Feel what you’ve been missing
Thank you for your purchase of the ButtKicker ®
LFE, the most powerful, musically accurate
and long lasting low frequency audio driver
available today.
This User’s Guide is designed to help you install
and use the ButtKicker in order to receive the
most possible enjoyment.
If after following these instructions you are
not COMPLETELY THRILLED with the ButtKicker,
please contact us. Call, email or fax us. We will
do everything possible to make sure you are
completely satised.
Specications.
Dimensions: 5.375” h x 5.5” w
Frequency Response: 5 – 200 Hz
Weight: 11 lbs. / 5 kg.
Nominal Impedance: 4 ohms, inductive
Power Handling: 400 watts min. / 1500 watts max.
Wiring polarity: Red terminal is “Hot”
Thermal Limit (internal): 150 F. (70 C.)
Page 12
Specications/Contact Information
Contact Information
The Guitammer Company Inc.
PO Box 82
Westerville, OH 43086
support@guitammer.com
Voice: 888-676-2828
Fax: 815-346-9532
Please visit our website www.thebuttkicker.com for additional
technical information, specications and FAQs.
ButtKicker LFE Dimensions
All measurement in inches
Contents
Product Description ..........................................................1
Quick Setup ....................................................................2
Integration into Your Sound System ...................................3
Power ......................................................................3
Low End Roll Off .......................................................3
Source Material ........................................................3
Source Hookup to Amplier ...............................................4
Surround Sound System ............................................4
Gaming Consoles / Stereo Systems ..............................4
No “Subwoofer Output” .............................................5
Physical Mounting and Placement .......................................5
Mounting Considerations ...................................................6
General ...................................................................6
Floating Wood Floors .................................................8
Chairs and Couches ...................................................8
Platforms and Risers .................................................8
How to Determine How Many Isolators You Will Need .... 10
Vertical vs. Horizontal Mounting ................................. 10
Thermal Protection ........................................................ 11
Warranty ...................................................................... 11
Specications ................................................................ 12
Contact Information ........................................................ 12
Thermal Protection
If the ButtKicker® is driven too hard (i.e. given too much power
for too long of a period) it may overheat. For this reason,
each ButtKicker contains a thermal switch. This switch will
automatically disconnect the ButtKicker from the amplier if the
internal temperature of the shaker reaches a preset limit. This
should happen only rarely, and only when the unit is overdriven.
In most situations, the level of “shake” that is produced by the
ButtKicker, until it overheats, will be far more than needed. This
is also related to the “exibility” and size of the surface you are
endeavoring to shake. However, if tripped, the thermal switch
will automatically reset after the unit has cooled sufciently.
Then the ButtKicker will resume normal operation. Cooling
off time can be 5 - 20 minutes, depending on ventilation.
While in thermal protection mode, the ButtKicker may feel
quite warm to the touch, but the cutoff point has been set
to avoid damage.
Warranty
The Guitammer Company products are warranted against
defects in materials and workmanship for a period of two (2)
years from date of purchase by the original end-user. Items
returned for repair under warranty will be repaired or replaced at
the sole discretion of The Guitammer Company without charge
for materials or labor, providing such items are returned for
inspection, transportation prepaid, to The Guitammer Company
or an authorized service center. All repaired or replaced items will
be returned freight collect. Warranties do no apply to products
that have been subjected to abuse, accident, modications,
improper handling or installation, or repairs made by anyone
other than The Guitammer Company or an authorized service
center. The Guitammer Company shall be the nal authority in
the determination of all warranty service claims.
Please contact us before returning any defective products to
the store where they were purchased.
Page 11
Thermal Protection/Warranty
