User's Manual
X23
www.altoproaudio.com
Version 1.0 SEP. 2007
LTO
R
R
R
RR
English
2-WAY STEREO/3-WAY MONO
ACTIVE CROSSOVER
CAUTION
RISK OF ELECTRIC SHOCK
DO NO T OPEN
IMPORTANT SAFETY INSTRUCTION
TO REDUCE THE RISK OF ELECTRIC SHOCK
PLEASE DO NOT REMOVE THE COVER OR
THE BACK PANEL OF THIS EQUIPMENT.
THERE ARE NO PARTS NEEDED BY USER
INSIDE THE EQUIPMENT. FOR SERVICE,
PLEASE CONTACT QUALIFIED SERVICE
CENTERS.
WARNING
To reduce the risk of electric shock
and fire, do not expose this equipment
to moisture or rain.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Dispose of this product should
not be placed in municipal waste
and should be separate collection.
11.
12.
Move this Equipment only with a cart,
stand, tripod, or bracket,
specified by the
manufacturer, or
sold with the
Equipment. When
a cart is used, use
caution when
moving the cart /
equipment
combination to
avoid possible
injury from tip-over.
Permanent hearing loss may be caused by
exposure to \ extremely high noise levels.
The US. Government's Occupational Safety
and Health Administration (OSHA) has
specified the permissible exposure to noise
level.
These are shown in the following chart:
According to OSHA, an exposure to high SPL in
excess of these limits may result in the loss of
heat. To avoid the potential damage of heat, it is
recommended that Personnel exposed to
equipment capable of generating high SPL use
hearing protection while such equipment is
under operation.
This symbol, wherever used, alerts you to the
presence of un-insulated and dangerous voltages
within the product enclosure. These are voltages that
may be sufficient to constitute the risk of electric
shock or death.
This symbol, wherever used, alerts you to
important operating and maintenance instructions.
Please read.
Protective Ground Terminal
AC mains (Alternating Current)
Hazardous Live Terminal
ON: Denotes the product is turned on.
OFF: Denotes the product is turned off.
The apparatus shall be connected to a mains
socket outlet with a protective earthing
connection.
The mains plug or an appliance coupler is used
as the disconnect device, the disconnect device
shall remain readily operable.
CAUTION
Describes precautions that should be observed to
prevent damage to the product.
Read this Manual carefully before operation.
Keep this Manual in a safe place.
Be aware of all warnings reported
with this symbol.
Keep this Equipment away from water and
moisture.
Clean it only with dry cloth. Do not use
solvent or other chemicals.
Do not damp or cover any cooling opening.
Install the equipment only in accordance with
the Manufacturer's instructions.
Power Cords are designed for your safety. Do
not remove Ground connections! If the plug
does not fit your AC outlet, seek advice from
a qualified electrician. Protect the power
cord and plug from any physical stress to
avoid risk of electric shock. Do not place
heavy objects on the power cord. This could
cause electric shock or fire.
Unplug this equipment when unused for long
periods of time or during a storm.
Refer all service to qualified service personnel
only. Do not perform any servicing other than
those instructions contained within the
User's Manual.
To prevent fire and damage to the product,
use only the recommended fuse type as
indicated in this manual. Do not short-circuit
the fuse holder. Before replacing the fuse,
make sure that the product is OFF and
disconnected from the AC outlet.
HOURS X DAY
EXAMPLE
8
6
4
3
2
1,5
1
0,5
0,25 or less
SPL
90
92
95
97
100
102
105
110
115
Small gig
train
Subway train
High level desktop monitors
Classic music concert
Rock concert
IN THIS MANUAL:
1. INTRODUCTION..........................................................................1
2. FEATURES.................................................................................1
3. CONTROL ELEMENTS.................................................................2
4. APPLICATION.............................................................................4
5. INSTALLATION & CONNECTION....................................................6
6. TECHNICAL SPECIFICATIONS
7. WARRANTY................................................................................9
........................................................8
1. INTRODUCTION
Thank you for your purchasing the LTO products X23 Active Crossover.
It is just one of the many LTO products that a talented, multinational Team
of Audio Engineers and Musicians have developed with their great passion for
Music. The X23 Active Crossover is an ideal crossover and used universally in
most small and large PA systems, recording studio monitors, DJ setups,
commercial installations and live concerts. It is not only adaptable in mounting
to different sound systems, but also it has many developed features. For
example, Clip LED Indicators, Mute switches for all frequencies output, CD
Boost and Phase Inversion. The X23 Active Crossover is a single rack unit, dual
channels electronic crossover, which is able to operate as the 2-way stereo
and 3-way mono speaker systems.
Enjoy your X23 and make sure to read this Manual carefully before operation!
2. FEATURES
Mountable in a 19" rack unit(1U)
Clip LED indicators
Mute switches used to mute the output signal of each frequencies range
XLR balanced and connectors for inputs and outputs
Excellent audio performance and low noise interference
1/4" TRS
Phase inversion compensates for corresponding frequencies cancellation in
some field
CD Boost compensates power loss during the long distance transmission
1
