Sivu 1/18
T25 Tube Compressor
OPERATOR’S MANUAL
Written for Automated Processes Incorporated
by Dan Pfeifer
Rev. 21-04-26
Table of Contents
About This Manual ...................................................................................... 1
1.0 Introduction ......................................................................................... 3
1.1 Features ..................................................................................................... 3
2.0 Quick Start ............................................................................................ 4
3.0 Overview .............................................................................................. 5
4.0 Compressor Controls 6............................................................................
4.1 Attack Time ................................................................................................ 6
4.2 Release Time .............................................................................................. 6
4.3 Ratio .......................................................................................................... 6
4.4 Input Level – Threshold .............................................................................. 6
4.5 Output Level – Make-up Gain ...................................................................... 6
5.0 Side- Chain and Routing Controls .......................................................... 7
5.1 De-esser (D-S) 7...........................................................................................
5.2
THR
THR
THR
THRTHRU
U
U
UUST
ST
ST
ST ST
® ........................................................................................................ 7
5.3 IN/out Switch 8............................................................................................
5.4 Bypass Switch ............................................................................................ 8
5.5 Stereo Link Switch ...................................................................................... 8
6.0 Level Indication .................................................................................... 9
6.1 Gain Reduction Meter & Peak Indicator ....................................................... 9
6.2 VU Meter .................................................................................................... 9
7.0 Tube Vent Window ................................................................................ 9
8.0 Power Switch & Rear Panel Connections ............................................ 10
8.1 Power Switch ........................................................................................... 10
8.2 Rear Panel ................................................................................................ 10
8.2.1 Audio Connections ................................................................................................. 10
8.2.2 AC Power .............................................................................................................. 10
APPENDIX................................................................................................. 11
A1 Technical Specifications ............................................................................. 12
A2 Block Diagram ........................................................................................... 12
A3 Recall Chart ............................................................................................... 13
A4 User Accessible Maintenance ..................................................................... 14
A4.1 Tube Replacement .................................................................................................. 14
A4.2 VU Meter Level Jumper ............................................................................................ 14
A5 API Limited Warranty and Service Information .......................................... 15
T25 Tube Compressor API Select
1
About This Manual
This manual explains the operation and applications of the API Select T25 Tube Compressor. This
manual is organized in sections that correspond to the front panel controls and rear panel interface.
Legend:
• UPPER- , CASE BOLD = POTS CONTROLS, SWITCHES, BUTTONS
• UPPER-CASE = REAR PANEL CONNECTIONS
Manual Revision History: YY- -MM DD format
Original: 21-04-26
Revised:
Dan Pfeifer is a Professor of
Recording Industry at
Middle Tennessee State University
