Sivu 1/2
ø
21.5 – 32 mm
Click
Click
16°
TL-LD620G
Manual
Before using the light, read this manual
thoroughly and keep it for future reference.
ENG
HOW TO CHARGE
1
HOW TO MOUNT
2
PRECAUTIONS ON USE
• Check periodically to ensure that the light unit is
attached securely.
Do not use a damaged rubber band.
• Before your trip, please make sure the light is firmly
mounted to the bracket, it lights up, and the light is
not blocked by baggage, etc.
• Do not place it within children’ s reach.
• Charging, discharging, and storing in high
temperatures will cause the rechargeable battery to
deteriorate faster. Do not place the light inside a
vehicle or near a heater.
• This product is water-resistant under normal daily
use and can be used in the rain. However, do not
intentionally submerge it in water.
• If the light unit or parts become dirty with mud, etc.,
clean with a soft cloth which is moistened with mild
soap.
Never apply paint thinner, benzine or alcohol;
damage will result.
PRECAUTIONS ON CHARGING
• We recommend using 500+mA (USB2.0) USB
battery charger.
• Avoid charging in direct sunlight or in a vehicle
parked under direct sunlight, and make sure to
charge only when the ambient temperature is
between 41°F and 104 °F (5 and 40°C).
• Before charging, be sure that no dust or other
foreign objects attach to the USB plug.
• Do not subject the light to vibrations while charging.
• When your PC is in sleep state, the unit cannot be
charged.
• Once charging is complete, be sure to disconnect the
USB plug.
• Charging and lighting times are approximate values,
and will vary by environmental and user conditions.
• If the illumination time is significantly reduced even
after proper charging, the rechargeable battery may
be nearing the end of its service life. Dispose of the
battery as described in “PRECAUTIONS ON
DISPOSAL” .
STORAGE PRECAUTIONS
Cool and dry storage is recommended. For long period
storage, it is important to charge the battery 30
minutes every 6 months.
PRECAUTIONS ON DISPOSAL
When disposing of the light unit, remove the internal
rechargeable battery and dispose of it according to
local regulations.
Always charge the product before use.
Attach securely in the mounting position.
* The light can be used even when
mounted upside down or flipped
horizontally.
* Mount the light at least 250 mm above
the ground.
Bracket
Bracket rubber pad
Bracket rubber pad
Bracket
Light unit
USB cable
Design Pat. Pending
Copyright© 2016 CATEYE Co., Ltd.
TLLD620G-161011 3
Horizontal Vertical
(MICRO USB)
(SP-14-R)
Rubber band
Rubber band
USB cable
To PC or USB battery charger
Charging Charging is
completed
Standard
charging time
Switch (Indicator)
2 h
(USB 2.0)
Approx.
1
2
2
1
3
4
4
2-8-25, Kuwazu, Higashi Sumiyoshi-ku, Osaka 546-0041 Japan
Attn : CATEYE Customer Service Section
Phone : (06)6719-6863 Fax : (06)6719-6033
E-mail : support@cateye.co.jp URL : http://www.cateye.com
CO.,LTD.
When the remaining battery power is low,
the lighting mode switch turns on.
Charge the light as soon as possible.
Caution:
• The light must not be covered.
• If any of LEDs is broken, stop use of
the light.
Press and hold
ONOFF Approx.5
h
Switch (Indicator)
Constant
SWITCH OPERATION
Battery : Rechargeable lithium-ion battery (320 mAh)
Temperature range : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times
: About 300 times
(until the rated capacity drops to 70%)
Dimensions/weight : 2-3/64” x 25/32” x 1-17/64”
(52 x 20 x 32 mm) / 0.74 oz (21 g)
*
The specifications and design are subject to change without notice.
3
SPECIFICATIONS
LIMITED WARRANTY
2-year Warranty: Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materials and workmanship for a period of 2 years from original purchase.
If the product fails to work during normal use, CatEye will repair or replace the defect at no charge. Service must be performed by CatEye
or an authorized retailer. To return the product, pack it carefully and enclose the warranty certificate (proof of purchase) with instruction
for repair. Please write or type your name and address clearly on the warranty certificate. Insurance, handling and transportation charges
to CatEye shall be borne by person desiring service.
For UK and REPUBLIC OF IRELAND consumers, please return to the place of purchase. This does not affect your statutory rights.
Please register your CatEye product on the website.
http://www.cateye.com/en/support/regist/
INCLUDED
USB cable
(MICRO USB)
5342730
(SP-14-R)
5342450
Bracket
