Sivu 1/3
10/100/1000 Mbps
Desktop Switch
- 10/100/1000 Mbps Auto-Negotiation RJ45 ports supporting Auto-MDI/MDIX
- Green Ethernet technology saves power
- IEEE 802.3x ow control provides reliable data transfer
- Steel housing, desktop or wall-mounting design
- Support 802.1p/DSCP QoS and IGMP Snooping function
- Plug and play, no conguration needed
Highlights
Overview
The TP-Link Gigabit Unmanaged Switch TL-SG605/TL-SG608 provides an easy way to expand your
wired network. With all ports support Auto-MDI/MDIX, there’s no need to worry about the type of cable
to use. Featuring full duplex mode, TL-SG605/TL-SG608 can send and receive data at a rate up to
2000Mbps, making it an ideal choice for expanding your high performance wired network. Moreover,
with innovative energy-ecient technology, TL-SG605/TL-SG608 can save power consumption,
making it an eco-friendly solution for your home or oce network.
TL-SG605 TL-SG608
Gigabit Switch
Featured 10/100/1000Mbps ports, TL-SG605/TL-SG608 greatly expands your network capacity,
enabling instant large les transferring. So, power users in the home, oce, workgroup, or creative
production environment can now move large, bandwidth-intensive les faster. Transfer graphics, CGI,
CAD, or multimedia les across the network instantly.
Power down Idle Ports
When a computer or network equipment is o, the corresponding port of a traditional switch will
continue to consume considerable amounts of power. can automatically detect
TL-SG605/TL-SG608
the link status of each port and reduce the power consumption of ports that are idle, resulting in up to
reduction in power use.
Power Budget According to Cable Length
Ideally, shorter cable would use less power because of less power degradation over their length. This is
not the case with most devices as they will use the same amount of power across the cable regardless
of the length.
Easy to Use
The auto features of this gigabit switch make installation plug and play and hassle-free. No conguring
is required. Auto MDI/MDIX eliminate the need for crossover cables. Auto-negotiation on each port
senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for
compatibility and optimal performance.
https://www.tp-link.com
Specications are subject to change without notice. All brands and product names are trademarks or registered trademarks of their respective holders. © 2023 TP-Link
Specications
Ordering Information
Product Picture
Model TL-SG605 TL-SG608
S r IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1ptanda ds
Forwar Stording Mode e and f dorwar
Inter ace f
5 10/100/1000 Mbps RJ45 ports
Auto Negotiation
Auto MDI/MDIX
8 10/100/1000 Mbps RJ45 ports
Auto Negotiation
Auto MDI/MDIX
Switching Capacity 10 Gbps 16 Gbps
MAC A ress Table 2K 4Kdd
Packet Forwar te 7.4 Mpps 11.9 Mppsding Ra
1 Mb 1.5 Mb
Jumbo Frame 16 KB 16 KB
A v Featuresd anced
Green Technology
802.3x Flow Control
802.1p/DSCP QoS
IGMP Snooping
Max Power C ption Vonsum 2.9 W (220 /50 Hz) 4.0 W (220 V/50 Hz)
Max Heat Dissipation 9.889 BTU/h 13.64 BTU/h
LEDs Power, Link/A cators per port built into RJ45 porct (indi t)
Power Supply External Ada (output: 5 VDC/0.6 A)pter External Ada (output: 5 VDC/0.6 A)pter
Dimensions (W × D × H) 3.9 x 3.9 x 1.0 in.
(99.8 x 98 x 25 mm)
6.2 x 4.0 x 1.0 in.
(158 x 101 x 25 mm)
CE, FCC, RoHS
Environment
Operating Temperature F: 0 °C~40 °C (32 °F~104 ° )
Storage Temperature F: -40 °C~70 °C (-40 °F~158 ° )
Oper ty: 10% ~ 90%RH, non-ating Humidi condensing
Stor ty: 5%~95%RH, non-age Humidi condensing
Product Model Description
TL-SG605 5-Port 10/100/1000 Mbps Desktop Switch
TL-SG608 8-Port 10/100/1000 Mbps Desktop Switch
