Sivu 1/26
USER MANUAL
August 11th 2022
We always value feedback and ideas, so feel free to reach out.
Please check the website for the latest firmware!
THANK-YOU!
Thank-you for adopting MEGAfm, the product of several years of work &
play.
MEGAfm offers a unique gritty texture that is uncommon for FM
synthesisers, plus an unprecedented hands-on control of all the synth’s
parameters.
We hope that you will enjoy making music with MEGAfm as much as we
have enjoy developing it!
ABOUT MKII
In September 2022 MEGAfm becomes MEGAfm MKII.
This updated version is identical in appearance and functionality but it
will include a pair of YM3438 chips instead of the YM2612.
The YM3438 is a variant of the YM2612 that is identical in functionality
and was featured in the Sega Megadrive II.
The circuit layout has also been updated to grant access to the FM chips
with minimal disassembly.
Indeed the chips are now socketed (removable) and accessible by
removing the bottom panel.
This allows customers to install alternate FM chips (like the YM2612,
modern alternatives or even custom sound chips).
Customers even have the ability to mix different versions of FM chip as
both slots can be configured individually.
MEGAfm MKII features the same audio circuitry and warm analog
distortion as the MKI, as a result both chips sound very similar inside of
MEGAfm.
The firmware will work identically on both versions.
YM2612/YM3438 Overview
“The Yamaha 2612/3438 Frequency Modulation (FM) sound synthesis IC
resembles the Yamaha 2151 (used in Sega’s coin-op machines) and the
chips used in Yamaha’s synthesisers.
It is famously known as the Sega Megadrive’s voice.
An FM channel is capable of expressing, with a high degree of realism, a
single note in almost any instrument’s voice. Chords are generally created
by using multiple FM channels.
The standard FM channels each have a single overall frequency and data
for how to turn this frequency into the complex final wave form (the
voice). This conversion process uses four dedicated channel components
called ‘operators’, each possessing a frequency (a variant of the overall
frequency), an envelope, and the capability to modulate its input using
the frequency and envelope. The operator frequencies are offsets of
integral multiples of the overall frequency.
There are 6 FM channels. Channels 3 and 6, have the capability to use a
totally separate frequency for each operator rather than offsets of integral
multiples (ch3 special mode). This works well for sound effects and
experimental instruments. “ !
