JBL FM62 Käyttöohje
Lue alta 📖 käyttöohje suomeksi merkille JBL FM62 (12 sivua) kategoriassa Kaiutin. Tämä opas oli hyödyllinen 4 henkilölle ja sai 4.5 tähden keskimäärin 2 käyttäjältä
Sivu 1/12
thank you for choosing JBL. For over 50 years, JBL has
been involved in every aspect of musical and film recording and
reproduction, from live performances to monitoring the recordings
you play in your home, car, or office.
We’re confident that the JBL loudspeakers you have
chosen will provide every note of enjoyment that you expected –
and that when you think about purchasing additional audio equip-
ment for your home, car, or office you will once again choose JBL.
Please take a moment to complete the enclosed profile card. It
enables us to keep you posted on our latest advancements, and
helps us to better understand our customers and build products
that meet your needs and expectations.
FM52, FM62,
FM82, FM65C
& FM8SUB
simple
set-up guide
one. Speaker Placement
FM52, FM62, FM82 as front speakers
FM52, FM62, FM82 as rear speakers
FM65C in ceiling FM8SUB subwoofer
in wall
5 – 6 ft.
two. Speaker Connections
Speakers and electronics ter-
minals have corresponding (+)
and (–) terminals. It is impor-
tant to connect both speakers
identically: (+) on the speaker
to (+) on the amplifier and (–)
on the speaker to (–) on the
amplifier. Wiring “out of phase”
results in thin sound, weak bass
and a poor stereo image.
Connection Tips
FM52, FM62, FM82, FM65C
FM8SUB
Wire Length Recommended Size
Up to 20 ft. 16 gauge
Up to 30 ft. 12 gauge
Greater than 30 ft. 10 gauge
– +– +
Front or Rear Speaker Outputs
LEFT RIGHT
LEFT RIGHT
–+–+
– +– +
Front Speaker Outputs
LEFT RIGHT
Connection (1) Connection (2)
–+–+
Right Satellite
–+
Left Satellite
–+
Subwoofer
The wires for both speakers
should be the same length. If
one speaker is placed closer to
the amplifier than the other,
hide the excess wire behind
the wall.
The FM8SUB has two speaker
connections. Connect one set of
terminals, along with your left
satellite to the left channel of
your amplifier. Connect the
other set of terminals, along
with your right satellite to the
right channel of your amplifier.
