Manual
RCA-24
Item no. 45-02247
24-fold RailCom display
t ms elektronik
a
n n n
English RCA-24
Table of contents
1. Getting started ...........................................................................3
2. Safety instructions.......................................................................4
3. Background information: RailCom................................................5
4. Operating mode of the RCA-24....................................................7
5. Technical specifications...............................................................8
6. Connections................................................................................9
7. Programming............................................................................10
8. Operation.................................................................................12
9. Check list for troubleshooting.....................................................13
10. Guarantee bond........................................................................14
11. EU declaration of conformity......................................................15
12. Declarations conforming to the WEEE directive...........................15
© 07/2013 Tams Elektronik GmbH
All rights reserved. No part of this publication may be reproduced or
transmitted in any form or by any means, electronic or mechanical,
including photocopying, without prior permission in writing from Tams
Elektronik GmbH.
Subject to technical modification.
Remark: RailCom® is the registered trademark of the Lenz Elektronik
GmbH, Hüttenbergstraße 29, D-35398 Gießen. To increase the text´s
readability we have refrained from refering to this point in each
instance.
Page 2
RCA-24 English
1. Getting started
How to use this manual
This manual gives step-by-step instructions for safe and correct
connecting of the device, and operation. Before you start, we advise
you to read the whole manual, particularly the chapter on safety
instructions and the checklist for trouble shooting. You will then know
where to take care and how to prevent mistakes which take a lot of
effort to correct.
Keep this manual safely so that you can solve problems in the future. If
you pass the device on to another person, please pass on the manual
with it.
Intended use
The RailCom display RCA-24 is designed to be operated according to
the instructions in this manual with digital model railways. Any other
use is inappropriate and invalidates any guarantees.
The RCA-24 should not be mounted by children under the age of 14.
Reading, understanding and following the instructions in this manual
are mandatory for the user.
Checking the package contents
Please make sure that your package contains:
one display RCA-24,
a CD (containing the manual and further information).
Required materials
In order to connect the device you need wire. Recommend diameters:
data bus: > 0,1 mm². It is recommended to use twin wire (e.g. LiYz,
2x0,19 mm², red-brown, item no. 73-30037);
connections to the voltage supply of the display device: > 0,25 mm².
Page 3
