Sivu 1/8
CST55, CSC55, CSS10
JBL CINEMA SOUND™
OWNER’S GUIDE
®
INCLUDED
THANK YOU FOR CHOOSING JBL
For more than 60 years, JBL
has been involved in every
aspect of music and film
recording and reproduction,
from live performances to
the recordings you play in
your home, car or office.
We’re confident that the JBL
system you have chosen will
provide every note of enjoy-
ment that you expect –
and that when you think
about purchasing additional
audio equipment for your
home, car or office, you will
once again choose JBL.
Please take a moment to
register your product on our
Web site at www.jbl.com.
It enables us to keep you
posted on our latest advance-
ments, and helps us to better
understand our customers
and build products that
meet their needs and
expectations.
JBL Consumer Products
CST55
CSC55 CSS10
Grille
Grille
2
READ FIRST! Important Safety Precautions!
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near
water.
6. Clean only with a dry cloth.
7. Do not block any ventilation
openings. Install in accordance with
the manufacturer’s instructions.
8. Do not install near any heat
sources such as radiators, heat
registers, stoves or other apparatus
(including amplifiers) that produce
heat.
9. Do not defeat the safety purpose
of the polarized or grounding-type
plug. A polarized plug has two
blades with one wider than the
other. A grounding-type plug has
two blades and a third grounding
prong. The wide blade or the third
prong are provided for your safety.
If the provided plug does not fit into
your outlet, consult an electrician
for replacement of the obsolete
outlet.
10. Protect the power cord from
being walked on or pinched, partic-
ularly at plugs, convenience recep-
tacles and the point where they exit
from the apparatus.
11.
Only use attachments/acces-
sories specified by the manufacturer.
12. Use only with the cart, stand,
tripod, bracket or table specified by
the manufacturer or sold
with the apparatus.
When a cart is used,
use caution when moving
the cart/apparatus combination to
avoid injury from tip-over.
13. Unplug this apparatus during
lightning storms or when unused for
long periods of time.
14. Refer all servicing to qualified
service personnel. Servicing is
required when the apparatus has
been damaged in any way, such
as power-supply cord or plug is
damaged, liquid has been spilled
or objects have fallen into the
apparatus, the apparatus has been
exposed to rain or moisture, does
not operate normally, or has been
dropped.
15. Do not use attachments not
recommended by the product
manufacturer, as they may cause
hazards.
16. This product should be operated
only from the type of power source
indicated on the marking label. If
you are not sure of the type of
power supply to your home, consult
your product dealer or local power
company. For products intended to
operate from battery power or other
sources, refer to the operating
instructions.
17. If an outside antenna or cable
system is connected to the product,
be sure the antenna or cable sys-
tem is grounded so as to provide
some protection against voltage
surges and built-up static charges.
Article 810 of the National
Electrical Code, ANSI/NFPA 70,
provides information with regard to
proper grounding of the mast and
supporting structure, grounding of
the lead-in wire to an antenna
discharge unit, size of grounding
conductors, location of antenna-
discharge unit, connection to
grounding electrodes, and require-
ments for the grounding electrode.
See Figure A.
18. An outside antenna system
should not be located in the vicinity
of overhead power lines or other
electric light or power circuits, or
where it can fall into such power
lines or circuits. When installing an
outside antenna system, extreme
care should be taken to keep from
touching such power lines or circuits,
as contact with them might be fatal.
19. Do not overload wall outlets,
extension cords, or integral
convenience receptacles, as this
can result in a risk of fire or
electric shock.
20. Never push objects of any kind
into this product through openings,
as they may touch dangerous volt-
age points or short-out parts, which
could result in a fire or electric
shock. Never spill liquid of any kind
on the product.
21. The apparatus shall not be
exposed to dripping or splashing,
and no objects filled with liquids,
such as vases, shall be placed on
the apparatus.
22. Do not attempt to service this
product yourself, as opening or
removing covers may expose you to
dangerous voltage or other hazards.
Refer all servicing to qualified
service personnel.
23. When replacement parts are
required, be sure the service tech-
nician has used replacement parts
specified by the manufacturer or
that have the same characteristics
as the original part. Unauthorized
substitutions may result in fire,
electric shock or other hazards.
24. Upon completion of any service
or repairs to this product, ask the
service technician to perform safety
checks to determine that the prod-
uct is in proper operating condition.
25. The product should be mounted
to a wall or ceiling only as recom-
mended by the manufacturer.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: To reduce the risk of electric shock,
do not remove cover (or back).
No user-serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION: To prevent electric shock,
do not use this (polarized) plug with
an extension cord, receptacle or other outlet
unless the blades can be fully inserted to
prevent blade exposure.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
“dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
Figure A.
Example of Antenna Grounding as per
National ElectricalCode ANSI/NFPA 70
3
SPEAKER PLACEMENT
SUBWOOFER
SURROUND SPEAKERS
FRONT
SPEAKERS
0–2 ft
0–0.6m
The front speakers should be
placed the same distance
from each other as they are
from the listening position.
They should be placed at
about the same height from
the floor as the listeners’
ears will be, or they may be
angled toward the listeners.
The center channel speaker
should be placed slightly
behind the front left and right
speakers, and no more than
2 feet (0.6m) above or below
the tweeters of the left and
right speakers. It is often
convenient to set the center
speaker on top of the televi-
sion set, as shown in the
drawing.
The JBL Cinema Sound
speaker system may be used
in 5.1-,
6.1- or 7.1-channel
applications. In 5.1-channel
applications, two
of the sur-
round speakers should be
placed slightly behind the lis-
tening position and, ideally,
should face each other and
be at a
level higher than the
listeners’
ears. If that is not
possible, they may be placed
against a wall behind the
listening position,
facing for-
ward. In 6.1-channel
applica-
tions, two of the surround
speakers should be placed in
the side positions, and a sin-
gle surround back speaker
should be placed against the
wall behind the listening
position. In 7.1-channel
applications, place
two of the
surround speakers
in the side
positions, and place the two
surround back speakers
against the rear wall.
In Dolby®Digital and DTS®
systems, it is best to aim all
of the speakers (except the
subwoofer) toward the lis-
tening position at or slightly
above about ear-level height.
In systems where only ana-
log surround processing
(such as Dolby Pro Logic® II)
is available, it may be prefer-
able to aim the speakers
straight out from the wall to
obtain a more diffuse sound.
The low-frequency material
reproduced by the subwoofer
is mostly omnidirectional,
and this speaker may be
placed in a convenient loca-
tion in the room. However,
bass reproduction will be
maximized when the sub-
woofer is placed in a corner
along the same wall as the
front speakers. Experiment
with subwoofer placement
by temporarily placing the
subwoofer in the listening
position and moving around
the room until the bass
reproduction is best. Place the
subwoofer in that location.
CENTER CHANNEL
SPEAKER
†Single surround back speaker
may be used with 6.1 receivers
and processors.
Alternate placement for surround speakers when only 5.1 channels are used; required placement for surround back
speakers in 7.1-channel systems.
