P/N: 2900-301015 Rev 2 www.kramerAV.com
USER MANUAL
MODELS:
TP-594Txr HDMI Line Transmitt er
TP-594Rxr HDMI Line Receiver
Kramer Electronics Ltd.
TP-594Txr Contents
i
Contents
Introduction 1
Getting Started 1
Overview 2
Typical Applications 4
Dening the Transmitter and Receiver 5
Dening TP-594Txr 5
Dening TP-594Rxr 6
Mounting TP-594Txr / TP-594Rxr 7
Connecting TP-594Txr / TP-594Rxr 8
Connecting Analog Audio Output to Balanced/Unbalanced Stereo Audio Acceptor 9
Connecting Balanced/Unbalanced Stereo Audio Source to Analog Audio Balanced Input 10
Connecting to TP-594Txr / TP-594Rxr via RS- 232 10
Wiring RJ-45 Connectors 11
Routing Audio Signals 12
Routing Audio Signals from TP-594Txr 12
Routing TP-594Rxr Audio Signals 17
Extending and Routing Control Signals 19
Extending Control Signals via HDBT 19
Extending HDMI CEC Commands via HDMI Connections 20
Routing -Driven Control Signals via Built-in Control Gateway IP 21
Operating and Controlling TP-594Txr and TP-594Rxr 22
Setting DIP-Switches 22
Operating via Ethernet 23
Using the Embedded Web Pages 25
Browsing Web Pages 25
Viewing General Information 28
Viewing Connected Clients 28
Changing Device Settings 29
Dening TP-594Txr Video and Audio Settings 33
Dening TP-594Rxr Video and Audio Settings 36
Managing EDID 38
Dening TP-594Rxr Gateway and Ports Activation 40
Dening TP-594Rxr Gateway Serial Port Settings 43
Setting Web Page Access Permission 44
Viewing About Page 46
Firmware Upgrade 47
Upgrading Firmware Using a Memory Stick 47
Technical Specications 48
Default Communication Parameters 50
Default EDID 51
Protocol 3000 53
Understanding Protocol 3000 53
Protocol 3000 Commands 54
Result and Error Codes 65
Kramer Electronics Ltd.
TP TP-594Txr, -594Rxr Introduction
1
Introduction
Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world
of unique, creative, and aordable solutions to the vast range of problems that confront the
video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we
have redesigned and upgraded most of our line, making the best even better!
Getting Started
We recommend that you:
Unpack the equipment carefully and save the original box and packaging materials for
possible future shipment.
Review the contents of this user manual.
Go to www.kramerav.com/downloads/TP-594Txr www.kramerav.com/downloads/TP- and
594Rxr to check for up- -date user manuals, application programs, and to check if to
rmware upgrades are available (where appropriate).
Achieving the Best Performance
Use only good quality connection cables (we recommend Kramer high-performance,
high-resolution cables) to avoid interference, deterioration in signal quality due to poor
matching, and elevated noise levels (often associated with low quality cables).
Do not secure the cables in tight bundles or roll the slack into tight coils.
Avoid interference from neighboring electrical appliances that may adversely inuence
signal quality.
Position your Kramer TP-594Txr / TP-594Rxr away from moisture, excessive sunlight
and dust.
Safety Instructions
Caution:
This equipment is to be used only inside a building. It may only be connected to other
equipment that is installed inside a building.
For products with relay terminals and GPI\O ports, please refer to the permitted rating
for an external connection, located next to the terminal or in the User Manual.
There are no operator serviceable parts inside the unit.
Warning:
Use only the power cord that is supplied with the unit.
To ensure continuous risk protection, replace fuses only according to the rating
specied on the product label which located on the bottom of the unit.
