Sivu 1/9
Premium Rotatable Wall Mount
Premium Draaibare Muurbeugel
Premium Support Mural Rotatif
Premium Drehbare Wandhalterung
FLYING START.
Whoooo.
951020 - BBPRWM3775 V1.0
WALL MOUNT INSTALLATION
CHECKLIST.
Does the tick.
Suitable surfaces:
J Solid brick
J Solid concrete
§J Dry wall with wooden pillars
behind it
Before drilling:
Use the wall scanner to
check if there aren’t any
pipes or cables behind the
wall.
Do you have a question?
Coolblue.nl/en/
customer-service
Coolblue isn’t liable for any
injury, damage, or arguments
with your partner caused by a
wrong installation. In doubt if
you can do this yourself? Ask a
professional installer.
EN
Determine the location of your TV on the
wall and draw out where you want the
bottom of your TV to be. Move up with
the same distance you just measured and
draw an X.
Have your items ready. Place the wall
mount
1
on a soft rug to prevent
damage.
Use the template
5
to draw the 4 drill
holes at the height of the X. Do this
level
6
.
Place your wall mount
1
on the TV and
measure the distance from the bottom of
the TV to the drill holes in the wall mount.
Write down the distance: cm
Drill holes in your wall. For extra
accuracy, first use the 6mm drill
9
and
then the 12mm drill
10
. en, hammer
the plugs from bag B
4
into the holes.
Click the 2 caps off the wall mount
1
by
pulling them towards you.
STEP 1.
Get the wall mount ready.
STEP 4.
Determine the location.
STEP 2.
Remove the caps.
STEP 5.
Mark the height.
STEP 3.
Measure the distance.
STEP 6.
Drill the holes.
44
