Specifications subject to change without notice.
© 2016 Bogen Communications, Inc.
54-2094-03D 1701 www.bogen.com
CK10B
Cable Kit, 10-Foot
Description
The CK10B is a 10-foot long Cable Kit. The kit can be used either as a main suspension
drop cable or as a safety cable.
Contents
10-foot long Cable w/ fixed loop, Cable Clamp, Instruction Sheet.
Installation
The cable can be secured to the speaker and the building structure in a variety of ways.
Below are three common approaches. The support structure MUST be able to support
100 lbs. to provide adequate safety margin.
The CK10B has a working load limit of 50 lbs. This working load limit is the maximum
load which should ever be applied to this product at any time.
CABLE CLAMPS MUST BE SECURELY TIGHTENED. FAILURE TO DO SO MAY RESULT IN PROPERTY
DAMAGE, INJURY OR DEATH, AND LEGAL LIABILITY TO YOU AND YOUR BUSINESS.
C A U T I O N
IN NO EVENT SHOULD THE WORKING LOAD LIMIT BE EXCEEDED. FAILURE TO FOLLOW THIS
INSTRUCTION MAY RESULT IN PROPERTY DAMAGE, INJURY OR DEATH, AND LEGAL LIABILITY TO
YOU AND YOUR COMPANY.
W A R N I N G
Note
IMPORTANT: For Vinyl-coated Cable, you must strip
away the coating in the area where the Cable Clamp
will be applied so that the clamp makes contact to the
wire core of the cable.
VINYL
COATING
EXPOSED
WIRE CORE
CLAMP
Pendant Drop Cable
Safety Cable for Pendant
(Primary Suspension Cables not shown)
Thread Spacer Nut completely on to
Eyebolt, then thread the Eyebolt into Safety Point.
Tighten securely (but do not over-tighten).
EYEBOLT
CABLE
CLAMP
CABLE
CLAMP
SUPPORT
STRUCTURE
SPACER NUT
FIXED
LOOP
FIXED
LOOP
