LYNX-MIX 124UM
12-CH COMPACT INTEGRATED RECORDING/LIVE SOUND
MIXER WITH DIGITAL EFFECTS AND USB PLAYER
USER'S MANUAL
www.altoproaudio.com
Version 1.2 DEC. 2009
English
IMPORTANT SAFETY INSTRUCTION
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK
PLEASE DO NOT REMOVE THE COVER OR
THE BACK PANEL OF THIS EQUIPMENT.
THERE ARE NO PARTS NEEDED BY USER
INSIDE THE EQUIPMENT. FOR SERVICE,
PLEASE CONTACT QUALIFIED SERVICE
CENTERS.
WARNING
To reduce the risk of electric shock
and fire, do not expose this equipment
to moisture or rain.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Dispose of this product should
not be placed in municipal waste
and should be separate collection.
11.
12.
Move this Equipment only with a cart,
stand, tripod, or bracket,
specified by the
manufacturer, or
sold with the
Equipment. When
a cart is used, use
caution when
moving the cart /
equipment
combination to
avoid possible
injury from tip-over.
Permanent hearing loss may be caused by
exposure to \ extremely high noise levels.
The US. Government's Occupational Safety
and Health Administration (OSHA) has
specified the permissible exposure to noise
level.
These are shown in the following chart:
HOURS X DAY SPL EXAMPLE
According to OSHA, an exposure to high SPL in
excess of these limits may result in the loss of
heat. To avoid the potential damage of heat, it is
recommended that Personnel exposed to
equipment capable of generating high SPL use
hearing protection while such equipment is
under operation.
8
6
4
3
2
1,5
1
0,5
0,25 or less
90
92
95
97
100
102
105
110
115
Small gig
train
Subway train
High level desktop monitors
Classic music concert
Rock concert
This symbol, wherever used, alerts you to the
presence of un-insulated and dangerous voltages
within the product enclosure. These are voltages that
may be sufficient to constitute the risk of electric
shock or death.
This symbol, wherever used, alerts you to
important operating and maintenance instructions.
Please read.
Protective Ground Terminal
ã
AC mains (Alternating Current)
Hazardous Live Terminal
ON: Denotes the product is turned on.
OFF: Denotes the product is turned off.
The apparatus shall be connected to a mains
socket outlet with a protective earthing
connection.
The mains plug or an appliance coupler is used
as the disconnect device, the disconnect device
shall remain readily operable.
CAUTION
Describes precautions that should be observed to
prevent damage to the product.
Read this Manual carefully before operation.
Keep this Manual in a safe place.
Be aware of all warnings reported
with this symbol.
Keep this Equipment away from water and
moisture.
Clean it only with dry cloth. Do not use
solvent or other chemicals.
Do not damp or cover any cooling opening.
Install the equipment only in accordance with
the Manufacturer's instructions.
Power Cords are designed for your safety. Do
not remove Ground connections! If the plug
does not fit your AC outlet, seek advice from
a qualified electrician. Protect the power
cord and plug from any physical stress to
avoid risk of electric shock. Do not place
heavy objects on the power cord. This could
cause electric shock or fire.
Unplug this equipment when unused for long
periods of time or during a storm.
Refer all service to qualified service personnel
only. Do not perform any servicing other than
those instructions contained within the
User's Manual.
To prevent fire and damage to the product,
use only the recommended fuse type as
indicated in this manual. Do not short-circuit
the fuse holder. Before replacing the fuse,
make sure that the product is OFF and
disconnected from the AC outlet.
1. INTRODUCTION...................................................................................1
2. FEATURES..........................................................................................1
4. CONTROL ELEMENTS.........................................................................5
5. INSTALLATION & CONNECTION........................................................16
1. INTRODUCTION
2. FEATURES
1
3. QUICK START....................................................................................4
6. OPERATION INSTRUCTION FOR MP3................................................19
IN THIS MANUAL
Thank you for purchasing the 12-inputs LTO LYNX-MIX 124UM compact mixer.
Your LYNX-MIX 124UM is a remarkable compact mixer that doesn't find many
equals in the market today, with 6 MIC and 4 Stereo Line-level inputs for serious
live performances. Your LYNX-MIX 124UM includes a 24-bit digital multi-effect
with 16 Factory Presets and 16 variations for every preset, for a total of 256
different digital effects. It has a 3-band sweepable MID EQ on mono input
channels, 4-band EQ on stereo input channels. It also features MP3 player
function, it can connect with the external USB interface, insert the MP3 & WAV
file of the MP3 USB disk for playback, and it supports root directory reading and
storing functions. All the above features and its audio quality, make it perfect for
piano bar, karaoke, as well as fixed PA installation. Enjoy your LYNX-MIX 124UM
and please carefully read this Manual before operation!
¶6 MIC inputs with gold plated XLR and balanced TRS jack
¶4 Stereo input channels with balanced TRS jacks
¶Ultra-low noise discrete MIC preamps with +48 V Phantom Power
¶SUB1-2, SUB3-4 & MAIN L-R signal assignment switches
¶4 AUX Sends per channel: 2 PRE/POST faders switchable for monitoring
application effects & sound processor input; 2 POST faders as external
send or for internal digital DFX
¶3-band EQ with sweepable MID on mono inputs; 4-band EQ on stereo inputs
¶Channel Inserts and Direct Outputs on each mono channel plus Main Inserts
for flexible connection of outboard equipment
¶24-bit internal DSP with 256 effects, 16 presets by 16 variations with DSP
Mute switch and Peak LED
¶2-TRACK IN assignable to Main Mix, Control Room/Headphone outputs
¶MP3 player functions
7. PRESET LIST....................................................................................22
8. BLOCK DIAGRAM............................................................................23
9. TECHNICAL SPECIFICATIONS............................................................24
10. WARRANTY..................................................................................25
