EKI 2428G- -4FA
Rackmount Ummanaged Redundant Industrial Switch
Specifications
The EKI 2428G is an unmanaged switch with 24 -
Gigabit ports and 4 Gigabit SFP ports that can
provide users with abundant ports to connect
many devices. It is designed for rack-mount
installation, and suitable for edge to core
networks.
Before installation, please make sure that you
have received the following:
•
1 x EKI- - 2428G 4FA Rackmount Ummanaged
Switch
•
1 x Startup manual
If anything is missing or damaged, contact your
distributor or sales representative immediately.
General
•
Compatibility: IEEE 802.3, 802.3u, 802.3x,
802.3ab, 802.3z
• LAN: 10/100/1000 Base-TX
•
SFP: Up to 110 km (depends on SFP)
•
Ethernet RJ- m45 Distance: Up to 100
•
Connectors:
24 x 10/100/1000Base- -T/TX RJ 45
4 x SFP(mini GBIC) port-
•
Power Requirements:
100~240V single AC power input
•
Power Consumption: 18 W
•
Dimensions (W x H x D): 442 x 44 x 211.1 mm
•
Enclosure: Metal shell with solid mounting kits
•
Operating Temperature: 0 ~ 55°C (32 ~ 131°F)
•
Storage Temperature: - - 20 ~ 70°C ( 4 ~158°F)
•
Operating Humidity: 10 ~ 95% (non condensing)-
•
Storage Humidity: 10 ~ 95% (non- )condensing
•
EMC: CE FCC Class A
•
Warranty: 5years
For more detailed information, please refer to the
full manual which can be found on the Advan-
tech’s website.
User Manual
Notes
For more information on this and other Advantech
products, please visit our websites at:
http://www.advantech.com/products
For technical support and service:
http://www.advantech.com/support/
This startup manual is for EKI- -2428G 4FA
Part No:
1st Edition
Dec 2017
Packing List
Overview
STARTUP
MANUAL
1 Startup Manual
Warning: This is a Class A product. In domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.
1. Read these safety instructions carefully.
2. Keep this user manual for later reference.
3. Disconnect this equipment from any AC outlet before
cleaning. Use damp cloth. Do not use liquid or spray
detergents for cleaning.
4. For plug in equipment, the power outlet socke must -
be located near the equip ment and must be easily -
accessible.
5. Keep this equipment away from humidity.
6. Put this equipment on a reliable surface during
installation. Dropping it or letting it fall may cause
damage.
7. The openings on the enclosure are fo air convection.
Protect the equipment from overheating. DO NOT
COVER THE OPENINGS.
8. Make sure the voltage of the power source is correct
before connecting the equipment to the power outlet.
9. Position the power cord so that people cannot step
on it. Do not place anything over the power cord.
10. All cautions and warning on the equipment should
be noted.
11. the equipment If is a not used for long time, disconnect
it from the power source to avoid damage by transient
over voltage.
12. Never pour any liquid into an opening. This may cause
fire or electrical shock.
13. Never open the equipment. For safety reasons, the
equipment should be opened only by qualified
service personnel.
1. one Position one bracket to align with the holes on
side of the switch and secure it with the bracket
screws. Then attach the remaining bracket to the
other side of the Switch.
2. After attaching the mounting brackets, position the
EKI- -2428G 4FA Ummanaged Switch in the rack by
lining up the holes brackets the appropriate in the with
holes on the rack. Secure the Switch to the rack by a
screw driver with the rack-mounting screws.
14. If one of the following situations arises, get the equipment
checked by service personnel:
•The power cord or plug is damaged.
•Liquid has peretrated into the equipment.
•The equipment has been exposed to moisture.
•The equipment does not work well, or you cannot
get it to work according to the user manual.
•The equipmen ha been droppe an damaged. t s d d
•The equipment has obvious signs of breakage.
15. Do NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT
WHERE THE STORAGE TEMPERATURE MAY GO
BELOW - (-20°C 4°F) OR ABOVE 70°C (158°F) THIS
COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT.
Startup Manual 2
Rack Mounting Safety Instructions
Overview
