ARC10, ARC30,
ARC1000,
ARC Center
simple set-up guide
thank you for choosing JBL. For over 50 years, JBL has
been involved in every aspect of musical and lm recording and
reproduction, from live performances to monitoring the recordings
you play in your home, car, or oce.
We’re condent that the JBL loudspeakers you have
chosen will provide every note of enjoyment that you expected –
and that when you think about purchasing additional audio
equipment for your home, car, or oce, you will once again
choose JBL.
Please take a moment to complete the enclosed prole card. It
enables us to keep you posted on our latest advancements, and
helps us to better understand our customers and build products
that meet your needs and expectations.
JBL Consumer Products
one. Speaker Placement
ARC10, ARC30
ARC1000
ARC Center
Specications
Occasional renements may
be made to existing products
without notice, but will
always meet or exceed origi-
nal specications unless
otherwise stated.
*The maximum recommended
amplier power rating will
ensure proper system head-
room to allow for occasional
peaks. We do not recommend
sustained operation at these
maximum power levels.
ARC10 ARC30
Frequency Response (–6dB): 75Hz – 20kHz 50Hz – 23kHz
Recommended Maximum
Power Handling*: 50 watts 125 watts
Sensitivity @ 1 watt/1 meter:
86dB 90dB
Nominal Impedance: 8 ohms 8 ohms
Crossover Frequency: 2200Hz 3700Hz
Woofer: 5-1/4" 6-1/2"
Midrange: N/A N/A
Tweeter: 2" paper cone 1" pure titanium
Dimensions (HxWxD): 11 x 6-1/2 x 7-1/4 inches 17-3/8 x 9-5/8 x 8-1/4 inches
280 x 165 x 184mm 441 x 245 x 210mm
Weight (each): 7 lbs/3.2 kg 16 lbs/7.3 kg
ARC1000 ARC Center
Frequency Response (–6dB): 36Hz – 23kHz 100Hz – 20kHz
Recommended Maximum
Power Handling*: 175 watts 70 watts
Sensitivity @ 1 watt/1 meter:
90dB 89dB
Nominal Impedance: 8 ohms 8 ohms
Crossover Frequency: 930Hz, 5600Hz 9000Hz
Woofer: 10" 2 x 4-1/2"
Midrange: 5" N/A
Tweeter: 1" titanium 2" paper cone
Dimensions (HxWxD): 39 x 12 x 11 inches 6 x 16 x 6-1/4 inches
991 x 305 x 209mm 152 x 406 x 159mm
Weight (each): 44 lbs/20 kg 9 lbs/4.1 kg
