Sivu 1/2
1 Your All-in-One cooker
Congratulations on your purchase, and
welcome to Philips!
To fully benet from the support that Philips
oers, register your product at
www.Philips.com/welcome.
2 Important
Read this safety leaet carefully before you
use the electric pressure cooker and save it
for future reference.
Danger
• The appliance must not be
immersed.
Warning
• This appliance is intended
to be used in household and
similar applications such as:
• sta kitchen areas in shops,
oces and other working
environments;
• farm houses;
• by clients in hotels, motels
and other residential type
environments;
• This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
• Children should be supervised
to ensure that they do not
play with the appliance. The
children should not contact
with the appliance or power
cord. Do not let the power
cord hang over the edge of
the table or worktop on which
the appliance stands.
• If the supply cord is damaged,
it must be replaced by the
manufacturer, its service agent
or similarly qualied persons
in order to avoid a hazard.
• Make sure to avoid spillage on
the power connector to avoid
a potential hazard.
• Always follow the instructions
and use the appliance
properly to avoid potential
injury.
• Caution: Surface of the
heating element is subject to
residual heat after use.
• The appliance is not intended
to be operated by means of
an external timer or a separate
remote-control system.
• The ducts in the pressure
regulator allowing the escape
of steam should be checked
regularly to ensure that they
are not blocked.
• The container must not be
opened until the pressure has
decreased suciently.
• Do not spill on the power
connector to avoid a potential
hazard.
• Always follow the instructions
and use the appliance
properly to avoid potential
hazard.
• Only connect the appliance
to a grounded power outlet.
Always make sure that the
plug is inserted rmly into the
power outlet.
• Do not use the appliance if
the plug, the power cord, the
inner pot, the sealing ring, or
the main body is damaged.
• Make sure the heating
element and the outside of
the inner pot are clean and
dry before you put the plug in
the power outlet.
• Do not plug in the appliance
or turn the control knob with
wet hands.
• Do not use the appliance
if too much air or steam is
leaking from under the top lid.
• Caution
• Never use any accessories
or parts from other
manufacturers or that
Philips does not specically
recommend. If you use such
accessories or parts, your
guarantee becomes invalid.
• Do not expose the appliance
to high temperatures, nor
place it on a working or still
hot stove or cooker.
• Do not expose the appliance
to direct sunlight.
• Place the appliance on a
stable, horizontal, and level
surface.
• Always put the inner pot in
the appliance before you put
the plug in the power outlet
and switch it on.
• Do not place the inner pot
directly over an open re to
cook food.
• Do not use the inner pot if it is
deformed.
• Make sure that the sealing
ring is clean and in good
condition.
• The accessible surfaces
may become hot when the
appliance is operating. Take
extra caution when touching
the surfaces.
• Beware of hot steam coming
out of the oating valve and
pressure regulator valve
during cooking or when you
open the lid. Keep hands and
face away from the appliance
to avoid the steam.
• Do not lift and move the
appliance while it is operating.
• Do not exceed the maximum
water level indicated in the
inner pot to prevent overow.
• Do not place the cooking
utensils inside the pot while
cooking.
• Only use the cooking utensils
provided. Avoid using sharp
utensils.
• To avoid scratches, it is
not recommended to cook
ingredients with crustaceans
and shellsh. Remove the
hard shells before cooking.
• Do not place a magnetic
substance on the lid. Do not
use the appliance near a
magnetic substance.
• Always let the appliance cool
down to room temperature
before you clean or move it.
• Always clean the appliance
after use. Do not clean the
appliance in dishwasher
(accessories included).
• Always unplug the appliance
if not used for a longer period.
• If the appliance is used
improperly or for professional
or semi-professional
purposes, or if it is not used
according to the instructions
in this safety leaet, the
guarantee becomes invalid
and Philips refuses liability for
any damage caused.
• Visit www.philips.com/support
to download the user manual.
Electromagnetic fields (EMF)
This Philips appliance complies with all
applicable standards and regulations
regarding exposure to electromagnetic elds.
3 What’s in the box (fig. 1)
All-in-One cooker main unit
Rice spoon Soup ladle
Measuring cup User manual
Power cord Recipe
Overview (fig. 2)
aDetachable top
lid fHeating element
bSealing ring gPressure
regulator
cInner pot hLid handle
dWater level
indication iLid release
button
eControl panel jPower socket
Controls overview (fig. 3)
kDisplay screen q分 button
l保溫 /取消 button r預約時間 button
mFunction selection
button s米飯 button
n再加熱 button t無水烹調 button
o保壓時間 button u開始烹調 button
p時 button
4 Use your All-in-One cooker
Before first use
1 Remove all packaging materials from
the appliance.
2 Take out all the accessories from the
inner pot.
3 Clean the parts of the electric pressure
cooker thoroughly before using it for
the rst time (see chapter ‘Cleaning’).
Note
•Make sure all parts are completely
dry before you start using the electric
pressure cooker.
Preparations before cooking
Before using the electric pressure cooker
to cook food, you need to follow below
preparations:
Us
a
f
g
h
i
j
bl
k
m
n
o
c
d
e
1 32
www.philip s.com/welcome
User manual
www.philip s.com/welcome
Recipe book
HD2137 4 5
986 7
18 19
17
3s
1612 13
2120 22 23
14 15
10 11
pq
r
s
t
u
HD2171
©2018 Koninklijke Philips N.V.
All rights reserved.
HD2171_UM_TW_EN_v2.0
1 Hold the lid handle and turn it anti-
clockwise until the top lid cannot move
any more (g. 4).
2 Lift up the top lid (g. 5).
3 Take out the inner pot from the electric
pressure cooker (g. 6).
4 Put the pre-washed food in the inner
pot. Wipe the outside of the inner
pot dry (g. 7) and put it back into the
electric pressure cooker (g. 8).
Note
•
Do not ll the inner pot with less than 1/3
or more than 2/3 full of food and liquid.
•For food that expands during cooking,
do not ll the inner pot with more than
1/2 full of food and liquid.
•For rice cooking, follow the water level
indications on the inside of the inner
pot. You can adjust the water level
for dierent types of rice and your
own preference. Do not exceed the
maximum water level indication.
5 Place the top lid onto the electric
pressure cooker and turn it clockwise
(g. 9).
Note
•Make sure the sealing ring is properly
assembled around the inside of the top
lid.
•Make sure the pressure regulator and
oating valve are clean and not blocked.
•Make sure the outside of the inner pot
is dry and clean, and that there is no
foreign residue on the heating element.
•Make sure the inner pot is in proper
contact with the heating element.
Pressure cooking
1 Follow the steps in “Preparations before
cooking”.
2 Turn the pressure regulator to ' 密封 '
position (g. 10).
3 Put the plug in the power socket (g.11).
4 Press the button to choose a function
you need.
•If you want to cook rice, press 米飯
button (g. 12).
» The rice indicator blinks.
» The screen displys the preset
cooking time and the pressure.
•If you want to choose the other
cooking functons ( 煮粥 /煲湯 , 雞肉
/鴨肉 , 牛肉 /羊肉 , 豬肉 /排骨 , 豆
類/蹄筋 , 蒸蛋 ), press the button
repeatedly until (g. 13).
» The indicator of the selected
function blinks.
» The screen displys the preset
pressure keeping time and the
pressure.
5 To set a dierent pressure keeping time,
press (g. 14).
» The pressure keeping time blinks.
6 Press the minute button ( ) to set the
time (g. 15).
Note
•Press the minute button to adjust the
time by one minute, press and hold the
minute button to fastward the time.
7 Press and hold 開始烹調 button ( ) for
3 seconds, the All-in-One cooker starts
working in the selected mode (g. 16).
8 When the All-in-One cooker reaches
the cooking pressure, it goes to dynamic
pressure keeping state.
9 After cooking is nished, the All-in-One
cooker automatically switches to keep
warm mode.
10 After the pressure is released
completely, turn the pressure regulator
to 排氣 position (g. 17). Hold the handle
of the top lid and turn it anticlockwise
until it cannot move (g. 4), and then
open the lid (g. 5).
Tips
•Do not turn the pressure regulator
during cooking process.
•Normally, you can open the lid after
cooking is nished. If you can't open
the lid, turn the pressure regulator to
vent position, let the steam release
completely.
•You can adjust the cooking time for
dierent types of food according to your
preference. It's not suggested to set the
cooking time shorter than preset time,
this may cause that the foods are still
raw.
•Press the 保溫 /取消 button to cancel
the cooking process. If you want to
open the lid, turn the pressure regulator
to 排氣 position.
Note
•When cooking soup or viscous liquid,
do not release pressure by turning the
pressure regulator to the steam vent
position, otherwise liquid might spurt
from the pressure control valve. Wait
until the pressure is naturally released
and the oater has dropped to open
the top lid.
•After the cooking is nished and the
pressure is released, unplug the electric
pressure cooker to turn o the keep
warm function or when not in use.
Waterless cooking
You can cook foods without adding water in
the inner pot.
1 Follow the steps in “Preparations before
cooking”.
2 Turn the pressure regulator to '無水烹調 '
position (g. 18).
3 Put the plug in the power socket
(g. 11).
4 Press the 無水烹調 button ( ) (g. 19).
» The display shows the preset
cooking time for waterless cooking.
5 To set a dierent cooking time, press
(g. 14).
» The pressure keeping time blinks.
6 Press the 分 button ( ) to set the time
(g. 15).
Tip
•You can adjust the cooking time for
dierent types of food according to your
preference. It's not suggested to set the
cooking time shorter than preset time,
this may cause that the foods are still
raw.
7 Press and hold 開始烹調 button ( ) for
3 seconds, the All-in-One cooker starts
working in the selected mode (g. 16).
8 When the All-in-One cooker reaches
the cooking pressure, the pressure
keeping time starts countdown.
9 After cooking is nished, the All-in-One
cooker automatically switches to keep
warm mode.
10 Turn the handle of the top lid
anticlockwise (g. 4) to open the lid
(g.5).
蒸蛋
1 Follow the steps 1-3 in ‘Preparations
before cooking’ .
2 Pour 2-3 scale water, put the steam
basket into the inner pot.
3 Put the ingredients of 蒸蛋 in the steam
basket.
4 Turn the pressure regulator to " 排氣 "
position (g. 17).
5 Put the plug in the power socket
(g. 11).
6 Press the button to choose the 蒸蛋
fucntion (g. 13).
7 Press and hold 開始烹調 button ( ) for
3 seconds, the All-in-One cooker starts
working in the selected mode (g. 16).
8 After cooking is nished, the All-in-One
cooker automatically switches to keep
warm mode.
9 Turn the handle of the top lid
anticlockwise (g. 4) to open the lid
(g.5).
再加熱
1 Loosen the cooled rice and evenly
distribute it in the inner pot.
2 Pour some water onto the rice to
prevent it from becoming too dry. The
quantity of the water depends on the
amount of rice.
3 Close the top lid, and turn the handle
anticlockwise to the lock position (g. 9).
4 Turn the pressure regulator to the 排氣
position (g. 17).
5 Put the plug in the power socket (g. 11).
6 Press the 再加熱 button ( ) to choose
the 再加熱 funtion (g. 20).
» The reheat indicator blinks.
7 To set a dierent cooking time, press
the 保壓時間 ( ) button (g. 14).
» The 保壓時間 for reheat blinks on the
screen.
8 Press the 分 ( ) button to set time
(g. 15).
9 Press the 開始烹調 ( ) button for 3
seconds, the All-in-One cooker starts
working in the selected mode (g. 16).
» The reheat indicator lights up.
» The reheat time starts to count
down.
10 When the cooking is nished, the All-
in-One cooker will be in keep warm
mode automatically.
11 Hold the handle of the top lid, and turn
it anticlockwise (g. 4) and open the top
lid (g. 5).
Preset time for delayed cooking
You can preset the delayed cooking time
for dierent cooking functions. The preset
timer is available up to 24 hours, but is not
applicable to the cake function.
1 Press , , or to choose the
desired cooking mode, then press the
preset timer button ( ) (g 21).
2 Press 時 button ( )to set hour, and
then press 分 button ( )to set minute
(g. 22).
Note
•Press 時 button to adjust the time by
one hour, press 分 button to adjust the
time by 10 minutes. Press and hold 時
or 分 to fast forward or fast backward
time.
3 Once the preset time is set, press the
開始烹調 button ( ) for 3 seconds to
enter preset mode (g.16).
» The remaining preset time is
displayed on the screen.
4 When the preset time is elapsed, the
All-in-One cooker starts working in the
selected cooking mode automatically.
Setting up child lock
To protect your child from using the
multicooker, you can set up the child lock
function.
• Press and hold the 預約時間
button( ) for 3 seconds to enter
the child lock mode.
» The child lock icon appears on the
display screen.
• To unlock, press and hold the 預
約時間 button ( ) for 3 seconds
again.
» The child lock icon disappears from
the display screen.
Keep warm mode
In standby mode, press the 保溫 /取消 ( )
button, the All-in-One cooker goes to keep
warm mode automatically. The screen shows
the keep warm time. When the All-in-One
cooker stays in keep warm mode for more
than 12 hours, it will switch to standby mode.
Note
•The All-in-One cooker can remain in
keep warm mode when you open or
close the lid.
Cooking time regulating range
Cooking
function
Cooking
time
(minute)
Default
pressure
keeping time
(minute)
Default
pressure
米飯 30 25-35 20kpa
煮粥/煲湯 40 35-59 40kpa
雞肉/鴨肉 35 30-59 30kpa
牛肉/羊肉 50 45-59 50kpa
豬肉/排骨 35 30-59 50kpa
豆類/蹄筋 50 45-59 60kpa
Cooking
function
Cooking
time
(minute)
Default
pressure
keeping time
(minute)
Default
pressure
無水烹調 15 1-59 /
再加熱 25 20-59 /
蒸蛋 20 15-59 /
5 Specifications
Model Number HD2171
Rated power
output 900W
Rated capacity 5.0L
Diamter 22cm
Temperature of
keeping warm 60-80°C
Dimension 371mmx277mmx298mm
Net. weight 6.7kg
Note
•Always unplug the appliance if not used
for a longer period.
6 Cleaning and Maintenance
Note
•Unplug the electric pressure cooker
before starting to clean it.
•Wait until the electric pressure cooker
has cooled down suciently before
cleaning it.
Interior
Inside of the outer lid and the main body:
• Wipe with wrung out and damp cloth.
• Make sure to remove all the food
residues stuck to the electric pressure
cooker.
Heating element:
• Wipe with wrung out and damp cloth.
• Remove food residues with wrung out
and damp cloth or toothpicks.
Sealing ring:
• Soak in warm water and clean with
sponge.
Exterior
Surface of the outer lid and outside of the
main body:
• Wipe with a cloth damped with soap
water.
• Only use soft and dry cloth to wipe the
control panel.
• Make sure to remove all the food
residues around the pressure regulator
and oating valve.
Pressure control valve and oating valve:
• Disassemble the pressure control valve,
soak it in warm water, and clean with
sponge (Fig. 23).
• Remove food residues in the pressure
control valve and oating valve with
toothpicks. When cleaning the oater,
remove the inner lid rst.
Accessories
Detachable inner lid, soup ladle, rice scoop
and inner pot.
• Soak in hot water and clean with
sponge.
7 Recycling
Do not throw away the product with the
normal household waste at the end of its
life, but hand it in at an ocial collection
point for recycling. By doing this, you help
to preserve the environment.
Follow your country’s rules for the separate
collection of electrical and electronic
products. Correct disposal helps prevent
negative consequences for the environment
and human health.
8 Guarantee and service
If you need service or information, or if you
have a problem, visit the Philips website
at www.philips.com or contact the Philips
Customer Care Center in your country. You
can nd its phone number in the worldwide
guarantee leaet. If there is no Customer
Care Center in your country, go to your local
Philips dealer.
9 Troubleshooting
If you encounter problems when using this
appliance, check the following points before
requesting service. If you cannot solve the
problem, contact the Philips Consumer Care
Center in your country.
Problem Solution
I have
diculties
closing the
top lid.
The inner lid is not well
assembled. Make sure the
inner lid is well assembled
around the inside of the
top lid.
The handle is in " 鎖緊 "
position. Turn it counter
clockwise to " 開蓋 "
position.
I have
diculties
opening the
top lid after
the pressure
is released.
Make sure the handle is
in " 開蓋 " position.
The food is
not cooked.
Make sure that there is
no foreign residue on the
heating element and the
outside of the inner pot
before switching the All-
in-One cooker on.
The heating element is
damaged, or the inner
pot is deformed. Take
the cooker to your Philips
dealer or a service center
authorized by Philips.
Air or steam
leaks from
under the
lid.
The inner lid is not well
assembled. Make sure the
inner lid is well assembled
around the inside of the
top lid.
There is food residue in
the sealing ring. Make sure
the sealing ring is clean.
The top lid is not properly
closed. Make sure the top
lid is properly closed.
The pressure regulator is
not well asseambled.
Air or steam
leaks from
the steam
valve.
There is food residue in
the rubber ring of the
steam valve. Clean the
rubber ring of the oater.
The rubber ring of the
oating valve is broken.
Replace the rubber ring.
The oater
is not raised
after ( the
air is leaked
from the
pressure
regulator.)
Make sure the amount of
water and the ingredients
is enough.
The top lid or the pressure
regulator has malfunction.
Take the appliance to a
Philips dealer or a service
center authorised by
Philips.
E0 displays
on the
screen.
The top lid is not closed
well. Make sure the top
lid is closed well and the
handle is locked.
E2 displays
on the
screen.
No inner pot is detected.
Put the inner pot into
the All-in-One cooker, or
check if the inner pot is
not properly connected
with the heating element.
E3 displays
on the
screen.
The temperature of the
inner pot is too high. Wait
until it drops to room
temperature.
E1, E4, E5, or
E6 displays
on the
screen.
The All-in-One cooker
has malfunction. Take
the appliance to a Philips
dealer or a service center
authorised by Philips.
Tuotetiedot
| Merkki: | Philips |
| Kategoria: | Panoroida |
| Malli: | HD2171 |
Tarvitsetko apua?
Jos tarvitset apua merkille Philips HD2171 esitä kysymys alla ja muut käyttäjät vastaavat sinulle
Panoroida Philips Käyttöohjeet
26 Lokakuuta 2024
26 Lokakuuta 2024
26 Lokakuuta 2024
26 Lokakuuta 2024
Panoroida Käyttöohjeet
- Panoroida IKEA
- Panoroida Imarflex
- Panoroida Khind
- Panoroida Taurus
- Panoroida Turbotronic
- Panoroida Brentwood
- Panoroida HomeCraft
- Panoroida Mellerware
- Panoroida Tefal
Viimeisimmät Panoroida Käyttöohjeet
27 Lokakuuta 2024
27 Lokakuuta 2024
27 Lokakuuta 2024
20 Lokakuuta 2024
20 Lokakuuta 2024
20 Lokakuuta 2024
20 Lokakuuta 2024
20 Lokakuuta 2024
20 Lokakuuta 2024
20 Lokakuuta 2024
