GLP impression FR10 Bar Käyttöohje
Lue alta 📖 käyttöohje suomeksi merkille GLP impression FR10 Bar (5 sivua) kategoriassa Helpotus. Tämä opas oli hyödyllinen 2 henkilölle ja sai 4.5 tähden keskimäärin 2 käyttäjältä
Sivu 1/5
from software version: v0.60
support@glp.de
www.glp.de
Instruction Manual
20
GLP German Light Products GmbH
impression X4 BAR 20 manual (v1.8) from software version: v0.60 2
Contents
1 Description of Device ..................................................................................................... 3
2 Safety Instructions .......................................................................................................... 4
3 Mounting ........................................................................................................................ 6
3.1.1 Operating on the Floor (Upright) ......................................................................... 7
3.1.2 Mounting in hanging or sideways position .......................................................... 7
3.2 Securing the Fixture ............................................................................................... 7
3.3 Alignment of the Fixtures ....................................................................................... 8
3.4 Connections ........................................................................................................... 8
3.4.1 Power Supply ..................................................................................................... 8
3.4.2 DMX ................................................................................................................... 9
4 The Menu Field .............................................................................................................10
5 DMX Chanel Selection (DMX Protocol) .........................................................................12
5.1 Normal Mode (norm) 34 DMX channels: ...............................................................13
5.2 Compressed Mode (comp) 20 DMX Channels: .....................................................15
5.3 High Resolution Mode (Hires) 35 DMX Channels: .................................................17
5.4 Dual Pixel Mode (dpix) 48 DMX Channels: ...........................................................19
5.5 Dual Pixel High Resolution Mode (DPixH) 49 DMX Channels: ..............................21
5.6 Single Pixel Mode (spix) 88 DMX Channels: .........................................................23
5.7 Single Pixel High Resolution Mode (SPixH) 89 DMX Channels: ............................26
6 Accessories ...................................................................................................................30
6.1 Optional diuser lter: ...........................................................................................30
6.2 End Omega Bracket: .............................................................................................31
7 Maintaining and Cleaning ..............................................................................................32
7.1 Safety regulations .................................................................................................32
7.2 Maintenance and Interval (rule- -thumb) of ..............................................................32
8 Technical Specications: ...............................................................................................33
9 Dimensions ...................................................................................................................34
GLP German Light Products GmbH
impression X4 BAR 20 manual (v1.8) from software version: v0.60 3
1 Description of Device
1. Moving Bar (actively and passively cooled)
2. LCD-Display / Menu (data entry)
3. Base with rubber feet and Camlock mounting system
A) Base side left
B) Base side right
4. DMX Input (5 pin)
5. Mains Input (blue powerCON)
6. Micro-fuse 5x20mm, T5A
7. Mains Output (white werCON) po
8. DMX Output (5 pin)
1
2
3
4
5
6
7
8
A
B
