What s In The Box
Please inspect the contents of your shipped package to ensure you have received everything that is listed
below.
Smart Lock Boom Drawer for Soundchief Cart -
Workstaon (CT SDCF SD)- -
A s s e m b l y M a n u a l
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo-copying, recording, or otherwise, except as may be expressly permied by the applicable copyright
statutes or in wring by the Publisher.
Proaim Smart Lock Drawer for Soundchief Cart -
1 x L type Allen key -(5/16”)
1 x Wrench (17)
2
Properly detach the upper and lower secon
of the Soundchief Cart (Not Included).
Remove the bolts on the boom wheel
bracket of the Soundchief cart (Not Included)
with the help of an Allen key.
Smart Lock Boom Drawer- Setup
Push the pin up slightly to properly detach the
side panels and remove it properly from the
Smart Lock drawer.-
Follow the same process for removing the
side panel of another side.
Using a wrench, unscrew the bolt on the
inner bar of the Soundchief cart
(Not Included) so that the upper and lower
secons can be separated.
Place the side panel in the center of the upper
or lower secon of the cart , (Not Included)
and then insert the bolt by matching the hole.
Side Panel Detachment from Proaim Smart Lock Drawer -
Push Pin
3
Insert the Allen bolt matching the thread
holes of the cart and side panels.
Insert the Smart Lock drawer manually by -
sliding it into the side panel, as shown in the
image.
NOTE: The soft closing side panel prevents the -
colliding & crashing of gears that is inside the
drawer.
NOTE: Proaim Smart Lock Drawer is a deep & -
fully enclosed drawer that takes in all suitable
audio/video producon accessories & facilitates
convenient access to them along with protec-
on.
Secure the side panel to the lower secon of
the cart using washers and ghten it with the
help of a wrench.
Re-insert the bolts into the wheel bracket
aer aaching the side panel to the
Soundchief cart and securely
(Not Included)
ghten the bolts with the help of an Allen
key.
Follow the same process as above to secure
another side panel.
