Sivu 1/26

Safety Instructions for IONIC 16

W : E H ARNING LECTRICAL AZARD

To ensure your safety, please read this manual thoroughly before using the unit. Please observe these safety rules.

1. Keep this user guide for future reference.

2. Take notice of and comply with all warnings

included in the user guide or indicated on the

device itself.

3. Do not expose this unit to rain or moisture. Do not

spill water or other liquids on this unit.

4. cleaning the cabinet or other parts of this When

appliance, use only a dry or slightly damp soft

cloth.

5. Do not block any ventilation openings or interfere

with the proper ventilation of this unit. Install in

accordance with the instructions.

6. Do not defeat the internal ventilation fans.

7. Do not use or store near any heat sources such as

radiators, heat registers, stoves, or other heat-

producing appliances.

8. Protect the power cord from being walked on or

otherwise damaged by items placed on or against it.

Particular attention should be given to the plugs,

receptacles, and the point where the cord exits the

appliance.

9. To avoid the risk of electrical shock, do not touch

any exposed wiring while the unit is in operation.

10. Only use attachments/accessories specified by the

manufacturer.

11. Unplug this unit and all connected electrical

equipment during lightning storms or when left

unused for a long period of time.

12. Refer all servicing to qualified service personnel.

Servicing is required when the appliance has been

damaged in any way or fails to operate normally.

For questions about safe installation, please contact us at www.waves.com.

IONIC 16 / User Guide

Contents

INTRODUCTION ................................................................................................................................................................. 4

HARDWARE AND CONNECTIONS 5...................................................................................................................................

Front Panel ...................................................................................................................................................................... 5

Rear Panel ....................................................................................................................................................................... 6

Getting Started ................................................................................................................................................................. 7

Connect the Hardware ................................................................................................................................................. 7

Download and Install Software ........................................................................................................................................ 9

Configure the System .................................................................................................................................................... 11

Status Indicators ........................................................................................................................................................ 12

Updating Firmware ..................................................................................................................................................... 13

Identifying a Device on the SoundGrid Network ......................................................................................................... 13

Shared Devices on Multiple LV1 systems. ..................................................................................................................... 13

IONIC 16 CONTROL PAN EL ............................................................................................................................................ 14

Input Page .................................................................................................................................................................. 15

Output Tab ................................................................................................................................................................. 18

Clock Tab ................................................................................................................................................................... 19

System Info Tab and About Tab ................................................................................................................................. 20

Presets ....................................................................................................................................................................... 21

Device ID .................................................................................................................................................................... 21

RESETTING THE UNIT .................................................................................................................................................... 21

SPECIFICATIONS ............................................................................................................................................................ 22

Dimensions ................................................................................................................................................................ 24

Installing IONIC 16 in a Rack ..................................................................................................................................... 25

Waves Inc

2800 Merchants Drive, Knoxville, TN 37912 USA

1-865- -9200 909

www.waves.com
