Made in U.S.A. www.SmartAVI.com 1-800-AVI-2131
EZWallPro
UserManual
4x4HDVideoWallController
HDMI,VGA,CompositeandY/Pb/PrInputs
IntegratedUSBMediaPlayer
MultiFormatVideoWallProcessor
2
TABLE OF CONTENTS 
WHAT'S 2INTHEBOX? 
INTRODUCTION 3
FEATURES 3
APPLICATIONS 3
TECHNICALSPECIFICATIONS 4
HARDWAREINSTALLATION 5
FRONT 6PANELCONTROL 
RS232COMMANDS 7
IRREMOTE CONTROL  8
CONTROLVIAETHERNET ‐9 11
LIMITEDWARRANTY STATEMENT 14
FIRMWAREUPDATE1213
WHAT'S IN THE BOX? 
PART NO. QTY DESCRIPTION
EZW4x4‐  S 1 EZWallPro:4x4 Video WallController
CCPWR06 1 Powersupplycord
  1 Quick Start Guide
EZRMT(NEC38KHz) Remote 1 IR Control
SMEYE 1 IRReceiver
Figure 2-1
Figure 2-2
3
INTRODUCTION
Thank AVIyouforchoosingSmart‐ EZWall EZWallPro solution.foryourvideowall The ‐Proofferstopnotch
HDDVI foroutput fivedifferent inputs.typeofsignal Createstriking 4x4 wall displays easily  withsimplesig
nal andswitching flexibleconnectivity.TheEZWall featuresProeven  a fullyintegratedUSBmediaplayer,
perfectforpopulatingyourdisplayswith digital content.enticing 
Capable scaleofexpanding twelveanysupported video input to large‐ screens EZWallat1080p,the ‐Pro
showcases SmartAVI youstunningpicturequalityand products’signatureeaseofuse.Inthisguide, willlearn
how to installandoptimizeyour theexperiencewith EZWallProusing basic steps. theWewillcover setting  
hardwareup,activating and and helpful connectingyoursystems, offer tipsonhowtobestuseEZWallPro’s
excellent enhanceselectionofpicturemodes to yourvideowall. Congratulations againonchoosingEZWall
ProandSmartAVIasyourgo‐ to videowallsolution!
FEATURES
 16  ‐  ‐ screen (4x4) multi Layout, multi format video wall controller
 Outputs:   (16) DVI single link
 Inputs:        (2) HDMI, (1) VGA, (2) Composite AV, (1) Y/Pb/Pr
 Integrated   USB Media Player for digital video, imagery and audio
 Internal  EDID learning
 1080p   (1920x1080 @ 60Hz) Full HD resolution output
 No   additional hardware or software required
 Supports   control via Front Panel Buttons
 Supports   control viaIR Remote control
 Supports  ‐ control via RS 232
 Supports   control via TCP/IP
 HDCP   and HDMI 1.4 compliant
APPLICATIONS
 Corporate  or Educational Presentations
 Airport Installations
 Wall Displays
 Digital Signage
 Dealer Rooms
 Control Rooms
 Shopping Centers
 Security
 Point‐ ‐ of Sale
 Entertainment Venues
 Corporate Lobbies
 Restaurants
