Sivu 1/2
ø
21.5 – 32 mm
Clic
Clic
Clic
TL-LD620-R
Manual
Before using the light, read this manual
thoroughly and keep it for future reference.
ENG
HOW TO CHARGE
1
HOW TO MOUNT
2
Always charge the product before use.
Attach securely in the mounting position.
OPTION : Clip (C-2)
Bracket
Bracket rubber pad
Bracket rubber pad
Bracket
Clip
Light unit
USB cable
Horizontal
Vertical
(MICRO USB)
(SP-14-R)
Rubber band
Rubber band
USB cable
To PC or USB battery charger
Charging Charging is
completed
Standard
charging time
Switch (Indicator)
2 h
(USB 2.0)
Approx.
1
2
2
1
1
3
2
4
4
Design Pat. Pending
Copyright© 2021 CATEYE Co., Ltd.
TLLD620R-211006
3
WARNING!!!
• Check periodically to ensure that the light unit
is attached securely. Do not use a damaged
rubber band.
•
Always attention to the remaining battery power
by checking the indicator periodically while using.
CAUTION!
• Stop your bicycle to operate the switch.
• Do not place it within children’s reach.
• This unit is not totally waterproof. Please wipe
and dry it completely after using in rain.
Otherwise, it may cause failure.
• If the light unit or parts become dirty with mud,
etc., clean with a soft cloth which is moistened
with mild soap. Never apply paint thinner,
benzine or alcohol; damage will result.
LITHIUM-ION BATTERIES
Cautions on recharging
• We recommend using 500+mAh (USB2.0)
USB battery charger.
• Avoid charging in direct sunlight or in a
vehicle parked under direct sunlight, and
make sure to charge only when the ambient
temperature is between 41°F and 104 °F (5
and 40°C).
• Before charging, be sure that no dust or other
foreign objects attach to the USB plug.
• Do not subject the light to vibrations while
charging.
• When your PC is in sleep state, the unit
cannot be charged.
• Once charging is complete, be sure to
disconnect the USB plug.
• Charging time is approximate values, and will
vary depending on the environmental and
usage conditions.
Cautions in use
• Charging, discharging, and storing in high
temperatures will cause the rechargeable
battery to deteriorate faster. Do not place the
light inside a vehicle or near a heater.
• If the illumination time is significantly reduced
even after proper charging, the rechargeable
battery may be nearing the end of its service
life. Dispose of the battery as described in
“Cautions for dispose”.
Cautions on storage
Cool and dry storage is recommended. For long
period storage, it is important to charge the
battery 30 minutes every 6 months.
Cautions for dispose
When disposing of the light unit, remove the
internal rechargeable battery and dispose of it
according to local regulations.
2-8-25, KUWAZU, HIGASHI SUMIYOSHI-KU, OSAKA, JAPAN 546-0041
For inquiries, please visit https://cateye.com/intl/contact/
[For US Customers]
Please visit https://www.cateyeamerica.com/contact-us/
Toll Free : 800.5.CATEYE
CO.,LTD.
5 h
Approx.
SPARE / OPTIONAL PARTS
SWITCH OPERATION
Battery : Rechargeable lithium-ion battery
(320 mAh)
Temperature range : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times
: About 300 times
(until the rated capacity drops to 70%)
Dimensions/weight : 2-3/64” x 25/32” x 1-17/64”
(52 x 20 x 32 mm) / 0.76 oz (21.5 g)
* The specifications and design are subject to change without
notice.
3
SPECIFICATIONS
LIMITED WARRANTY
2-year Warranty:
Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materials
and workmanship for a period of 2 years from original purchase. If
the product fails to work during normal use, CatEye will repair or
replace the defect at no charge. Service must be performed by
CatEye or an authorized retailer. To return the product, pack it
carefully and enclose the warranty certificate (proof of purchase)
with instruction for repair. Please write or type your name and
address clearly on the warranty certificate. Insurance, handling and
transportation charges to CatEye shall be borne by person desiring
service.
For UK and REPUBLIC OF IRELAND consumers, please return to
the place of purchase. This does not affect your statutory rights.
Automatic battery-saving function
When the remaining battery power is low, the lighting mode switch starts flashing and
the lighting mode changes to flash. Charge the light as soon as possible.
ClickLighting mode switch
Press and hold
ON OFF
Flashing 30 h
Approx.
Rapid
Approx.
20 h
Group Ride
Constant 3 h
Approx.
USB cable
(MICRO USB)
5342730
Click
Lighting mode switch
Press and hold
ON / OFF
(SP-14-R)
5342450
Bracket
(C-2)
5342460
Clip
