nuConnect ampX · Quick Start Guide · 08/2020 1
nuConnect ampX
Integrated Amplifier and Wireless Connector
QUICK START
GUIDE
®
!
1 Mounting the antennas
Place the nuConnect ampX on a at, stable surface. Ma
that there is some free space around the amplier to ensure proper
cooling.
To mount the antennas, Place the antennas over the antenna termi-
nals on the rear panel and turn the antennas clockwise until they are
rmly attached. Point the antennas upwards.
22 Cable connections
Make sure all cable connections between amplier, sources, loudspeakers and (optional) subwoofer are made
before switching the amplier on!
Sources, subwoofer Passive
loudspeakers
At the digital Port input,
you can plug in the
supplied HDMI/ARC
adapter, enabling
the direct connection
of a TV.
Be sure to enable the
CEC and ARC functions
on the TV and set
the audio output format
to PCM.
The nuConnect ampX is
connected to the power grid using
the supplied power-cable.
Move the power switch on the back
to the ON position to switch on the
amplier! If necessary, press the
power-button on the remote control
to “wake up” the amplier.
You can nd the most recent version of the
operating manual here: www.nubert.de/downloads/61/
All X-platform-based devices can exchange audio- and control-infor-
mation with each other.
(This functionality is only available when the nuConnect ampX is
used as an integrated amplier in combination with passive loud-
speakers. If you wish to connect a subwoofer, this must use a wired
connection too.)
The nuConnect must be set up as and connected to the wls slave
transmitting device. The amplier remains fully operable. Standby
power consumption is < 2,0 Watts.
➀
After switching on the nuConnect ampX, the display will show you
the set volume and input. This is the sub-menu, press volume
to
return to the main menu.
➁
Turn the
rotary encoder to get to the menu and press setup
the encoder to conrm.
➂
Turn the rotary encoder to get to the menu and wls slave
press the encoder to conrm. The display of the nuConnect ampX
will show for up to 60 seconds while trying to connect connecting
to a master device.
➃
Now congure the transmitting device, a nuPro X speaker or an-
other nuConnect for instance.Go to the menu of the transsetup -
mitting device, select and conrm your selection to wls master
begin the pairing process. Please refer to the manual of your specic
X-family device.
Once a connection is established, the displays on both devices will
briey show . An established connection will be permaconnected -
nently indicated on each device by the
symbol. The received
signal is available at the wireless (wls) input which can then be se-
lected like any other input.
2
2
nuConnect ampX · Quick Start Guide · 08/2020
3A
Wireless connections: The nuConnect as the receiving device
setup
wls slave
wls master
coax -30dB
coax -30dB
wls master ><
><
The nuConnect can also be used as a control hub, sending audio-
and control-signals to nuPro X loudspeakers and nuSub subwoofers
wirelessly. All audio sources must be connected to the nuConnect
ampX, which must then be set as . In this mode, standwls master -
by power consumption is < 2,0 watts. The wireless input is not avail-
able in this conguration.
Setting up nuPro X active speakers
Switch on the nuPros and set the correct channel for each loud-
speaker: Navigate to the submenu and set, for instance, channel
the left speaker to . You can now set the speaker as slave by left
navigating to the menu, selecting and conrming setup wls slave
your selection. The speaker will now search for a Master-device for
one minute.
Setting up the nuConnect ampX
Switch on your nuConnect ampX and set it as wls master by navigat-
ing to the menu and selecting , using the followsetup wls master -
ing steps: press the
back-key to return to the main menu and use
the
rotary encoder to get to the menu. Press the setup
rotary
encoder to enter the menu and go to , again using the wls master
rotary encoder. Conrm your selection by
pressing the rotary
encoder. The speaker will now search for a Slave-device for one min-
ute.
Connecting the nuConnect ampX
and nuSub-series subwoofers (optional)
Switch on the subwoofer. Press the SOURCE/PAIR button on the
back of the subwoofer for at least 3 seconds. The subwoofer will now
search for a Master-device for two minutes. On the nuConnect ampX,
restart the search for a slave device by following the steps above,
selecting in the menu.wls master setup
Note:
Combinations of the application-examples mentioned above are of
course possible.
You can mute the different speaker-systems independently of each
other. An example: to mute your main, passive loudspeakers, navi-
gate to and conrm by pressing zone ctrl. > local spk > mute
the rotary encoder. You can also adjust the level of wirelessly at-
tached systems relative to your main speakers. To do so, navigate to
zone ctrl > wireless > zone level > 0.0 dB.
3nuConnect ampX · Quick Start Guide · 08/2020
4 Source selection
Your nuConnect ampX is now congured and ready to use.
You can now select your preferred source – the
easiest way to do this is to use the remote control.
The remote control has 6 buttons for source selection. Pressing a key
repeatedly toggles between its two sources as shown below:
wls
analog
Wireless
Aux
Phono
coax
opto
Coaxial 1
Coaxial 2
Optical 1
Optical 2 usb
Bluetooth
USB
Digital Port
3B
Wireless connections: The nuConnect ampX as the transmitting device
