IR Sensor (500999)
© MuxLab Inc. 2015 500999
MuxLab Inc. | 8495 Dalton Road, Mount Royal, Quebec, Canada, H4T 1V5
Tel: (514) 905 0588 | Fax: (514) 905 0589 | Toll Free:1 877 689- 5228
E-mail: | videoease@muxlab.com www.muxlab.com
Overview:
The IR Sensor (500999) works in conjunction with
MuxLab products to support IR source control
between the AV source and the AV display. The
500999 connects to an active balun transmitter.
The IR Emitter (500998) is the complementary
product that connects to the active balun
transceiver. The handheld remote control is not
included.
Key Features:
Suitable for IR data format: NEC code, RC5 code, RC6
code, Grunding code, RCA Code, Zenith code and Sony
12-bit code.
Carrier frequency: 38 kHz
Specications
Environment
Infra-red (IR) control
Devices
TV Sets, STB, DVD, DVR, PVR, satellite receivers.
Works with MuxLab P/Ns
500145, 500405, 500407, 500415 500416 500417, 500418, 500419, 500420, , ,
500450 500451 500453 500454, 500456, 500460, 500468, 500469, 500600 , , ,
Transmission
Transparent to the user
IR data format supported
NEC code, RC5 code, RC6 code, Grunding code, RCA Code, Zenith code and
Sony 12-bit code
Frequency
38 K Hz
IR Wavelength
940 nm
Receiving Distance
15 m
Connectors
3.5mm (stereo) plug
Temperature
Operating: 0° to 40°C Storage: -10° to 70°C
Humidity: up to 95% non-condensing
Enclosure
Dark purple epoxy resin
Dimensions
0.79 0.95 5 mm x mm x 13 mm) with 39 (1 m) cable ” x ” x 0. 1” (20 24
Weight
0.64 oz. (18 gms )
Compliance
RoHS
Warranty
2 years
Order Information
500999 - IR Sensor (UPC: 6276990099 ) 94
Typical Application:
