ME19CB704112
Bespoke Smart 1.9 cu ft. Over-the-Range
Microwave with Sensor Cooking
Features
• 1.9 cu. ft. Oven Capacity
• Wi-Fi Connectivity & SmartThings Cooking
• 400 CFM
• Sensor Cook
• Auto Connectivity
• Ceramic Enamel Interior
• Glass Touch Controls
• White LED Display
• Voice Control
• 1000 Watts of Cooking Power
• 10 Power Levels
• Two-Stage Programmable Cooking
• Auto Defrost/Sensor Reheat
• Auto Cook
Convenience
• Eco Mode (Reduces Standby Power)
• Clock (12 hr/24 hr) with
Daylight Saving Time Adjustment
• Kitchen Timer
• End Signal
• Interior Light: Incandescent (1)
• Cooktop Lighting (Halogen): High/Low/Off
• Vent Fan Control: Boost/Hi/Mid/Lo/Off
• Child Safety Lock
• Sound On/Off
Signature Features
1.9 cu. ft. Large Capacity
• This microwave oven cavity has a sizeable 1.9 cu ft capacity
that can hold larger serving sizes.
Wi-Fi Connectivity & SmartThings Cooking
• This microwave makes weekly meal prep and planning easier
with Wi-Fi and SmartThings Cooking. The SmartThings App
lets you monitor and adjust settings or control the ventilation
and lighting from anywhere. Search recipes, plan meals, and add
any missing ingredients to your grocery cart for at-home delivery
with SmartThings Cooking*.
*Available on Android or iOS devices.A Wi-Fi connection and a Samsung SmartThings account are required.
4-Speed 400 CFM Ventilation System
• This Over-the-Range Microwave features a 400 CFM ventilation
system quickly and quietly eliminates steam and odor from
the kitchen.
Available Colors
White Glass
White LED Display
This Over-the-Range microwave includes smart technology that makes microwave cooking
even easier. Powerful ventilation used while cooking keeps your kitchen virtually odorless.
Bespoke kitchen appliances are available in complementary colors to the Bespoke refrigerator.
Ceramic Enamel Interior

Actual color may vary. Design, specifications, and color availability are subject to change without notice. Non-metric weights and measurements are approximate.
©2022 Samsung Electronics America, Inc., 85 Challenger Road, Ridgeeld Park, NJ 07660. Tel: 800-SAMSUNG. samsung.com. Samsung is a registered trademark of Samsung Electronics Co., Ltd.
ME19CB704112
Bespoke Smart 1.9 cu ft. Over-the-Range
Microwave with Sensor Cooking
Specifications
• Oven Cavity: 1.9 cu. ft.
• Power Output: 1000W
• Power Consumption: 1700W/14.5 A
• Power Source: 120V/60 Hz
• Control Method: Glass Touch
• Display: White LED
• Cooking Control: 10 Power Levels Including
Defrost and Sensor Cook
• Cooking Timer: Digital, up to 99 Minutes, 99 Seconds
• Microwave Distribution System: Turntable
• Glass Turntable Diameter: 14 3⁄16"
• Vent Fan: 4-Speed/400 CFM
• Vent Fan Control: Boost/Hi/Mid/Lo/Off
• Cooktop Lighting: High/Low/Off
• Interior LightIncandescent
Warranty
One (1) Year Parts and Labor
Ten (10) Years Parts on Magnetron
Product Dimensions & Weight (WxHxD)
Cavity Dimensions: 221/8" x 1013/16" x 1427/32"
Outside Net Dimensions: 29 7/8" x 171/16" x 161/2"
Weight: 60.0 lbs
Shipping Dimensions & Weight (WxHxD)
Dimensions: 33 11/32" x 2025/32" x 19 3/8"
Weight: 67.2 lbs
16 1/2"
17 1/16"
Dimensions
FOR EASIER INSTALLATION AND PERSONAL SAFETY, WE RECOMMEND THAT TWO PEOPLE
INSTALL THIS MICROWAVE OVEN. IMPORTANT: Do not grip or use handle during installation.
NOTE: If your cabinet is metal, use the nylon grommet around the power cord hole to prevent
cutting of the cord.
NOTE: We recommend using ller blocks if the cabinet front hangs below the cabinet bottom shelf.
IMPORTANT: If ller blocks are not used, case damage may occur from overtightening screws.
NOTE: When mounting the microwave oven, thread power cord through hole in bottom of top
cabinet. Do not pinch cord or lift oven by pulling cord.
• This microwave oven is designed
for adaptation to the following
three types of ventilation:
A. Outside Top Exhaust (Vertical Duct)
B. Recirculating (Non-Vented Ductless)
C. Outside Back Exhaust
(Horizontal Duct)
• The space between the cabinets must
be 30" wide and free of obstructions.
• This microwave oven is for installation
over ranges up to 36" wide.
• The microwave must be level. Use a
level to make sure the cabinet bottom
is level. If the cabinets have a front
overhang only, with no back or side
frame, install the mounting plate
down the same distance as the front
overhang depth. This will keep the
microwave level.
Installing Your Microwave
Color Model # UPC Code
White Glass ME19CB704112 887276701684
30"
30" min.
5"
161
/
2"
12" max
29 7/
8"
