C TABLE OOL
LENGTH and
VOLTAGE METER
NEW
M U LT I F U N C T I O N C A B L E M E T E R
MEASURE VOLTAGE up to 250 VOLTS
MEASURE CABLE LENGTH up to 2500 FEET
The New CABLETOOL model 50 from Psiber Data Systems provides contractors, electricians, low
voltage installers, or anyone involved in the installation or maintenance of metallic cables with the
capability to quickly find faults in cables up to a distance of 2500 feet. Simply select the appropriate
cable type from the pre-stored library, attach the test leads to two conductors of the cable and with
a single press of a button the length of the cable or distance to an open or short is displayed.
Voltage on the wires is continuously measured and displayed to warn of a potentially
unsafe condition. The CABLE OOLT will also inject a tone onto the conductors for
tracing cables installed in walls and ceilings with any standard tone probe.
The universal banana jack test lead connectors allow for a wide
range of adapters for any connector type. The
affordable CABLE OOLT is an essential tool
for anyone in the cabling industry.
C TA B L E O O L M u l t i f u n c t i o n C a b l e M e t e r
™
Identify and Find the Distance to an Open
or Short in Seconds
Measure Cable Length in a Box, on a Spool
or in a Wall
Transmit Tone Signals for Tracing Hidden
Cable Runs
Measure Voltage to Identify Live Circuits
Extensive Built-in Library of Cable Types
Compatible with All Common Cables
Displays Length in Feet or Meters
0101-0025-0001 Printed in U.S.A.
© 2002 Psiber Data Systems Inc.
All Rights Reserved. The Psiber Logo,
psiber, and C
ABLE
T
OOL
are trademarks of
Psiber Data Systems Inc.
PINPOINT CABLE DAMAGE
Cables can be damaged during or after installation. Typically the
damaged section is hidden from view behind walls, above ceilings or
buried underground. The CABLETOOL uses TDR (Time Domain
Reflectometry) technology to quickly identify an open or a short and
provide the distance to the problem location. Additionally, the tone
generator feature works with standard tone probes so that the exact cable
path can be traced.
MEASURE CABLE LENGTH ON A SPOOL OR INSTALLED
The CABLETOOL makes it easy for installers to know the amount
of cable remaining on a spool or in a box before pulling a run. When
multiple runs are being installed in the same area, the first run can be
measured to accurately determine the total amount of cable required to
complete the job. Checking cable inventory prior to starting a job
eliminates unplanned trips to buy more cable.
EASY TO USE
The CABLETOOL is simple to operate. After turning the unit on, a
cable can be measured or toned with a single push of a button. The full
graphics display provides all the cable and measurement information
together on one screen. The built-in library of over sixty cable types
makes finding the correct cable information easy. The standard banana
jack connectors means that different test leads and adapters are available
from many vendors.
AFFORDABLE
Telephone and CATV companies have used TDRs to find cable
problems for over thirty years. Until recently, this type of tool cost
thousands of dollars. Advances in technology have allowed the
CABLETOOL to provide the capabilities of previous TDRs at a fraction of
the price.
Selectable Cable Type with
a Library of Over 60 Cables
All Measurement Information Shown on One Screen
with the Press of a Single Button
L e n g t h M e a s u r e m e n t S c r e e n
Type of Cable Fault
(Open or Short)
Adjustable Cable NVP
Length Measurement
in Less Than 2 Seconds
Continuous Voltage Measurement
Physical
Dimensions: 7.0 in. x 3.2 in. x 1.4 in.
17.8 cm x 8.1 cm x 3.6 cm
Weight : 8.7 ounces
(w/batteries) 247 grams
Power
Four AA Alkaline Batteries
Environment
Operating Temperature: 0° to 50°C
Storage Temperature: -10° to 55°C
Length
Accuracy: +/- 2% plus +/- 2 feet
(with correct NVP)
Resolution: 1 foot or 0.2 meters
Maximum: 2500 feet or 750 meters
Minimum: 0 feet or meters
Voltage (True RMS Responding)
Range: 0-250V (AC or DC)
Accuracy: +/- 3% plus 1V
Tracing Tone
Frequencies: 575Hz, 977Hz, 1.0KHz, 7.82KHz
Patterns: Four
Display
Graphical - 122 x 32 pixels
Product design and specifications subject to change without notice.
S p e c i f i c a t i o n s
C T Model 50 Multifunction Cable MeterABLE OOL
Includes: Red Test Lead with Alligator Clip
Black Test Lead with Alligator Clip
Carrying Case
Four AA Alkaline Batteries
Psiber Data Systems Inc
7075-K Mission Gorge Road
San Diego, California 92120 USA
Phone: 619-287-9970
FAX: 619-287-9978
Internet: www.psiber.com
e-mail: info@psiber.com
O r d e r i n g I n f o r m a t i o n
