Sivu 1/6
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
HF70
Quick Start Guide
Helia 70 Watt 4 in. Fresnel Daylight LED Studio Light w/ DMX
What’s Included
1x Helia 70 Watt Fresnel
1x Barn Doors
1x Gel Frame
1x Yoke
1x AC Power Cord
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Getting Started
Thank you for buying the HF150 Fresnel Light from ikan. Please carefully read the instructions and guide before operating the products. The guide includes
product usage and maintenance. When you operate the product, please make sure that you have read the instructions carefully.
All the content of the manual is based on up-to-date information; technical data subject to change without notice.
Safety Instructions
1. Connect the AC power cable to the HF70 light before plugging into the power source. You risk electrocution by not following this instruction.
2. Don’t drag cables with excessive force. Any repairs on the products should be performed by ikan technicians. Users should not remove the power
supply, or else the damage will not be covered under warranty.
3. Be sure that the power is off before connecting and changing the fixture head or disconnecting your cable from the power source. We recommend using
Ikan connecting cables and connectors to avoid electrical shock.
4. The voltage shouldn’t exceed the value in the technical specifications. If the voltage is greater than, or less than the regulated values, it could damage
the product.
Overview
Color temperatures of 5600K (daylight). Ikan developed the HF70 Fresnel Light to handle both these temperatures. The HF70 offers a professional and
customizable LED light source. In addition, the light features separately-cooling ducts for optimizing heat dissipation. Specifically, the HF70 Fresnel Light
offers the following features:
1. The 10-100% brightness incremental adjustment of the 5600K temperature
2. A four-inch diameter Fresnel lens provides even, well-distributed light
3. Ultra-low noise and active cooling technology contribute to excellent thermal stability.
4. The power supply will automatically cut off when the fixture overheats.
5. The bright LCD readout is easy to view, enabling smooth adjustment of functions.
6. Digitally adjustable knob allows you to adjust menu settings quickly and accurately.
7. DMX Channel assignments can be adjusted as needed.
8. AC/DC power supply, AC110VAC-270VAC
Instructions
LED Fresnel housing is made aluminum alloy, which is heavy-duty, lightweight, and easy to transport.
The HF70structure is illustrated on the following page.
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Appearance & Structure - Front
5/8 Receiver: Connecting the lamp with stands or grid mounts
Yoke: Adjustable lighting direction
The pushing claw of barn doors; the holding claw of barn doors:
Appearance & Structure - Back
Power switch: Turn on/turn off power
Brightness Knob: Adjusts brightness from 10%-100%
(Press in to Toggle off the LED)
LCD Setting Screen: Displays brightness and color temperature
+&- Buttons: Adjusts the DMX channels
SYNC/DC24V: Possibe future update usuage
Fuse Cap: Fuse Holder with T6.3A 250V fuse
AC 110-220V Power Connector: Connecting with 110-220V power cable
Focusing Knob: Changing the Beam angle of the light from flood to spot
5/8 Receiver
LCD Setting Screen
Color/ Brightness
Knob Power Switch
Pushing Claw
Barn Doors
Holding Claw
SYNC
SET
mod e
DC42V
D
MX
512
SPOT
OFF/O
N
Yoke
+ & - Buttons
SYNC
DC24V
DMX IN/OUT
Fuse Cap
AC 110-220C
Power Connector
Focusing
Knob
