36" CLASSIC FRENCH DOOR REFRIGERATOR/FREEZER WITH INTERNAL DISPENSER

C L 3 6 5 0 U F D I D / S

FEATURES

Legacy product image shown; actual product varies slightly.

Split Climate™ intelligent cooling system revolutionizes Sub-Zero’s

already-superior preservation capabilities, keeping food even fresher for

longer

ClearSight™ LED lighting system fully illuminates the interior and

reduces shadows

Sleek stainless accents trim the interior, matching the sophistication of

the exterior

Touch control panel is conveniently located for easy access at the tap of

a finger

Night Mode optimizes the interior lighting based on the detected ambient

light, reducing the brightness by 90% in dim environments

Delivers fresh, filtered water through an internal dispenser located

discreetly within the refrigerator

Activate Max Ice Mode to temporarily increase ice production

Lift the base of the flip-up dairy compartments to store taller items on the

shelf below

The base of the expandable freezer basket conveniently slides out of the

way, offering customizable storage for taller items below

Wi-Fi enabled features provide remote access from your mobile device

Stainless-steel exterior and tubular or pro handles to match other Sub-

Zero, Wolf, and Cove products

Sub-Zero offers an industry-leading full two-year warranty on appliances,

along with a full five-year sealed system warranty and a limited twelve-

year sealed system warranty

ACCESSORIES

90° Door Stop

Air Purification Cartridge

Egg Container

Water Filter

Stainless Steel Kickplate

Accessories are available through an authorized dealer.

For local dealer information, visit subzero-wolf.com/locator.

HAN DL E OPTIONS

PRODUCT DETAILS

REFRIGERATOR

• 4 glass refrigerator shelves (3 adjustable; 1

stationary)

• 2 crisper drawers with removable dividers

• 4 adjustable refrigerator door bins

• 2 flip-up dairy compartments

• Air purification system

• Internal water dispenser

• LED refrigerator and freezer lights

FREEZER

• Full-extension drawer with expandable freezer basket

• Water filtration system

• Automatic ice maker with removable ice container

Specifications are subject to change without notice. This information was generated on July 11, 2023. Verify specifications prior to finalizing your cabinetry/enclosures.

36" CLASSIC FRENCH DOOR REFRIGERATOR/FREEZER WITH INTERNAL DISPENSER

PRODUCT SPECIFICATIONS

Model CL3650UFDID/S

Dimensions 36"W x 84"H x 24"D

Refrigerator Capacity 15.3 cu. ft.

Freezer Capacity 5.2 cu. ft.

Weight 573 lbs

Electrical Supply 115 VAC, 60 Hz

Electrical Service 15 amp dedicated circuit

Plumbing Supply 1/4" OD copper, braided stainless steel

or PEX tubing

Plumbing Pressure 35–120 psi

Receptacle 3-prong grounding-type

ELECTRICAL PL U M B ING

NOTE: Dimensions in parenthesis are in millimeters unless otherwise specified

INTERIOR VIEW

This illustration is intended for interior reference only and may not represent the

exterior of the model being specified.

DIMENS I ONS

STANDARD INSTALLATION

(

19)

TYPICAL

FRAMED

CABINETRY

(902)

FILLER

(89)

FINISHED

RETURN

FRAMELESS

CABINETRY

(902)

(

19)

TYPICAL

(89)

FINISHED

RETURN

NOTE:

(89)

finished returns will be visible and should be finished to match cabinetry

Shaded line represents profile of unit.

(2127)

OPENING

HEIGHT

24"

(610)

OPENING

DEPTH

FRONT VIEW

SIDE VIEW

TOP VIEW

(902)

OPENING WIDTH

Specifications are subject to change without notice. This information was generated on July 11, 2023. Verify specifications prior to finalizing your cabinetry/enclosures.
