BALBOA 10, BALBOA 30
AND BALBOA CENTER
BALBOA SERIES
®
OWNER’S GUIDE
MODEL: BALBOA 10
SPEAKER PLACEMENT
Proper placement of the
speakers is an important step
in obtaining the most realistic
soundstage possible. These
recommendations are for the
optimal placement of the
loudspeakers. Use these
placement recommendations
as a guide. Slight variations
will not diminish your listen-
ing pleasure.
All of the Balboa Series loud-
speakers referred to in this
guide are video-shielded
and can safely be placed
near a television.
As front speakers
MODEL: BALBOA 30
As surround speakers
MODEL: BALBOA CENTER
The Balboa Center loud-
speaker is designed to com-
plement all of the Balboa
Series loudspeakers. It is the
ideal way to re-create the
cinematic experience in your
home.
†Placement for surround back
speakers in 6.1/7.1 systems,
or alternate placement for
side surround speakers in 5.1
systems.
MODELS:
BALBOA 10 AND
BALBOA CENTER
The supplied self-adhesive
rubber feet may be attached
to the bottom corners of your
speakers to protect your
furniture.
MODEL: BALBOA 30
This model is shipped with
four self-adhesive nonskid
pads that are to be used when
the loudspeaker is intended
to be placed on a smooth-
surfaced floor, such as tile or
hardwood. Gently lay the
speaker on its side (not its
front or back) on a soft,
nonabrasive surface. Attach
each pad to the bottom of its
foot in the widest portion of
the recessed area.
DO NOT attach the pads if
the speaker will be placed
on carpeting.
NEVER drag the speaker to
move it, as this will damage
the pads, the feet and/or the
wood cabinet itself. Always
lift the speaker and carry it to
its new location.
CAUTION: Floorstanding
(tower) loudspeakers have a
high center of gravity and may
become unstable and tip over
during earthquakes, or if
rocked, tipped or improperly
positioned. If this is a concern,
these speakers should be
anchored to the wall behind
them, using the same proce-
dures and hardware custom-
ary for anchoring bookcases
and wall units. The customer
is responsible for proper instal-
lation and proper selection of
hardware.
Without pad With pad
Place pads here
SPEAKER PLACEMENT (CONTINUED)
MODELS:
BALBOA 10 AND
BALBOA 30
MODEL:
BALBOA CENTER
Speakers and electronics
terminals have correspon-
ding (+) and (–) terminals. It
is important to connect both
speakers identically: (+) on
the speaker to (+) on the
amplifier and (–) on the
speaker to (–) on the ampli-
fier. Wiring “out of phase”
results in thin sound, weak
bass and poor imaging. With
the advent of multichannel
surround sound systems,
connecting all of the speak-
ers in your system with the
correct polarity remains
equally important in order to
preserve the proper ambi-
ence and directionality of the
program material.
To use the binding-post
speaker terminals, unscrew
the colored collar until the
pass-through hole in the cen-
ter post is visible. Insert the
bare end of the wire through
this hole; then screw the col-
lar down until the connection
is tight.
The hole in the center of
each collar is intended for
use with banana-type con-
nectors. To comply with
European CE certification,
these holes are blocked with
plastic inserts at the point of
manufacture. Use of banana-
type connectors requires the
removal of the inserts. Do
not remove these inserts if
you are using the product
in an area covered by the
European CE certification.
Receiver
Speaker Outputs
– +
CENTER
– +
– +– +
– +
Receiver’s Speaker Outputs
LEFT
LEFT
RIGHT
RIGHT
– +
SPEAKER CONNECTIONS
TROUBLESHOOTING
If there is no sound from
any of the speakers:
• Check that receiver/ampli-
fier is on and that a source is
playing.
• Review proper operation of
your receiver/amplifier.
If there is no sound com-
ing from one speaker:
• Check the “Balance”
control on your receiver/
amplifier.
• Check all wires and connec-
tions between receiver/
amplifier and speakers.
• Make sure no wires are
touching other wires or
terminals and creating a
short circuit.
• Make sure all wires are
connected. Make sure none
of the speaker wires are
frayed, cut or punctured.
• In Dolby* Digital or DTS®
modes, make sure that the
receiver/processor is config-
ured so that the speaker in
question is enabled.
• Turn off all electronics and
switch the speaker in ques-
tion with one of the other
speakers that is working cor-
rectly. Turn everything back
on, and determine whether
the problem has followed the
speaker, or has remained in
the same channel. If the
problem is in the same chan-
nel, the source of the prob-
lem is most likely with your
receiver or amplifier, and
you
should consult the owner’s
manual for that product for
further information.
If the
problem has followed the
speaker, consult your dealer
for further assistance or, if
that is not possible, visit
www.jbl.com for further
information.
If the system plays at
low volumes but shuts
off as volume is
increased:
• Check all wires and connec-
tions between receiver/
amplifier and speakers.
• Make sure all wires are
connected. Make sure none
of the speaker wires are
frayed, cut or punctured.
• If more than one pair of
main speakers is being used,
check the minimum imped-
ance requirements of your
receiver/amplifier.
If there is no (or low)
bass output:
• Make sure the polarities
(+ and –) of the left and right
“Speaker Inputs” are
connected properly.
• If your system includes a
powered subwoofer, make
sure it is connected correctly,
plugged into an active AC
outlet and turned on. See the
owner's guide for your sub-
woofer for more information.
• If your system does not
include a powered sub-
woofer, consider adding one
for use with digital “.1” sur-
round formats.
If there is no sound from
the surround speakers:
• Check all wires and con-
nections between receiver/
amplifier and speakers. Make
sure all wires are connected.
Make sure none of the
speaker wires are frayed,
cut or punctured.
• Review proper operation of
your receiver/amplifier and
its surround sound features.
• Make sure the movie or TV
show you are watching is
recorded in a surround sound
mode. If it is not, check to
see whether your receiver/
amplifier has other surround
modes you may use.
• In Dolby Digital or DTS
modes, make sure your
receiver/processor is config-
ured so that the surround
speakers are enabled.
• If you are using both side
surround and back surround
speakers, make sure that your
receiver/processor is config-
ured for 6.1/7.1 operation.
• Review the operation of your
DVD player and the jacket of
your DVD to make sure that
the DVD features the desired
Dolby Digital or DTS mode,
and that you have properly
selected that mode using both
the DVD player’s menu and the
DVD disc’s menu.
Declaration of Conformity
We, Harman Consumer Group International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility that the products
described in this owner’s manual are in compliance
with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Gary Mardell
Harman Consumer Group International
Chateau-du-Loir, France 1/05
