Owner’s Guide
• IL25c
• IL36c
INTERLUDE™S SPEAKER YSTEMS
2INTERLUDE IL25c, IL36c
Innity Interlude Series
The Interlude series of loudspeakers continues Innity’s
longstanding commitment to accurate sound reproduction.
Our proprietary Ceramic Metal Matrix Diaphragm
™(C.M.M.D.)
drivers, precision dividing networks and rigid, heavily braced
enclosures combine to deliver uncompromised performance
in any stereo or multichannel home-theater system.The IL25c
and IL36c are the perfect center-channel loudspeakers to
complete any home-theater system.
If you suspect damage from transit, report it immediately to
your dealer. Keep the shipping carton and packing materials
for future use.
Placement
For best results, the IL25c or IL36c should be placed on top
of, or directly below, the television and aimed toward the
listening area (see Figure 1).
The IL25c and IL36c terminal cups each have an adjustable
foot to angle the speaker toward the listening position
(see Figure 2).
UNPACKING THE PEAKERSS
P Y SLANNING OUR YSTEM
Couch
Left
Front
Channel
Left
Surround
Channel
Right
Surround
Channel
Right
Front
Channel
Center
Channel
Innity
Subwoofer
(optional)
F 1IGURE – This overhead view shows a typical
home-theater plan.
F 2IGURE
– +
INPUT
INPUT
– +
– +
INPUT
Loosen thumbscrew.
Slide rod down
the desired amount.
Tighten thumbscrew.
3
INTERLUDE IL25c, IL36c
IMPORTANT: Make sure all equipment is turned o before
making any connections.
For speaker connections, use a minimum #16-gauge speaker
wire with polarity coding.The side of the wire with a ridge or
other coding is usually considered positive polarity (i.e., +).
NOTE: If desired, consult your local Innity dealer about speaker
wire and connection options.
To ensure proper polarity, connect each terminal on the back+
of the amplier, receiver or television to the respective +(red)
terminal on each speaker, as shown in Figure 3. Similarly,
connect the (black) terminals in the same way.Also, see the–
owner’s guides that were included with your amplier or
receiver to conrm connection procedures.
W SIRING THE YSTEM
Red = +
Black = –
❶ Loosen Terminal
❷ Insert
Bare End;
Tighten Terminal
Speaker Wire
Marking = +No Marking = –
Receiver or
Amplier
(rear view)
Interlude Center
redblack
(one channel shown)
+
–
-
+
F AINAL DJUSTMENTS
C Y S SARE OF OUR PEAKER YSTEM
F 3IGURE
–
Interlude series
speakers feature
color-coded
terminals.This
example shows the
most common way
of connecting
speaker wire by
directly inserting
into terminals.
F 4IGURE – Wiring diagram shows polarity connections for
one channel of a stereo or home-theater system.
IMPORTANT: Do not reverse polarities (i.e., + to – or – to +)
when making connections. Doing so will cause poor imaging and
diminished bass response.
Check the speakers for playback rst by setting the system
volume control to a minimum level, and then by applying power to
your audio system. Following the directions provided with your
receiver/processor, adjust the center-channel volume so that it
matches the output of the left and right speakers.
Each Interlude series cabinet has a wood-vinyl nish that
does not require any routine maintenance. When needed, use
a soft cloth, dampened with water only, to remove any
ngerprints or dust.
Clean the grille by gentle vacuuming.
NOTE: Do not use any cleaning products or polishes on the
cabinet or grille.
