Atlona Technologies www.atlona.com
VGA SWITCHER USER GUIDE
VGA SWITCHERS: AT-VGA0801 TO AT-VGA9601
VGA SWITCEHRS W/AUDIO: AT-VGA802 TO AT-VGA1608
1
Atlona Technologies www.atlona.com 2
Contents
1.0 Safety Operation Guide......................................................................3
1.1 Notice.................................................................................................3
2.0 Introduction........................................................................................4
2.1 Installation..........................................................................................4
3.0 Connecting the Swticher.....................................................................8
3.1 Connecting with inputs and output terminals.....................................9
3.2 Audio signal connection......................................................................9
4.0 Stacking The Switcher......................................................................10
5.0 Operation Controls For VGA0404-A...............................................11
5.1 Operation Controls For VGA0801...................................................11
5.2 Operation Controls For VGA3201,VGA0808-A, VGA1608-A.....12
5.3 Remote Control Operation................................................................15
6.0 Operation of Application Software...................................................15
6.1 Keyboard Tab...................................................................................17
6.2 Auto Tab...........................................................................................17
6.3 Custom Code Tab.............................................................................18
6.4 Code Group Tab...............................................................................19
6.5 Send / Recieve Code List Tab..........................................................20
7.0 RS-232 Operation.............................................................................20
8.0 Technical Specications...................................................................22
9.0 Troubleshooting................................................................................24
Atlona Technologies www.atlona.com 3
1.0 Safety Operation Guide
***************************************************************
In order to ensure the credibility and the users safety, please comply with the fol-
lowing items during installation, maintenance and operation of the switch.
1) The switch must be in stable position. Use only the power supply that
comes with unit. Do not use an alternate as it may damage it.
2) Do not place the switcher near hot or cold surfaces or sources.
3) To avoid any damage by over heating, please keep the environment in good
ventilation to radiate the heat when running the switcher.
4) The switcher should be turned off when it is not used.
5) Please do not attempt to take cover off the switcher for there is a high-volt
age component inside that could cause electric shock.
6) Do not splash any liquid or chemical on or near the equipment.
7) Please make sure all the wiring are in working condition and are not cut or
damaged.
1.1 Notice
*******************************************************************
This VGA Switchers User Manual can be used for other VGA matrix switcher
models. This manual is only an instruction for operators, not for any maintenance
usage. Any changes of functions and parameters since then will be informed sepa-
rately. This manual is copyright Atlona Technologies. All rights reserved. No part
of this publication may be copied or reproduced without the prior written consent of
Atlona Technologies.
Please check Atlona website updates.
http://www.Atlona.com
