MC531
Monitor Controller
Operator’s Manual
Written for Automated Processes, Incorporated
by Dan Pfeifer
Rev. 21-07-07
Table of Contents
About This Manual ...................................................................................... 3
Important Safety Instructions .................................................................... 1
1.0 Introduction ......................................................................................... 2
1.1 MC531 Overview ......................................................................................... 2
2.0 Input Source Selectors ......................................................................... 4
2.1 Input Source Selection ................................................................................ 4
2.1.1 Bluetooth Pairing ..................................................................................................... 5
2.2 Input Source Meter ..................................................................................... 6
2.3 Input Source Connections ........................................................................... 6
3.0 Monitor Control Functions ..................................................................... 8
3.1 Monitor Controls ......................................................................................... 8
4.0 Monitor Selectors ................................................................................ 10
4.1 Monitor Selector Controls .......................................................................... 10
4.2 Subwoofer Output Linking ........................................................................ 11
4.3 Monitor Output Connections ...................................................................... 11
4.4 External Meter Connections ...................................................................... 12
5.0 Headphone Amplifiers ......................................................................... 13
5.1 Headphone Controls.................................................................................. 13
5.2 Headphone Cue Function........................................................................... 14
5.3 Talkback to Headphones ........................................................................... 14
5.4 Headphone Connections ............................................................................ 14
6.0 Rear Panel .......................................................................................... 15
6.1 Input Source Connections ......................................................................... 15
6.2 Monitor Output Connections ...................................................................... 16
6.3 Headphone Connections ............................................................................ 17
6.4 External Meter Connections ...................................................................... 17
6.5 Power Supply Connection.......................................................................... 18
APPENDIX................................................................................................. 19
A1 MC531 Block Diagram ................................................................................ 20
A2 Bluetooth Compliance ................................................................................ 21
A3 API Limited Warranty and Service.............................................................. 22
About This Manual
This manual explains the operation and applications of the API MC531 monitor controller. Based on
the monitor sections found in API consoles, the MC531 provides flexible, quality audio monitor high-
control for most production applications, in stand a - alone configuration.
Legend:
UPPER- CASE BOLD = SWITCHES, BUTTONS, and POTS
UPPER-CASE = REAR PANEL CONNECTIONS
Manual Revision History: YY- - MM DD format
Original: 21-07-07
Dan a Pfeifer is Professor of Recording Industry
at Middle Tennessee yState Universit
