Sivu 1/8
Owner’s Guide
• Entra One
• Entra Two
• Entra Three
• Entra Center
• Entra Center Two
ENTRA
®S SPEAKER YSTEMS
Innity Entra Series
The Entra Series of loudspeakers continues Infinity’s
longstanding commitment to accurate sound reproduction.
Our patented Ceramic Metal Matrix Diaphragm
™(C.M.M.D.
™)
drivers, precision dividing networks, and rigid, well-braced
enclosures combine to deliver uncompromised performance in
any stereo or multichannel home-theater system. In addition,
Entra Series speakers are magnetically shielded for safe
placement adjacent to a television.
If you suspect damage from transit, report it immediately to
your dealer. Keep the shipping carton and packing materials
for future use.
Stereo
Before deciding where to place your Entra speakers, survey your
room and think about placement, keeping the following points
in mind, using Figure 1 as a guide:
•For best results, place the speakers 6'– 8' apart.
•Position each speaker so that the tweeter is approximately at
ear level.
•Generally, bass output will increase as the speaker is moved
closer to a wall or corner.
•Refer to “Home Theater” below if you also plan to use the
speakers for home-theater reproduction.
Home Theater
For front-channel use, place one speaker on the left and another
on the right along either side of the television monitor. Since the
speakers are magnetically shielded, you can place them without
worrying about the field distorting the TV picture.
For rear-channel use, place Entra One speakers on bookshelves
or stands – or Entra floorstanding speakers on the floor –
alongside the listening position. Final placement depends on
room acoustics, availability of space and your listening
preference (Figure 2).
The center channel speaker should be placed on top of or
directly below the television and aimed towards the listening area.
NOTE: An Infinity powered subwoofer will add impact and
realism to both music and film soundtracks. Contact your Infinity
dealer for recommendations on subwoofer models for your
application.
PLACEMENT
UNPACKING THE SPEAKERS
F 1IGURE
Listening Position
Left
Channel
Right
Channel
Couch
Left
Front
Channel
Left
Surround
Channel
Right
Surround
Channel
Right
Front
Channel
Center
Channel
Innity Subwoofer
(optional)
– Experiment with speaker placement to obtain the
best bass level and stereo imaging in your room.
F 2IGURE – This overhead view shows a typical home-theater
plan.
2ENTRA
Couch
Left
Front
Channel
Left
Surround
Channel
Right
Surround
Channel
Right
Front
Channel
Center
Channel
Innity Subwoofer
(optional)
F 3IGURE – This figure shows an alternate layout,which may
be more suitable for some rooms.
3
ENTRA
Entra Two and Entra Three
Refer to Figure 4 as you perform the following steps:
1. The Entra Two and Entra Three come with the round end of
their feet exposed for use on hard-surface floors.To expose
the spiked end of the feet, lay each speaker on its side and
use the enclosed wrench to unscrew and remove the four
feet. Screw the round end of each foot into its hole and
hand-tighten a nut onto each foot. Leave a minimum of 5/8"
of exposed spike. (On thicker carpets, you can increase the
length of exposed spike up to 1-1/8.")
2. Carefully stand each speaker upright to sit on its feet.
3. If needed, adjust the feet so each speaker is level and then
tighten each nut with the enclosed wrench.
INSTALLING PIKEDS FEET
Nylon Dome
(optional for
wood oors)
Locking Nut
HARD-SURFACE
FLOORS
CARPETED
FLOORS
Foot
round end
spike end
Bottom
of Speaker
5⁄8"
5⁄8" min.
11⁄8" max.
F 4IGURE – This cross section shows how to install a foot
onto the bottom of an Entra floorstanding speaker.
