Sivu 1/19
RM650 | RM750 | RM850
WEB: cors air.com
PHONE: (888) 222-4346
SUPPORT: suppor t.corsair.com
BLOG: corsair.com/blog
FORUM : forum.corsair.com
YOUTUBE: youtube.com/corsairhowto
© 20 21 C ORSAIR MEMORY Inc. All rights reserved. CORSAIR and the sails
logo are registered trademarks in the United States and/or other countries.
All other trademarks are the property of their respective owners. Product may
vary slightly from those pictured. 49-002491 AA
RM SERIEST M
Fully Modular ATX Power Supply
RM SERIESTM
ENGLISH 1 .......................................................
FRANÇAIS 7 .....................................................
DEUTSCH 13 ...................................................
NEDERLANDS 19 ............................................
DANSK 25 ........................................................
SUOMI 31 .........................................................
SVENSKA 37 ....................................................
NORSK 43 ........................................................
ITALIANO 49 .....................................................
ESPAÑOL 55 ....................................................
PORTUGUÊS 61 ..............................................
POLSKI 67 ........................................................
ČEŠTINA ..................................................... 73
SLOVENČINA .............................................. 79
MAGYAR 85 .....................................................
ROMÂNĂ ..................................................... 91
ССКИЙ ..................................................... 97
简体中文 .................................................... 103
繁體中文 .................................................... 109
日本 ........................................................ 115
한국어 ........................................................ 121
ةيبرعلا .......................................................... 127
1 2
ENGLISH ENGLISH
TABLE OF CONTENTS
SAFETY AND PROTECTION
CONGRATULATIONS ON THE PURCHASE OF YOUR
NEW CORSAIR RM SERIES ATX POWER SUPPLY!
CORSAIR RM Series fully modular power supplies deliver reliable 80 PLUS Gold efcient power to
your system.
Please be sure to only use the screws, cables, and other hardware included in the box. Use of third-party
hardware could result in damage to your power supply or your system and its components.
> Over-Voltage Protection (OVP)
Over-voltage protection for the 12V, 5V, and 3.3V DC outputs is required to comply with the ATX
specication. OVP shuts down the PSU in the event that the DC outputs exceed a set level, determined by
the PSU manufacturer.
> Over-Current Protection (OCP)
OCP is featured on the 3.3V, 5V, and 12V rails. OCP ensures that the output of the DC voltage rails remains
within safe operating limits.
> Over-Temperature Protection (OTP)
OTP ensures that the PSU will shut down when the internal temperature reaches a set point. This is usually as
a result of internal current overloading or a fan failure.
> Short-Circuit Protection (SCP)
A short-circuit is dened as any output impedance of less than 0.1 ohms. Amongst other things, SCP ensures
that the PSU shuts down should the 3.3V, 5V, and 12V rails short to any other rail, or to ground. It also ensures
that no damage should occur to the unit, or your PC’s components in the event of a short.
0
650
130 260 390 520
30
25
20
15
10
5
0
CORSAIR RM650 POWER SUPPLY FAN NOISE CURVE
FAN NOISE (dB)
POWER OUTPUT (W)
RM650 INCLUDED HARDWARE AND SPECIFICATIONS
Dimensions: 160mm(L) x 150mm(W) x 86mm(H)
Package contents: Power Supply, AC cable, DC cables, cable ties, mounting screws, safety leaet
CORSAIR RM650 POWER TABLE MAX LOAD MAX OUTPUT
MODEL +3.3VRPS0118 20A
130W
PART NO. +5VCP-9020233 / 75-004587 20A
AC INPUT RATING +12V100 240V a.c. 54A 650W
INPUT CURRENT -12V1 5A0A 0.3A 3.6W
FREQUENCY +5Vsb47 – 63Hz 3A 15W
TOTAL POWER: 650W
95
90
85
80
75
70
10
0
2 2010 50
CORSAIR RM650 POWER SUPPLY EFFICIENCY
input 115 input 230V a.c.V a.c.EFFICIENCY (%)
SYST EM LO AD (%)
RM650 2 .......................................................................................................................................................................
RM750 3 .......................................................................................................................................................................
RM850 4 .......................................................................................................................................................................
Installation 6 .................................................................................................................................................................
