TAG _______
AquaSpec® is a registered trademark of Zurn Industries, LLC
©2010 Zurn Industries, LLC
ZURN INDUSTRIES, LLC ♦♦♦♦
♦ COMMERCIAL BRASS OPERATION ♦♦♦♦
♦ 2640 SOUTH WORK STREET ♦♦♦♦
♦ FALCONER NY 14733
Phone: 1-800-997-3876 ♦♦
♦♦
♦ Fax: 1-919-775-3541 ♦♦
♦♦
♦ www.zurn.com
In Canada: ZURN INDUSTRIES LIMITED ♦♦♦♦
♦ 3544 Nashua Drive ♦♦♦♦
♦ Mississauga, Ontario L4V1L2 ♦♦♦♦
♦ Phone: 905/405-8272 Fax: 905/405-1292
_____________________
LABORATORY FAUCET - DOUBLE
Z826C4-XL
Note: All dimensions are for reference only. Do not use for pre-plumbing.
Rev. Date: 8/4/10 C.N. No. 126723
Dwg. No. 301674 Product No. Z826C4-XL
OPTIONAL ACCESSORIES
Suffix Description
Engineering Specifications: Zurn AquaSpec ®
Z826C4-XL
Polished chrome-plated double laboratory faucet with integral shank, quarter turn ceramic disc
cartridges and a 8”[203mm] centerline rigid or swing gooseneck spout. Unit is furnished with a 2.2
GPM [8.3 L] pressure compensating aerator (complying with ANSI A112.18.1 Standard for flow),
4”[102mm] vandal-resistant color-coded metal wrist blade handles, mounting hardware and
stainless steel flex connection hoses.
__ -AR Anti-Rotation Pins
__ -CST Copper Supply Tubes
__ -FC 2.0 GPM [7.6 L] Laminar Flow Control in Base of Spout
__ -G 1-1/4" [32mm] Grid Strainer Drain
__ -HCT Hot/Cold Text Indexes
__ -MY Mixing Yoke Assembly Instead of Copper Supplies
__ -PT 1-1/4" [32mm] Cast Brass P-Trap with a 7-1/2" [191mm] Long 17-Gauge Wall Bend
__ -140 140o Restricted Swing Spout
__ -2F 2.2 GPM [8.3 L] Vandal-Resistant Pressure Compensating Female Aerator
__ -3F 0.5 GPM [1.9 L] Vandal-Resistant Pressure Compensating Female Spray Outlet
__ -4F 2.2 GPM [8.3 L] Vandal-Resistant Pressure Compensating Female Laminar Flow Outlet
__ -7F 1.0 GPM [3.8L] Pressure Compensating Female Spray Outlet
__ -16F 1.0 GPM [3.8L] Vandal-Resistant Pressure Compensating Female Spray Outlet
__ -17F 1.5 GPM [5.7L] Vandal-Resistant Pressure Compensating Female Aerator
__ -18F 1.5 GPM [5.7L] Vandal-Resistant Pressure Compensating Female Laminar Flow Outlet
__ -18FH 18” [457mm] S.S. Braided Flex Hoses
__ -19F 1.5 GPM [5.7 L] Anti-Microbial Pressure Compensating Female Laminar Flow Outlet
__ -21F 1.0 GPM [3.8L] Pressure Compensating Female Laminar Flow Outlet
__ -22F 1.0 GPM [3.8L] Pressure Compensating Vandal-Resistant Female Laminar Flow Outlet
__ -23F 1.5 GPM [5.7L] Pressure Compensating Female Aerator
Zurn Lead Compliant* “XL” products
are a line of durable, high quality
brass faucets and fixtures that are
designed and manufactured to
comply with state laws and local
codes that mandate lead content
levels. Zurn “XL” products are
manufactured with *not more than
0.25% lead content when used with
respect to wetted surfaces of pipes
and pipe fittings, plumbing fitting
and fixtures: California Health &
Safety Code § 116875; Vermont 9
VCA § 2470h
