USER MANUAL
REFRIGERATOR
PLEASE READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
RC518CXD0
Images are for reference only. Products are subject to change without notice.
Please read the instruction manual carefully before use and keep it for future reference.
1
Contents
Safety instructions
Product introduction
Handling and placement
Preparations prior to use
Operation keys
Illustration and operation of display panel
Food storage
Disassembly and assembly method of accessory
Fault analysis
Non-failure
Technical parameters
Packing list
Thank you for buying TCL refrigerator. We hereby express our thanks.
Welcome to use TCL refrigerator. We will do our best to provide you with quality
1. his appliance is not intended for use by persons (including children) with reduced physical,T
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.Children should be supervised to ensure that they do not play with the appliance.
2.If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
3.This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way andun
derstand the hazards involved. Children shall not play with the appliance. Cleaning and usermai
ntenance shall not be made by children without supervision.
4.WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure,
clear of obstruction.
5.WARNING: Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
6.WARNING: Do not damage the refrigerant circuit.
7.WARNING: Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
8.Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
9.This appliance is intended to be used in household and similar applications such as
— Sta ffkitchen areas in shops, offices and other working environments;
— Farm houses and by clients in hotels, motels and other residential type environments;
— Bed and breakfast type environments;
— Catering and similar non-retail applications.
service.
Safe recovery instructions
Description of climate types
10.T
P2
P5
P6
P7
P8
P8
P11
P12
P15
P15
P16
P16
P17
P17
his product contains a light source of energy efficiency class F for light source ERP，
test with(without) light cover.
2
Safety instructions
1.Warning
Warning: No barrier is allowed around the appliance or in the embedded structure in
orderto ensure the free ventilation.
Warning: It is forbidden to speed up the defrosting process with any mechanical
equipment or by other method except for the method recommended by the manufacturer.
Warning: Never damage the refrigerating circuit.
Warning: Never use any electric apparatus in the food chamber of the appliance
except for the type recommended by the manufacturer.
Warning: Never place the liquid beverage or food contained with glass container in
the freezing chamber for fear of cracking.
Warning: If powered off, the refrigerator shall be powered on 5min later for fear of
damaging the compressor.
Warning: If any live part, abnormal noise, smell, smoke or other abnormality is found
during use, it is necessary to power o ffthe appliance immediately and contact the after-
sales service department of the Company timely.
Warning: Never place your finger or hand under the refrigerator, especially rear
bottom of refrigerator; otherwise, you may be hurt by the sharp matter.
Warning: The children must not play or climb the refrigerator. The operation by the
children must be supervised by their parents for fear of danger.
Warning: Never place your hand between the doors to open or close door for fear of
jamming your finger. The door handle shall be used to open or close the door.
Warning: Under the rated climate types SN, N and ST, the operating ambient range of
the appliance is 10 ~38 ; under the climate types SN, N, ST and T, the operating ℃ ℃
ambient range of the appliance is 10 ~43 . If the appliance operates outside the rated ℃ ℃
climate type (ambient temperature range), the appliance may not maintain the satisfying
interior temperature.
Safety instructions
Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances
Opening the door for long periods can cause a significant increase of the temperature in the
compartments of the appliance.
Clean regularly surfaces that can come in contact with food and accessible drainage systems.
Clean water tanks if they have not been used for 48 h; flush the water system connected to a
water supply if water has not been drawn for 5 days.
Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact
with or drip onto other food.
Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or
making ice-cream and making ice cubes.
One-, two- and three-star compartments are not suitable for the freezing of fresh food.
If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry,
and leave the door open to prevent mould developing within the appliance.
Warning: When positioning the appliance, ensure the supply cord is not trapped or
damaged.
Warning Risk of fire / flammable materials:
Warning: Do not locate multiple portable socket-outlets or portable power supplies at the
rear of the appliance.
3
2. Cautions
Cautions: The power supply of this product must be uniform with the power supply
mentioned on the nameplate, and the standard independent 3-hole socket shall be used
(above 10A, and reliably grounded). One socket must not be shared by more than one
appliance; otherwise, fire may be caused due to overheat.
Cautions: Never pull the power wire by hand. It is necessary to hold and unplug the
power connector from the socket to disconnect the power supply. The power wire or
connector must not be touched by the wet hand for fear of electric shock.
Cautions: The power wire must not be squeezed by the refrigerator or any heavy
load, and the power wire shall not be bent extremely. The damage or peeling of power
wire may result in fire or electric shock. If the power wire is broken or cut, please contact
the after-sales service department immediately.
Cautions: No flammable or explosive matter or corrosive acid or alkaline matter is
allowed in the refrigerator.
4
Safety instructions
Cautions: The refrigerator must not be used in the rain or under the sunshine.
Cautions: It is forbidden to place the container with fluid on the refrigerator because
the breakage or turnover of the container may affect the electrical insulation of
refrigerator and result in electric shock or fire.
Cautions: The refrigerator must not be disassembled or modified without
permission. The repair of refrigerator must be performed by the specialist.
Cautions: In case of leakage of any flammable gas such as coal gas, it is necessary
to close the leaking valve first and then open the window for ventilation, and forbidden to
unplug the refrigerator connector immediately for fear of fire or explosion due to electric
spark.
Cautions: Refrigerating appliances – in particular a refrigerator-freezer Type I –
might not operate consistently (possibility of defrosting of contents or temperature
becoming too warm in the frozen food compartment) when sited for an extended period
of time below the cold end of the range of temperatures for which the refrigerating
appliance is designed;
Cautions: The fact that effervescent drinks should not be stored in food freezer
compartments or cabinets or in low-temperature compartments or cabinets, and that
some products such as water ices should not be consumed too cold.
Cautions: The need to not exceed the storage time(s) recommended by the food
manufacturers for any kind of food.
Cautions: The precautions necessary to prevent an undue rise in the temperature of
the frozen food while defrosting the refrigerating appliance, such as wrapping the frozen
food in several layers of newspaper.
Cautions: The fact that a rise in temperature of the frozen food during manual
defrosting, maintenance or cleaning could shorten the storage life.
Cautions: The care required with regard to frozen food in storage in the event of an
extended non-running of the refrigerating appliance (interruption of power supply or
failure of the refrigerating system).
Cautions: The action to be taken when the refrigerating appliance is switched o ff
and taken out of service temporarily or for an extended period (e.g. emptied, cleaned
and dried, and the door(s) or lid(s) propped ajar).
5
Product introduction
Refrigerator bottle
holder
Warm prompt:
If your product is improved product, it may not be totally same as that in the
instructions. But it will not change the performance and method of application.
Please feel relieved about usage.
The pictures are for reference only. Please refer to the object
Refrigerator shelf
Fruit and vegetable box
T-Temp functionBottom crisper
Refrigerator bottle holder
Variable temperature tray
Variable temperature drawer
Freezer tray
Freezer drawer
Bottom crisper cover
Water storage box
Lamp
6
Handling and placement
During handling, the door
side of the refrigerator shall
not contact with the
handling tools
Removing the foam base is
beneficial for bottom heat
dissipation and can avoid
fire.
The refrigerator shall be
placed in an environment
which is dry, has good
ventilation, far from direct
sunshine and heat source.
The refrigerator shall be
placed on the flat and firm
surface. If the ground is not
flat, adjust the adjusting leg
to keep it level.
Never place the refrigerator
into a too cold environment
that may get frozen.
Warm prompt:
--When handling the refrigerator, at least two persons are required – one lifts the top of
rear part, the other one handles the bottom (if one part is clamped, it is quite
dangerous and may cause accident).
--When moving the refrigerator, the lower runner may damage and scratch the floor. If you
need to move the refrigerator for a long distance, the internal accessories shall be fixed
using adhesive tape. Otherwise, the accessories may get damaged due to crashing each
other.
--Please place the refrigerator in the position with small vibration or little exposed to
vibration. For users in the area where earthquake often occurs, please fix the refrigerator
against the wall or pole. Otherwise, the falling of refrigerator will cause accident.
--Sufficient clearance shall be left around. If the clearance is too small or place goods on the
top or close to the side, or paste on the sides, the heat dissipation of refrigerator will be
affected, and thus to cause unnecessary electric energy waste as well as burn out of the wall
and other goods; the contact between the back and wall will cause vibration and noise;
--Adjust the front part and adjusting leg of the refrigerator to level it. Unlevel of the
refrigerator will cause vibration and noise.
Certain space shall be left
around the refrigerator,
shown in the figure.
>1cm
>1cm
>2cm
Outline dimension of
product
Total space needed by the use of
product
L1 L2
W1 W2
Space needed by the free ventilation
Outline dimension of
product
Unit:mm
L1 W1 L2 W2 L3 W3
＞L1+450
＞W1+480＞L1+20 ＞W1+20640 833
7
Handling and placement
Space needed by the use of
product
This refrigerating appliance is not intended to be used as a built-in appliance
The outline dimension of the product and the space needed by the use of product are
shown in the following.
pictures:
Space needed by the
use of product
Total space needed
by the use of product
1. Remove all packing assemblies such as case fixing tape etc., especially the foam base.
2. Use warm wet cloth to clean both interior and exterior of the refrigerator, (neutral detergent can be
added in warm water).
3. After leveling and cleaning the refrigerator, stand it for about 2 hours before plugging the
Preparations prior to use
power plug for powering on, and cool the refrigerator for 2 to 3 hours before storing foods.
1. Remove fixing tape 2. Connect to power 3. Store food after
connecting to power
for 2-3 hours
Wipe with
warm and
wet cloth
In hot summer, 24 hours are
needed to fully freeze the food.
Check the refrigerating condition
on the second day.
Do not open the
doors frequently
to save electricity.
The plastics deodorant will disappear
automatically after freezing for a while.
Notes:
1.When installing the refrigerator as a built-in unit, it is important to consider the accuracy of cabin
measurements and the levelness of the floor.
2. Due to variations in plug sizes and socket locations, the dimensions W2 and L2 for the
refrigerator placement space do not include the plug installation size. When installing the socket,
consider the thickness of the plug and reserve enough space according to the actual situation.
8
Preparations prior to use
The appliance should be located in the coolest area of the room, away from heat producing appliances
or heating ducts, and out of the direct sunlight.
Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance
forces the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil.
Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance. This cuts
down on frost build-up inside the appliance.
Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners
interfere with cold air circulation, making the appliance less efficient.
Organize and label food to reduce door openings and extended searches. Remove as many items as
needed at one time, and close the door as soon as possible.
Please refer to the product introduction picture on page 6 for the placement of accessories
Operation keys
Illustration and operation of display panel
10
Operation keys
refrigerator chamber
freezing function after it is under in high freezing status for 24 hours.
If the refrigerator compartment door or temperature change compartment door or freezer
compartment door is not tightly closed or kept opening for more than 1 minute, the “tick” buzzer
alarm will be heard. Press any key to temporarily stop the alarm, followed by alarm again 1 minute
later; Close the refrigerator compartment door or freezer compartment door tightly to stop the
alarm.
When the setting temperature in the temperature change compartment is not placed at “ O F”,
exit the temperature change deactivation function. (Under the temperature change deactivation
function mode, it is possible to automatically exit the temperature change deactivation
function when you carry out setting of other function. Note: Prior to access to the temperature
change deactivation function, empty the temperature change compartment.)
Under the “Temperature change deactivation” function mode, the temperature change compartment
is placed at the non-use state.
Tuotetiedot
| Merkki: | TCL |
| Kategoria: | Jääkaappi |
| Malli: | RC518CXD0 |
Tarvitsetko apua?
Jos tarvitset apua merkille TCL RC518CXD0 esitä kysymys alla ja muut käyttäjät vastaavat sinulle
Jääkaappi TCL Käyttöohjeet
9 Helmikuuta 2025
31 Tammikuuta 2025
23 Tammikuuta 2025
23 Tammikuuta 2025
23 Tammikuuta 2025
23 Tammikuuta 2025
23 Tammikuuta 2025
23 Tammikuuta 2025
23 Tammikuuta 2025
23 Tammikuuta 2025
Jääkaappi Käyttöohjeet
- Jääkaappi Teka
- Jääkaappi Maytag
- Jääkaappi Thomson
- Jääkaappi Amana
- Jääkaappi Uniprodo
- Jääkaappi Miele
- Jääkaappi Whirlpool
- Jääkaappi Etna
- Jääkaappi Haier
- Jääkaappi NewAir
- Jääkaappi Insignia
- Jääkaappi Adler
- Jääkaappi Pelgrim
- Jääkaappi Royal Catering
- Jääkaappi LG
- Jääkaappi Bosch
- Jääkaappi Jocel
- Jääkaappi BEKO
- Jääkaappi Exquisit
- Jääkaappi Grundig
- Jääkaappi Hisense
- Jääkaappi Sharp
- Jääkaappi Electrolux
- Jääkaappi Severin
- Jääkaappi Café
- Jääkaappi Balay
- Jääkaappi Siemens
- Jääkaappi Koldfront
- Jääkaappi Arcelik
- Jääkaappi Danby
- Jääkaappi Bartscher
- Jääkaappi Smeg
- Jääkaappi Hoover
- Jääkaappi Philips
- Jääkaappi Russell Hobbs
- Jääkaappi Hotpoint
- Jääkaappi Nabo
- Jääkaappi Amica
- Jääkaappi IKEA
- Jääkaappi Ignis
- Jääkaappi AEG
- Jääkaappi Rosieres
- Jääkaappi Inventum
- Jääkaappi Artusi
- Jääkaappi Cecotec
- Jääkaappi Samsung
- Jääkaappi Neff
- Jääkaappi Delonghi
- Jääkaappi Bomann
- Jääkaappi Edgestar
- Jääkaappi Kogan
- Jääkaappi Caple
- Jääkaappi PKM
- Jääkaappi Marvel
- Jääkaappi G3 Ferrari
- Jääkaappi Yamaha
- Jääkaappi Midea
- Jääkaappi Sauber
- Jääkaappi Candy
- Jääkaappi Liebherr
- Jääkaappi Viking
- Jääkaappi Orbegozo
- Jääkaappi Kuppersbusch
- Jääkaappi Gorenje
- Jääkaappi Summit
- Jääkaappi Accucold
- Jääkaappi Brandt
- Jääkaappi Gram
- Jääkaappi Panasonic
- Jääkaappi Monogram
- Jääkaappi Vox
- Jääkaappi Westinghouse
- Jääkaappi Orava
- Jääkaappi Schneider
- Jääkaappi Kluge
- Jääkaappi Juno-electrolux
- Jääkaappi Bertazzoni
- Jääkaappi DCG
- Jääkaappi Coyote
- Jääkaappi Stirling
- Jääkaappi Privileg
- Jääkaappi MPM
- Jääkaappi Cosmo
- Jääkaappi Khind
- Jääkaappi Euro Appliances
- Jääkaappi Bauknecht
- Jääkaappi Frigidaire
- Jääkaappi Whynter
- Jääkaappi GE
- Jääkaappi Concept
- Jääkaappi Guzzanti
- Jääkaappi XO
- Jääkaappi Omega
- Jääkaappi Hitachi
- Jääkaappi Fisher Paykel
- Jääkaappi Hyundai
- Jääkaappi Chiq
- Jääkaappi Vintec
- Jääkaappi Nevir
- Jääkaappi Eqtemp
- Jääkaappi Infiniton
- Jääkaappi Indesit
- Jääkaappi Daikin
- Jääkaappi Zephyr
- Jääkaappi Asko
- Jääkaappi Blaupunkt
- Jääkaappi Mitsubishi
- Jääkaappi Marshall
- Jääkaappi Scandomestic
- Jääkaappi Cylinda
- Jääkaappi Respekta
- Jääkaappi AYA
- Jääkaappi Costway
- Jääkaappi Dometic
- Jääkaappi Blaze
- Jääkaappi Husky
- Jääkaappi Fridgemaster
- Jääkaappi Eldom
- Jääkaappi Fisher And Paykel
- Jääkaappi Elba
- Jääkaappi Worx
- Jääkaappi Philco
- Jääkaappi Jenn-Air
- Jääkaappi Wisberg
- Jääkaappi ECG
- Jääkaappi HomeCraft
- Jääkaappi Igloo
- Jääkaappi ATAG
- Jääkaappi Landmark
- Jääkaappi Signature
- Jääkaappi Freggia
- Jääkaappi Becken
- Jääkaappi Element
- Jääkaappi Avanti
- Jääkaappi Acros
- Jääkaappi Kucht
- Jääkaappi Glem Gas
- Jääkaappi True
- Jääkaappi Perlick
- Jääkaappi Toshiba
- Jääkaappi BeefEater
- Jääkaappi Hansa
- Jääkaappi Thor
- Jääkaappi Sub-Zero
- Jääkaappi Koolatron
- Jääkaappi Coca-Cola
- Jääkaappi Kenmore
- Jääkaappi Meireles
- Jääkaappi Fagor
- Jääkaappi Edesa
- Jääkaappi IFB
- Jääkaappi Profilo
- Jääkaappi Gaggenau
- Jääkaappi Milectric
- Jääkaappi Tisira
- Jääkaappi Hiberg
- Jääkaappi LERAN
- Jääkaappi Zerowatt
- Jääkaappi Baumatic
- Jääkaappi Iberna
- Jääkaappi Ilve
- Jääkaappi Wolkenstein
- Jääkaappi Hoover-Grepa
- Jääkaappi Primo
- Jääkaappi Svan
- Jääkaappi Trisa
- Jääkaappi Corberó
- Jääkaappi Atosa
- Jääkaappi Scancool
- Jääkaappi FrigeluX
- Jääkaappi Mora
- Jääkaappi DAYA
- Jääkaappi Salora
- Jääkaappi Pitsos
- Jääkaappi Avallon
- Jääkaappi Aconatic
- Jääkaappi Fhiaba
- Jääkaappi Winia
- Jääkaappi Consul
- Jääkaappi Kuhla
- Jääkaappi Yolco
- Jääkaappi Sangiorgio
- Jääkaappi Ardes
- Jääkaappi Zanussi
- Jääkaappi Kernau
- Jääkaappi Cookology
- Jääkaappi Hanseatic
- Jääkaappi Aspes
- Jääkaappi Benavent
- Jääkaappi Vedette
- Jääkaappi Crosley
- Jääkaappi Goddess
- Jääkaappi Edy
- Jääkaappi Thetford
- Jääkaappi Kaiser
- Jääkaappi Pando
- Jääkaappi U-Line
- Jääkaappi Orima
- Jääkaappi Equator
- Jääkaappi Romo
- Jääkaappi Rhino
- Jääkaappi Cooluli
- Jääkaappi Hoshizaki
- Jääkaappi SEIKI
- Jääkaappi Premium
- Jääkaappi Corona
- Jääkaappi Oranier
- Jääkaappi Coors Light
- Jääkaappi FAURE
- Jääkaappi Ideal
- Jääkaappi Turbo Air
- Jääkaappi Emperor's Select
- Jääkaappi Beverage-Air
- Jääkaappi Delfield
- Jääkaappi Galanz
- Jääkaappi Snaigė
- Jääkaappi Avantco
- Jääkaappi Zanker
- Jääkaappi De Dietrich
- Jääkaappi Miller Lite
- Jääkaappi Lanbo
- Jääkaappi Cool Head
- Jääkaappi Listo
- Jääkaappi Schmick
- Jääkaappi Hestan
- Jääkaappi Helkama
- Jääkaappi Icecool
- Jääkaappi Schaub Lorenz
- Jääkaappi Premium Levella
- Jääkaappi Linarie
- Jääkaappi United
- Jääkaappi Kalamazoo
- Jääkaappi Robinhood
- Jääkaappi Brandy Best
- Jääkaappi Momcube
- Jääkaappi Waltham
- Jääkaappi Valberg
- Jääkaappi Rex
- Jääkaappi Lynx
- Jääkaappi Prima
- Jääkaappi Bompani
- Jääkaappi Sheffield
- Jääkaappi Stoves
- Jääkaappi Bushman
- Jääkaappi Richome
- Jääkaappi Sevenstars
Viimeisimmät Jääkaappi Käyttöohjeet
9 Huhtikuuta 2025
9 Huhtikuuta 2025
9 Huhtikuuta 2025
9 Huhtikuuta 2025
8 Huhtikuuta 2025
8 Huhtikuuta 2025
8 Huhtikuuta 2025
8 Huhtikuuta 2025
7 Huhtikuuta 2025
4 Huhtikuuta 2025
