Sivu 1/11
Model/Modelo:PFR51400X
PFR71400X
CONGELADOR HORIZONTAL
CHEST FREEZER
Transportation and Placement
△When transporting the chest freezer from one place to another, the
inclination of the cabinet should not exceed 45 degrees to prevent against
compressor or system damage.
△Before use, remove all the packing material. The back side of the cabinet
should be more than 20cm away from the wall, both flank sides more than
20cm.
△The freezer should be put in a well-ventilated, dry place. Do not place it
under direct sunshine. The freezer should be kept away from the water sink,
heat sources and any volatile or corrosive material.
Power source and test-running
△Specified capacity of the wire is 7A. Section squares of the wire is 0.82mm2.
Single line or compound lines are all allowed. A fuse of 2.5A specified
electric current should be installed. (Power cord should be replaced with the
same of 7A and 0.82mm2 if it is damaged).
△Single-phase power supply, 60Hz, voltage range 98~132V. If the voltage is
unstable, please install a voltage stabilizer with capacity above 1000W.
△Avoid turning the power on and off too frequently. If the power is turned off,
wait an interval of 5 minutes before turning it on again.
△When the freezer is going to be out of use for a long time, disconnect the
power first, remove all its contents and then clean it. Please examine the
circuit whether it is in perfect conditions before reuse.
Operation of the Temperature Control Knob
△The temperature inside the cabinet can be controlled with the temperature
control knob.
△The knob should be kept upright normally to adjust the temperature. 7 is < =
the coldest freezing setting and is suitable for fast freezing. Do not keep the
knob at this point for long.
△ 1 : temperature inside the freezer cabinet is around -10 < = ℃
△ 2< =: temperature inside the freezer cabinet is around -12 ℃
△ 3< =: temperature inside the freezer cabinet is around -15 ℃
△ < =: temperature4 inside the freezer cabinet is around -18 Factory setting℃ÿ Ā
△ 5< =: temperature inside the freezer cabinet is around -20 ℃
△ 6< =: temperature inside the freezer cabinet is around -22 ℃
△ 7 : temperature inside the freezer cabinet is around -25< = ℃
Food storage
△Allow space between the foods stored in the cabinet, and between the foods
and the inner surface of the cabinet to keep good ventilation of cold air and
1
freeze evenly. Do not put in any bottled or canned beverages with freezing
points above the temperature in the cabinet when it is below zero.
△For foods that should be moisture-free or lose water easily, wrap them up in
airtight food bags or containers before putting in the cabinet to avoid
smell-mixing and reduce frosting.
△Storage of volatile and combustible gases, liquids such as strong alkalis,
strong acids, petrol, etc. is not allowed.
Maintenance
△The freezer should be cleaned regularly. When cleaning, turn off the power,
take out all the food from the cabinet, and clean the inside using water or a
little neutral detergent.
△Do not use boiling water, acid, chemical diluents, petrol, oil, or dirt- removing
powder.
△Dry it after cleaning.
△Use light soap water when cleaning the door seal and apply a little of talcum
powder on it after natural drying to extend its service life.
△Use a soft cloth with water or a little detergent to clean the exterior surface.
Note: Keep the power supply and connecting wires away from water to
avoid electric shock.
△Those who are not a service technician should not take apart and repair the
freezer on their own to avoid additional trouble. Unauthorized repairs of
electrical parts as compressor, temperature controller is forbidden.
Defrosting
△For better freezing efficiency, defrost when the frost film inside the cabinet is
4-5mm thick.
△When defrosting, turn off the power, take out the frozen foods, open the door
for warming and melting. Use a soft cloth to absorb water and clean it up.
△Do not use sharp metal tools as steel brushes to clean the frost film when
defrosting to avoid evaporator damage.
Trouble shooting
Failure
Cause
Removal method
The indicator is not on.
The compressor does
not start.
The plug is not really
connected to the socket.
Replug it.
No power
Connect to a socket
with power.
