Sivu 1/8
1
ENQuick Guide
PROGRAMS TABLE
Program Programs description
Drying
phase
Auto Door
Available
options *)
Duration
ofwash
program
(h:min)**)
Water
con-
sumption
(litres/cycle)
Energy
con-
sumption
(kWh/cycle)
1.
Eco 50°- Eco program is suitable to clean normally soiled tableware, that
for this use, it is the most ecient program in terms of its combined energy
and water consumption, and that it is used to assess compliance with the EU
Ecodesign legislation.
3:35 8.7 0.59
2. Auto Intensive 65° - Automatic program for heavily soiled dishes and pans
(not to be used for delicate items). 2:00 - 3:10 14.0 - 17.0 1.50 - 1.85
3.
Auto Mixed - 55° Automatic program for normally soiled pans and dishes.
1:20 - 3:00 7.0 - 14.0 0.70 - 1.10
4. Half Load 55°- Ideal for washing a half load of lightly or normally soiled crockery. 1:20 11.0 1.00
5. Rapid 30’ 45° - Program to be used for half load of lightly-soiled dishes with
no dried food residues. Without drying. - 0:30 9.0 0.50
6.
Extra Hygiene 65° - Normally or heavily soiled crockery, with additional antibac-
terial wash. Can be used to perform maintenance of the dishwasher.
- 1:50 12.0 1.30
7.
Extra - 50° Program that allows to wash very big items loaded in the lower
rack. Please apply detergent directly to tub instead of detergent dispenser.
Upper rack should be removed with this cycle. -- 1:30 11.0 1.20
8. Prewash - Use to refresh crockery planned to be washed later. Nodetergent
to be used with this program. -- 0:10 4.5 0.01
9.
Push&GO 50° - Everyday wash and dry cycle that ensures great cleaning per-
formance in a short time without the need to pre-treat dishes.
1:25 11.5 1.10
1. On-O/Reset button with indicator
light
2. Program selection button
3. Salt rell indicator light
4. Rinse Aid rell indicator light
5. Program number and delay time
indicator
6. Tablet (Tab) indicator light
7. Display
8. Push & Go button
9. Delay button
10. Start/Pause button with
indicator light/ Tablet (Tab)
FILLING THE SALT RESERVOIR
The use of salt prevents the formation of LIMESCALE on the dishes and on
the machine’s functional components.
• It is mandatory that the salt reservoir never be empty.
• It is important to set the water hardness.
The salt reservoir is located in the lower part of the dishwasher and must be
lled when the SALT REFILL indicator light in the control panel is lit.
1. Remove the lower rack and unscrew the reservoir cap
(anticlockwise).
2. Position the funnel and ll the salt reservoir (see gure)
right up to its edge (approximately 1 kg); it is not unu-
sual for a little water to leak out.
3. Only the rst time you do this: ll the salt reservoir
with water.
4. Remove the funnel and wipe any salt residue away from the opening.
Make sure the cap is screwed on tightly, so that no detergent can get into the
container during the wash program (this could damage the water softener be-
yond repair). Whenever you need to add salt, it is mandatory to complete the
procedure before the beginning of the washing cycle to avoid corrosion.
WATER SOFTENING SYSTEM
Water softener automatically reduces water hardness, consequently pre-
venting scale buildup on heater, contributing also to better cleaning e-
ciency. This system regenerates itself with salt, therefore it is required
to rell salt container when empty.
A
C
D
Frequency of regeneration depends on water hardness level setting - regen-
eration takes place once per 6 Eco cycles with water hardness level set to 3.
Regeneration process starts in nal rinse and nishes in drying phase, be-
fore cycle ends.
• Single regeneration consumes: ~3.5L of water;
• Takes up to 5 additional minutes for the cycle;
• Consumes below 0.005kWh of energy.
FILLING THE RINSE AID DISPENSER
Rinse aid makes dish DRYING easier. The rinse
aid dispenser should be lled when the A RINSE
AID REFILL indicator light in the control pan-
el is lit. NEVER pour the rinse aid directly into the
appliance tub.
FILLING THE DETERGENT DISPENSER
To open the detergent dispenser use the opening device . Introduce the C
detergent into the dry dispenser only. Place the amount of detergent for D
pre-washing directly inside the tub.
If all-in-one detergents are used, we recommend using the TABLET button,
because it adjusts the program so that the best washing and drying results
are always achieved.
Usage of detergent not designed for dishwashers may cause malfunc-
tion or damage to the appliance.
1 2 3 4 5 6 7 8 9 10
ECO program data is measured under laboratory conditions according to European Standard EN 60436:2020.
Note for Test Laboratories: For information on
comparative EN testing conditions, please send an email to the following address:
dw_test_support@europeanappliances.com
Pre-treatment of the dishes is not needed before any of the programs.
*) Not all options can be used simultaneously.
**) Values given for programs other than the program Eco are indicative only. The actual time may vary depending on many factors such as temperature and
pressure of the incoming water, room temperature, amount of detergent, quantity and type of load, load balancing, additional selected options and sensor cali-
bration. The sensor calibration can increase program duration up to 20 min.
PLEASE SCAN THE
QR CODE ON YOUR
APPLIANCE IN
ORDER TO HAVE
MORE DETAILED
INFORMATION
Before using the appliance carefully read Safety and Installation Instructions.
After installation, please remember to remove all transport protection parts from
the dishwasher.
CONTROL PANEL
FIRST TIME USE More information in the Daily Reference Guide on website.
2
Quick GuideEN
PUSH&GO - Push&GO button is an easily distinguishable button that
allows you direct access to the Push&GO program, a wash and dry
cycle that ensures great cleaning performance in a short time. You don’t have
to worry which program to choose, Push&GO cycle will do the work for you.
OPTIONS AND FUNCTIONS
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected
program (see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
Please scan on your product in order to have more detailed information. the QR code
DELAY -The start of the program may be delayed for a period of time
between and hours. 1 12
The DELAY function cannot be set once a wash cycle has been started.
TABLET (Tab)- If you use powder or liquid detergent, this option
should be o.
OPERATION INDICATOR - A LED light projected on the oor indicates
that the dishwasher is working. One of the following operating modes
can be selected:
a) Disabled function.
b) When the cycle starts the light goes on for few seconds, stays o during
the cycle and ashes at the end of the cycle.
c) The light stays on during the cycle and ashes at the end of the cycle
(default mode).
Auto Door is a convection drying system which automatically opens
the door during/after drying phase to ensure exceptional drying
performance every day. Door opens at the temperature that is safe to
your kitchen furniture.
LOADING THE RACKS CAPACITY: 10 standard place-settings
CLEANING AND MAINTENANCE More information in the Daily Reference Guide on website.
UPPER RACK
Load delicate and li-
ght dishes: glasses,
cups, saucers, low sa-
lad bowls.
(loading example for
the upper rack)
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
LOWER RACK
For pots, lids, plates, salad
bowls, cutlery etc. Large
plates and lids should ide-
ally be placed at the sides
to avoid interferences
with the spray arm.
The lower rack has tip-up
supports which can be
used in a vertical position
when arranging plates or
(loading example
for the lower rack)
in a horizontal position
(lower) to load pans and
salad bowls easily.
CUTLERY BASKET
The basket is equipped
with top grilles for im-
proved cutlery arrange-
ment. The cutlery basket
should be positioned only
at the front of the lower
rack.
Knives and other uten-
sils with sharp edges must be placed in
the cutlery basket with the points facing
downwards or they must be positioned
horizontally in the tip-up compartments
on the upper rack.
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
AA
B
C
1 2 3 4
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds
etc.) please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in
aclockwise direction.
The lower spray arm may be
removed by pulling it upwards.
EXTRA - makes it possible to carry out a heavy-duty wash cycle of
large crockery up to a max height of 53cm. baking pans, oven grids,
dripping pans, hob grids, large saucepans, serving dishes, pizza dishes,
stainless-steel hood lters. Remove the upper rack to load bulky crockery.
Release the two locks (right and left) and pull out the rack.
When the upper rack is tted, the locks must be always
closed.
In order for the water to reach the crockery everywhere,
arrange it as shown in the Figure.
Do not start the dishwasher without the upper rack
using wash cycles other than EXTRA.
To carry out the wash cycle Extra pour the detergent
DIRECTLY INTO THE TUB and not into the dispenser.
3
ENQuick Guide
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher does not
ll the water.
Display shows: H,
6 and On/O LED is
blinking rapidly
No water in the water supply or the tap is closed. Make sure there is water in the water supply or the tap running.
The inlet hose is bent. Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher and
reboot.
The sieve in the water inlet hose is clogged; it is
necessary to clean it
After having carried out the verication and cleaning, turn o and turn on the dishwasher
and restart a new program.
Dishwasher nishes the
cycle prematurely.
Display shows: 15
and On/
O LED is blinking
rapidly
Drain hose positioned too low or siphoning into
home sewage system.
Check if end of drain hose is placed at correct height (see INSTALLATION).Check for sipho-
ning into home sewage system, install air admittance valve if necessary.
Air in water supply. Check water supply for leaks or other issues letting air inside.
Detergent leaks.
Depends on the liquid detergent used and
can be emphasized in case of delay option is
activated.
Small leaks will not cause machine malfunction and can be avoided by changing liquid
detergent type or using tablets.
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues
please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period
of either up to 7 or up to 10 years, according to the specic Regulation requirements.
TROUBLESHOOTING
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website and docs.privileg.eu parts-selfservice.europeanappliances.com
• Alternatively, (See phone number in the warranty booklet). When contacting our After-sales contact our After-sales Service
Service, please state the codes provided on your product‘s identication plate.
The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model
identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
IEC 436
:
Please scan on your product in order to have more detailed information. the QR code
Tuotetiedot
| Merkki: | Privileg |
| Kategoria: | Astianpesukone |
| Malli: | PV2IC10BS7LA0 |
Tarvitsetko apua?
Jos tarvitset apua merkille Privileg PV2IC10BS7LA0 esitä kysymys alla ja muut käyttäjät vastaavat sinulle
Astianpesukone Privileg Käyttöohjeet
14 Tammikuuta 2025
14 Tammikuuta 2025
14 Tammikuuta 2025
14 Tammikuuta 2025
14 Tammikuuta 2025
14 Tammikuuta 2025
14 Tammikuuta 2025
27 Joulukuuta 2024
13 Joulukuuta 2024
Astianpesukone Käyttöohjeet
- Astianpesukone Teka
- Astianpesukone Maytag
- Astianpesukone Miele
- Astianpesukone Whirlpool
- Astianpesukone Haier
- Astianpesukone KitchenAid
- Astianpesukone Pelgrim
- Astianpesukone Royal Catering
- Astianpesukone LG
- Astianpesukone Bosch
- Astianpesukone Jocel
- Astianpesukone BEKO
- Astianpesukone Exquisit
- Astianpesukone Grundig
- Astianpesukone Hisense
- Astianpesukone Sharp
- Astianpesukone Electrolux
- Astianpesukone Café
- Astianpesukone Balay
- Astianpesukone Siemens
- Astianpesukone Koldfront
- Astianpesukone Arcelik
- Astianpesukone Smeg
- Astianpesukone Hoover
- Astianpesukone Saba
- Astianpesukone Hotpoint
- Astianpesukone Nabo
- Astianpesukone Amica
- Astianpesukone IKEA
- Astianpesukone Ignis
- Astianpesukone AEG
- Astianpesukone Rosieres
- Astianpesukone Artusi
- Astianpesukone Cecotec
- Astianpesukone Samsung
- Astianpesukone Neff
- Astianpesukone Comfee
- Astianpesukone Imarflex
- Astianpesukone Bomann
- Astianpesukone Edgestar
- Astianpesukone Kogan
- Astianpesukone Caple
- Astianpesukone Midea
- Astianpesukone Franke
- Astianpesukone Sauber
- Astianpesukone Candy
- Astianpesukone CDA
- Astianpesukone Kuppersbusch
- Astianpesukone Gorenje
- Astianpesukone Summit
- Astianpesukone Brandt
- Astianpesukone Gram
- Astianpesukone Master Kitchen
- Astianpesukone Monogram
- Astianpesukone Vox
- Astianpesukone Westinghouse
- Astianpesukone Medion
- Astianpesukone Kluge
- Astianpesukone MPM
- Astianpesukone Cosmo
- Astianpesukone Euro Appliances
- Astianpesukone Bauknecht
- Astianpesukone Defy
- Astianpesukone Euromaid
- Astianpesukone GE
- Astianpesukone Omega
- Astianpesukone Fisher Paykel
- Astianpesukone Fulgor Milano
- Astianpesukone Hyundai
- Astianpesukone Infiniton
- Astianpesukone Indesit
- Astianpesukone Asko
- Astianpesukone Blaupunkt
- Astianpesukone Cylinda
- Astianpesukone AYA
- Astianpesukone Fisher And Paykel
- Astianpesukone Elba
- Astianpesukone Philco
- Astianpesukone Jenn-Air
- Astianpesukone Wisberg
- Astianpesukone Klarstein
- Astianpesukone ATAG
- Astianpesukone Signature
- Astianpesukone Freggia
- Astianpesukone V-Zug
- Astianpesukone Black And Decker
- Astianpesukone Sauter
- Astianpesukone Kucht
- Astianpesukone Technika
- Astianpesukone Hansa
- Astianpesukone Thor
- Astianpesukone Kenmore
- Astianpesukone Meireles
- Astianpesukone Fagor
- Astianpesukone Edesa
- Astianpesukone IFB
- Astianpesukone Profilo
- Astianpesukone Gaggenau
- Astianpesukone Constructa
- Astianpesukone KKT Kolbe
- Astianpesukone Tisira
- Astianpesukone Porter & Charles
- Astianpesukone Zerowatt
- Astianpesukone Baumatic
- Astianpesukone Iberna
- Astianpesukone Silvercrest
- Astianpesukone Otsein
- Astianpesukone Corberó
- Astianpesukone Pitsos
- Astianpesukone Daewoo
- Astianpesukone La Germania
- Astianpesukone Emilia
- Astianpesukone Emerio
- Astianpesukone Barazza
- Astianpesukone Thermador
- Astianpesukone Zanussi
- Astianpesukone Hanseatic
- Astianpesukone Proline
- Astianpesukone Junker
- Astianpesukone Blomberg
- Astianpesukone Black Decker
- Astianpesukone Bellini
- Astianpesukone Continental Edison
- Astianpesukone Pando
- Astianpesukone Equator
- Astianpesukone SEIKI
- Astianpesukone Oranier
- Astianpesukone Upo
- Astianpesukone Sammic
- Astianpesukone Hoonved
- Astianpesukone De Dietrich
- Astianpesukone JennAir
- Astianpesukone Esatto
- Astianpesukone Helkama
- Astianpesukone Robinhood
- Astianpesukone Rex
- Astianpesukone Prima
- Astianpesukone Bompani
- Astianpesukone Cove
Viimeisimmät Astianpesukone Käyttöohjeet
9 Huhtikuuta 2025
9 Huhtikuuta 2025
9 Huhtikuuta 2025
8 Huhtikuuta 2025
8 Huhtikuuta 2025
8 Huhtikuuta 2025
7 Huhtikuuta 2025
7 Huhtikuuta 2025
7 Huhtikuuta 2025
7 Huhtikuuta 2025
