tray to a stable horizontal position and its weight can be supported by
the arm, mount, or stand.
2. Adjust the to best match the thickness.Stoppers Laptop
3. Rotate the , located at the bottom of the , to unlock the Lever Laptop Arms
Laptop Arms Lever. Leave the unlocked.
4. Pull the apart to the maximum available width.Laptop Arms
5. Place the into the with the on either side. Laptop Laptop Tray Laptop Arms
6. Slide the inwards until they are rmly seated against the sides of Laptop Arms
the . Laptop
7. Rotate the , located at the bottom of the , to lock the Lever Laptop Arms Laptop
Arms.
Figure 1
A
B
A: Clips
B: Rectangular Slots
