Power On
Bluetooth® Connection
Playing music via Micro SD
Product Overview
A. Microphone
B. Power Button
C. Echo
D. Music Volume
E. Microphone Volume
F. Bass
G.Treble
H. LED Lights
I. Mode (TF Card/Bluetooth
®)
J. Turn LED Lights On/Off
K. Previous Track
L. Play/Pause
M. Next Track
N. Micro USB Input (for
charging unit)
O. Micro SD Card (TF Card)
Press the power button for 2 seconds to turn the
microphone on/off. When on, a blue LED light will be lit.
(Press the LED light on/off button to turn the lights on/off).
FRONT VIEW
TOP VIEW
BOTTOM VIEW
SIDE VIEW
I
A
B
C
D
E
F
G
N O
J K L M
H
M
TF
User Guide
Model: APMP-1224
Karaoke Microphone
Insert a Micro SD (TF) card into the Micro SD (TF) port. The microphone will detect
all of the .mp3 les and start playing them automatically. You can press the operation
buttons to pause or switch songs. When playing songs via the Micro SD (TF) Card,
you can control the voice volume by adjusting the music volume.
NOTE: The microphone supports up to 32GB Micro SD card or TF card. Please make
sure the card is formated as FAT32 format.
Open the Bluetooth® menu on your device (e.g. phone/tablet) and scan the Bluetooth®
devices. Select ‘APMP-1224’ to connect. There will be a notication voice once
successfully connected.
While singing, operations such as Play/Pause, Last Song/Next Song can be done on
your device and/or on the microphone.
Press and hold the LED light On/Off button for 2s to turn on/off the karaoke
accompaniment function.
Press and hold the Mode button for 2s to manually disconnect the existing paired
device.
If you have two karaoke microphones, press and hold the Play/Pause button for 2s to
turn on the karaoke party function. Once the two karaoke microphones are connected
to each other, they can playback same songthrough Bluetooth TWS connection. This
function doesn’t support Micro SD (TF) mode..
NOTES:
Once the microphone has been connected to your device for the rst time, it will connect
automatically the following times. There is no need to pair again.
If you just want to listen to music via the microphone without singing, you can simply set the voice
volume to the minimum setting.
If a Micro SD (TF) card is inserted, the microphone will switch to Micro SD (TF) card mode
automatically; press the M button to switch to Bluetooth
® mode.
5V 1A
No power • Insert the supplied charging cable securely into the power
output and ensure the power outlet is switched on.
No audio • Turn the microphone on and adjust the voice volume.
No reverb
effect • Adjust the echo button to the appropriate setting.
Noise when
singing
• Move to a quieter location and ensure the mobile phone is
close to the microphone during use.
Troubleshooting
Give us a call
Specications
Charging
What? You mean this User Guide didn’t have ALL the answers?
Speak to us! We’d love to help you get up and running as quickly
as possible. Call our on . After Sales Support 1300 002 534
Operating hours: Monday-Friday, 8:30am-6pm; Saturday, 9am-6pm AEST
Bluetooth®Yes
Battery capacity 3.7V 1200mAh
Operation time Up to 5 hours
Power input DC 5V, 1A
Size 75 x 74 x 262mm
Weight 440g
Music keeps
dropping out • Move the microphone closer to the mobile phone.
Music is too
quiet or not
playing at all
• Adjust the volume on your phone.
Failed to
connect to
Bluetooth®
• Place the phone and microphone closer together.
• Check the Bluetooth® menu on your phone to ensure it is
connected to the correct Bluetooth® device.
• Turn the microphone off then on to restart. On your device,
turn Bluetooth®
off then back on, and search again.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc., and any use of such marks by Hands (IP) Holdings Pty Ltd is under license.
Other trademarks and trade names are those of their respective owners.
When battery is too low, the microphone will
turn off automatically. Use the included Micro
USB cable to charge. The red light will be lit
during charging. Charging time is approximately
2-3 hours; the red light will be off when the
microphone is fully charged.
Your new product is ready to enjoy!
Well done, you made it.
Now sit back and relax... your new product is automatically covered
by a 1-year warranty. How nice!
