JUICE EXTRACTOR
Model: EJE-A2050(SS)
Owners Manual
Please read this manual carefully
before operating your set.
Retain it for future reference.
Record model number and serial
number of the set.
See the label attached on the set and
quote this information to your dealer
when you require service.
For The Warranty Terms & Conditions, Please Refer To Warranty Certificate.
IMPORTANT SAFEGUARDS
When using this appliance, basic precautions should always be followed, including the following:
1. Read all instructions before use.
2. Do not use the appliance if the stailess steel grater and filter assembly is damaged.
3. Do not contact the plug or power cord with wet hands.
4. Do not let the plug remains plugged when not in use.
5. Do not immerse power cord, plug or the motor base into water or any other liquids.
6. Do not use this appliance when the plug or power cord is damaged or the plug is not properly
inserted.
7. Never bend or bind the power cord or apply by excessive force, otherwise it may cause damage. If
the power cord is damaged, it must be replaced by the manufacturer or after-sales service center
to avoid hazards.
8. Keep the power cord out of children. Do not let the power cord hang over the edge or the table or
worktop on which the appliance stands.
9. Operate the appliance on a dry and stable surface.
10. Do not carry the appliance during operation.
11. Do not operate the appliance continuously for more than 3 minutes.
12. Do not operate the appliance without any loading.
13. Only use the food pusher as supplied. Never put your fingers or any other sharp objects into the
feeder tube.
14. Do not touch the cutting blades at the bottom of the stailess steel grater and filter assembly.
15. Before removing the juicer cover, switch off and wait for the filter to stop.
16. Always make sure the appliance is properly and completely assembled before operating. The unit
will not turn on unless it is properly assembled.
17. Before disassembling the appliance, switch off the power and wait for the filter to stop operating.
18. Before cleaning the appliance, make sure the control switch have turn to “0” position. Switch off the
power and unplug the plug from wall outlet then slowly remove the parts.
19. This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
20. Children should be supervised to ensure that they do not play with the appliance.
21. This appliance is intended to be used in household and similar applications.
22. Save this instructions for future reference.
DESCRIPTION OF PARTS
1. Motor base
2. Control switch
z 0 Stop / no power
z 1 Low speed
z 2 High speed
3. Safety locking arms
4. Pulp container
5. Pulp chute/ Juicer cover
6. Food pusher
7. Juicer collector assembly
8. Juice jug
9. Rubber feet
10. Spout cover
11. Light indicator
12. Stainless steel grater and filter
13. Feeder tube
ASSEMBLE THE APPLIANCE
(Figure 1)
Place the motor base on a stable surface.
Place the spout cover on the motor base with
the spout hole at the right hand side (facing the
direction of the safety locking arms).
Swivel the spout cover until it fits on the motor
base.
Insert the juicer collector assembly on the spout
cover.
(Figure 2)
Hold the stainless steel grater and filter
assembly as per figure 2.
Install the stainless steel grater and filter
assembly into the motor base.
Twist the filter assembly and gently push down
until it is seated on the motor base.
NOTE: The top edge of the grater should not be
higher than the edge of the juice collector assembly
when properly installed.
