GENERAL WARNINGS
• Read carefully the instructions in this booklet as they give important information on the correct installation, use and maintenance of the
appliance. Keep this booklet in a safe place so that it will be available for future reference.
• After unpacking check the integrity of the set. In case of doubt do not use the set and ask for qualifi ed person’s intervention. All the packaging
(plastic bags, polystyrene foam, nails, etc) must be kept out of the reach of children.
• Before connecting the appliance to the mains supply ensure that the rating label specifi cations correspond to your electrical supply. (The
rating label is to be found on the top part of the motor holder).
• This appliance must only be used for the purpose for which it was designed i.e. ventilation of rooms. All other uses must be considered to
be potentially dangerous. The Manufacturer cannot be held responsible for any damage caused by improper, incorrect or unreasonable use.
• The safe use of any electrical appliance involves the observing of certain basic rules, in particular:
• Do not touch the appliance with wet or moist hands or feet.
• Do not use the appliance with bare feet.
• Do not pull the plug from the power socket by the mains lead of the appliance itself.
• Do not leave the appliance where it is exposed to adverse elements such as rain, salt etc.
• Do not let young children, aged or infi rm people use the device without supervision.
• Before beginning any cleaning or maintenance operations disconnect the appliance from the electrical supply by taking out the plug or
switching off the appliance insolation switch.
• In case of a fault and/or malfunction of the appliance, switch it off but do not attempt to rectify. Seek advice from a suitably qualifi ed person.
If repair is necessary contact the Manufacturer and ask for only original spare parts. If the above action is not carried out, the safety of
the appliance could be jeopardized.
• Should it be decided not to use this appliance any longer, it should be removed from the electrical supply and rendered inoperative, then
disposed of in the normal manner. It is also recommended to make harmless those parts of the appliance which could be harmful, especially
to children who might play with the disused appliance.
• The installation must conform to the requirements of the latest issue of the I.E.E. wiring regulations.
• This appliance has been constructed to comply with the requirements of the following European Directives EEC: 73/23 - 89/336 , 92/31, 93/68.
• Do not install in a room where the fan will be exposed to a temperature in excess of 40°C.
• The set is workmanlike manufactured. A correct use and a regular maintenance guarantee life and reliability of all electrical and mechanical parts.
SPECIAL WARNINGS
• Installation must be carried out as detailed in these instructions. The user is warned that incorrect installation could cause harm to persons
or animals or damage to property. The Manufacturer cannot be held responsible in such cases.
• The apparatus is double insulated (Class II) and does not require earthing.
• Check that the current carrying capacity of the mains wiring and socket are adequate for the maximum rating of the device shown on the
rating label. In case of doubt consult a suitably qualifi ed person.
• When installing, it is necessary to use a double pole switch with a contact separation of 3 mm or more.
• Do not leave the appliance plugged if unnecessary. Switch off the main switch of the appliance when the appliance is not in use.
• Do not obstruct the air inlet or outlet grilles.
• In conformity with prevention and safety laws in force, when installation of exhaust fan is completed, make sure that it is not at all possible
to reach the motion parts from the inlet side. On the contrary it is necessary to mount the special protection shutter.
• If there is already a combustion fuel appliance in the room, it is essential to ensure that the air supply to the room is adequate for the
correct functionning of both the combustion appliance and the fan.
• Do not install the fan in the same duct where gas appliance fume is conveyed.
• The appliance must discharge into a single exhaust pipe or directly outside the building.
INSTALLATION AND ELECTRIC CONNECTION (Fig. A - B)
• Separate the cover (1) from the motor housing (5) by removing the screw (2).
• Fasten the feed cable by means of a cable-clip (4) and connect to the terminal block (3) (Fig. B).
• In case of feed-cable-strap type, overturn the cable-clip (4).
• Insert cover (1) and tighten screw (2).
MAINTENANCE
• After having disconnected the power supply, using the greatest care, wash every dirty part in water with neutral washing liquid.
NEVER IMMERSE ELECTRICAL PARTS IN WATER OR IN OTHER LIQUIDS.
WARNING:
Important information concerning the environment friendly disposal of the appliance
This product conforms to EU Directive 2002/96/EC. The symbol of the barred waste bin indicates that, at the end of its useful
life, the product has to be collected separately from the domestic waste.
The user will have to take the product to a collection centre for waste electrical and electronic equipment, or return it to a retailer
on purchase of a replacement. Failure to do so may incur the penalties established by laws governing waste disposal.
Proper differential collection and the subsequent recycling, processing and environmentally compatible disposal of waste
equipments avoids unnecessary damage to the environment and possible related health risk and promotes also recycling of the
materials used in the appliance.
