SPECIFICATIONS:
MODEL NO. : IAF-761DH
RATED VOLTAGE : 230Va.c. 60Hz
POWER CONSUMPTION : 1600 Watts
CAPACITY : 6.0L
BOX DIMENSION : 655*375*370mm
UNIT DIMENSION : 360*3 *355mm 20
GROSS WEIGHT : 5.43KG
UNIT WEIGHT : 4.5 KG
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed,
including the following:
1. Read all instructions carefully.
2. fore using the unit, check if the voltage indicated corresponds with the convenience Be
outlet (230Va.c.).
3. Do not use any appliance with a damage cord or plug. If the cord is damaged it should
be replaced with the same type and size or bring the unit to the nearest Imarex
Authorized Service Center.
4. Do not use the two-way socket with another appliance.
5. Place the Turbo Fryer on a dry, stable surface.
6. Do not place on or near gas stove, electric burner or in a heated oven.
7. Keep curtains, furniture, flammable materials, etc. away from the unit and from the
convenience outlet where the unit is plugged.
8. Do not move the unit while cooking is in progress.
9. Children should be supervised to ensure that they do not play with the appliance.
10. This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliances by a
person responsible for their safety.
11. Do not cover the air inlet and outlet opening while the appliance is operating.
12. Do not pour oil into the frying pan that may cause re hazard.
13. Keep the turbo fryer at least 4 inches away from walls or other objects during
operation.
14. CAUTION: Never leave the unit unattended while cooking.
15. Keep the unit in a dry and cool place.
16. For household use only; not intended for any business purposes.
17. Save this instruction for future reference.
DESCRIPTION OF PARTS:
CONTROL PANEL:
PRE-SET ICONS
ICON
DESCRIPTION
DEFAULT
TEMP
DEFAULT
TIME
ADJUSTABLE
TEMP
ADJUSTABLE
TIME
French Fries
200°C
17mins
160°C to
200°C
10 to 25 mins
Chicken Legs
200°C
25mins
160°C to
200°C
10 to 35 mins
Chicken Wings
200°C
18mins
100°C to
200°C
10 to 25 mins
Fish
180°C
18mins
160°C to
200°C
10 to 20 mins
Beef
200°C
10mins
100°C to
200°C
10 to 25 mins
Shrimp
200°C
9mins
160°C to
200°C
5 to 20 mins
Skewers
180°C
18mins
100°C to
200°C
10 to 60 mins
Pizza
160°C
17mins
100°C to
200°C
10 to 30 mins
Mushroom
180
12mins
100°C to
200°C
5 to 20 mins
Vegetables
160
15mins
100°C to
200°C
10 to 25 mins
Potato
170
50mins
100°C to
200°C
10 to 60 mins
Cupcake
160
15mins
100°C to
200°C
10 to 25 mins
2
CONTROL ICONS
ICON
DESCRIPTION
POWER
ON: Press button to turn ON the unit
A beep sound will be heard and the power light indicator will
keep ashing to indicate that the unit is in standby mode
OFF: Press and hold button for 3 seconds, the digital display will be
off while the preset and lower heater icons will keep flashing, inner lamp
will still be ON. The unit will automatically turn o after 30 seconds
START/PAUSE
Press button to start / pause the program
PRE-SET
Press button to select the desired function
Press it repeatedly until you reach the desired function
TIMER
To select the desired time, please button then press
or button to adjust the time
TEMPERATURE
To select the desired temperature, please button then
press or button to adjust the temperature
LOWER HEATER
Lower heater only: Place the food at the bottom of the frying
basket then press button and adjust to your desired
temperature and time by pressing or button. Lastly,
press button to start the cooking cycle
You could also select pre-set function and use the lower
heater at the same time but it can only be used on the
following functions: (1) Chicken legs, (2) Chicken wings, (3)
Fish and (4) Steak
Pre-set + Lower Heater: Applicable for
Press button to select the desired function, adjust
temperature and time according to your requirement then
press button to enable the lower heater.
Lastly, press button to start the cooking cycle
Please do not use the grill tray when using the lower heater.
Place the food in the frying basket
FOR INITIAL USE:
1. Remove the stickers.
2. Clean the frying basket and grill tray thoroughly with hot water, detergent and
non-abrasive sponge.
3. Wipe the appliance with wet cloth.
*Note: Do not immerse the turbo fryer body in water or any other liquids.
4. After cleaning, return the grill tray into the frying basket.
3
HOW TO USE:
1. Place the unit on a at surface.
2. Place the food into the frying basket.
*Note:
- To ensure proper cooking and air circulation, do not ll the unit more than
2/3 full.
- Maximum frying capacity of fresh vegetable is 3 cups. Do not exceed with
the maximum capacity.
- Make sure that the frying basket is fully closed.
3. Plug the unit into a convenience outlet. A beep sound will be heard and power
light indicator will keep ashing to indicate that the unit is in standby mode
4. Select the desired function by pressing ‘PRE SET’ icon repeatedly.-
5. If you wish to adjust the time and temp, select the desired time and temperature
by pressing ‘TIME and TEMP’ icons followed by ‘UP’ and ‘DOWN’ icon to
manually adjust the desired time and temperature then press ‘START’ icon to
start the cooking cycle.
For better cooking result, open the frying basket halfway of its cooking time
then shake the food inside the frying basket
*Note: The heat will automatically stop when the frying basket is removed from
the unit.
6. Beep sound will be heard once the cooking is done.
7. Unplug the unit after every use.
CLEANING AND MAINTENANCE:
1. Unplug and wait until the unit cool down before moving or cleaning the unit.
2. Wipe the body of the turbo fryer with moist cloth.
3. Clean the grill tray and frying basket with hot water and liquid detergent.
4. Do not use abrasive materials to avoid scratches.
REMINDER: Please do not forget to register your product warranty through the
warranty registration website at
https://imarflex.ph
Distributed By: Xelframe Enterprises Inc.
Unit 711 IPI Buendia Tower Condo 501, Gil Puyat Ave., Pasay
Made in China
