Product Introduction
The GVM digital display panel series is a range of professional photography video LED lights
that have two versions: GVM-520LD and GVM-520LS. GVM-520LD/S is made of 520 LED
beads. GVM-520LD support you to adjust brightness. GVM-520LS support you to adjust
brightness and color temperature at the same time. The GVM digital display panel series has
an exceptional color rendering index of 97+ and lights consistently. Meanwhile, the dual
power system, digital display and 360° rotation U bracket improve your light setup and
stabilization system.
Main Features
Over View
Accessoties
1
Using The Light
Battery plate
1
Power switch
2
3
4
Brightness and Color
temperature adjustment wheel
5
Digital Display
6
U bracket adjusting knob
7
DC power interface
8
Soft diffusion
9
LED bead
10
Light stand locking knob
11
Hole for light stand installation
U bracket
• Ultra Heat Dissipation
Delicate Design with Aviation Aluminum Alloy housing
•
High Color Rendering Index, CRI97+•
PWM Dimming Technology•
Digital Display•
Brightness and Color Temperature Adjustment•
Dual Power System•
Convenient Light Set-Up and Stabilization System•
Rotate the brightness/color temperature adjustment
wheel clockwise to increase your brightness and color
temperature.
4
Insert the DC adapter/ Put on the battery.Turn
on the power switch.
5
Insert the Panel on the light stand by rotating
clockwise,countercockwise to uninstall it.
1
Loosen the U bracket adjusting knob,adjust the angle
of the panel which you need,then tighten the U bracket
adjusting knob.
2
Insert the soft diffusion into the light panel sides.
Fixed by diffusion brake and screw.
3
Other purchase accessories
GVM-520LD / GVM-520LS
Mounting the light to light stand
45
Align the light stand installation hole to the light stand, rotate the light stand locking knob. You can choose
the light stand installation direction according to your operating environment need.
Specifications
Model LED Bead CRI LED angle Voltage Co lor
Temp er atu re
Power
Consumption Size
GVM-520LD
GVM-520LS 520 97+ 45°DC15V 5600(±50）
3200~5600 30W 323*341*80mm
1. Barndoor: can purchase a set of foldable barndoor to control the
angle of brightness.
Mounting the barndoor: align the barndoor mounting holes to the light panel screw holes, use the screws
to locking the barndoor.
2. Enhanced soft diffusion: if you want to make the brightness to be
softer, you can other purchase this accessory.
2 3
Product Manual
7
8
910
11
45
11 3
2
6
Mounting the enhanced soft diffusion: mount the diffusion support frame to the light panel, align the
diffusion to the screw holes and use the screws to lock the diffusion.
Carry Bag Power Line Power Adapter Soft Diffusion Packing Box
Add: 338 N Canal St, #20, South San Francisco,CA94080, USA
Web: www.gvmled.com
Email: support@gvmled.com
Attention
1. Do not look at the light directly when it is on.
2. Do not cover light when it is on, or it will prevent the light from cooling down and damage it.
3. Do not place the light around flammable items such as alcohol, gasoline or near volatile solvent.
4. Do not place any liquid on the light or fall it into the light.
5. Power the light off if you don’t use it in case of a fire.
6. Move the light carefully to prevent dropping it down.
