Sivu 1/4
TLX Center1
TLX Center2
simple set-up guide
thank you for choosing JBL. For over 50 years, JBL
has been involved in every aspect of musical and lm recording
and reproduction, from live performances to monitoring the
recordings you play in your home, car, or oce.
We’re condent that the JBL Loudspeaker you have
chosen will provide every note of enjoyment that you expected –
and that when you think about purchasing additional audio
equipment for your home, car, or oce, you will once again
choose JBL.
Please take a moment to complete the enclosed prole card.
It enables us to keep you posted on our latest advancements,
and helps us to better understand our customers and build
products that meet your needs and expectations.
JBL Consumer Products
– + – +
– +
– +
– +
Receiver
Center
Front
Left
Left
Surround
Front
Right
Right
Surround
– +
Center
Speaker
two. Speaker Connections
Separate and strip the ends of
the speaker wire as shown.
Speakers and electronics ter-
minals have corresponding (+)
and (–) terminals. It is impor-
tant to connect both speakers
identically: (+) on the speaker
to (+) on the amplier and
(–) on the speaker to (–) on
the amplier. Wiring “out of
phase” results in thin sound,
weak bass and a poor stereo
image.
Connection Tips
On TV.
one. Speaker Placement
0-2 ft.
TLX Center1
TLX Center2
JBL continually strives to improve its products. New materials, production methods and design renements are introduced into
existing models without notice as a routine expression of our design philosophy. For this reason, JBL loudspeakers may dier in
some respect from their published specications and descriptions, but will always equal or exceed the original specications unless
otherwise stated.
If there is no sound from the center
speaker, check the following:
• Make sure that your receiver’s Center Channel
Mode is in the “normal” or “wide” position. If
it is in the “phantom” position, the center
speaker will not play.
• Check all connections between processor/
amplier and the center speaker.
If the system plays at low volumes but
shuts o as volume is increased, check
the following:
• Check all wires and connections between
receiver/amplier and speakers. Make sure all
wires are connected. Make sure none of the
speaker wires are frayed, cut, or punctured.
• If more than one pair of main speakers is
being used, check the minimum impedance
requirements of your receiver/amplier.
Troubleshooting
TLX Center1
High-Frequency Transducer
Low Frequency
Crossover Frequency
Frequency Response (–6dB)
Sensitivity (1 watt/1 meter)
Impedance
Recommended
Amplier Power*
Dimensions (HxWxD)
Weight
Center
2-1/2" ber cone
4-1/2" (2)
7.5kHz
90Hz – 20kHz
90dB
8 ohms (nominal)
10 – 100 watts
6-1/2 x 18-1/2 x 6-1/8"
165 x 470 x 156mm
10 lbs/4.5 kg
Specications
TLX Center2
High-Frequency Transducer
Low Frequency
Crossover Frequency
Frequency Response (–6dB)
Sensitivity (1 watt/1 meter)
Impedance
Recommended
Amplier Power*
Dimensions (HxWxD)
Weight
* Undistorted continuous power per channel.
Center
14mm titanium
5-1/4" (2)
2.7kHz
80Hz – 20kHz
87dB
8 ohms (nominal)
10 – 100 watts
7 x 20 x 6-1/2"
178 x 508 x 165mm
15 lbs/6.8 kg
