Owner’s Manual
Part #335158-001
High-Performance Loudspeaker
Center-Channel Loudspeaker
Models HPS-1.5, HPS Center
HPS
2
◆HPS-1.5/Center – Owner’s Manual
The Innity HPS-1.5 bookshelf loudspeaker features advanced acoustic technology, the highest
quality components and superior enclosure design. While the HPS-1.5 is, on its own, an
excellent loudspeaker, it is ideal for use with the wide variety of subwoofer systems available
today. When combined with a powered subwoofer, especially one of Infinity’s HPS Series
subwoofers, the HPS-1.5 oers the listener superior accuracy, dynamics and resolution while
delivering an exceptionally realistic stereo image. The HPS Center is the perfect center channel
for expansion into home theater, and is voice-matched with the HPS-1.5 for optimal
performance.
UNPACKING THE PEAKERSS
If you suspect damage from transit, report it immediately to your dealer and/or delivery service.
Keep the shipping carton and packing materials for future use.
These speakers are covered by a Limited Warranty (see Warranty Sheet for details), so save the
sales receipt to protect your purchase and aid in any service-related questions. Also, save these
instructions for future reference.
Declaration of Conformity
We, Innity Systems A/S
Kongevejen 194B
DK-3460 Birkerød
DENMARK
declare in own responsibility, that the products described
in this owner’s manual are in compliance with technical
standards:
EN 50081-1:1992
EN 50082-1:1992
Steen Michaelsen
Innity Systems A/S
Birkerød. DENMARK. 3/99
HPS-1.5/Center – Owner’s Manual
◆3
S
TEREO
S
PEAKER
P
LACEMENT
...
Figure 1. Experiment with speaker
placement to obtain the best bass level
and stereo imaging in your room.
W
ALL
M
OUNTING
...
Figure 2. Integrated wall-mount bracket.
P Y SLANNING OUR YSTEM
Before deciding where to put your HPS-1.5 bookshelf speakers, survey your room, keeping the
following points in mind:
◆These speakers are designed for placement on surfaces such as bookshelves, low tables or
speaker stands. For optimum performance, it is strongly suggested that you place the
speakers on rigid stands that place the tweeter at or near ear level.
◆Position each speaker so that the top of the enclosure is between 25 and 50 inches above
the floor.
◆Refer to Figure 1 when placing speakers for optimum bass level and stereo image (see Final
Adjustments on page 7).
◆If you also plan to use the speakers for home-theater reproduction, refer to Home-Theater
Placement on the next page.
Listening Position
Left
Channel
Right
Channel
If desired, the HPS-1.5 may be mounted to a wall using the integrated wall-mount bracket
(see Figure 2).
NOTE: The customer is responsible for proper selection and use of mounting hardware (available
in hardware stores) and for correctly and safely wall-mounting the speakers.
