Sivu 1/2
4-1/4"
110mm
6-1/4"
159mm
3-9/16"
90mm
5"
127mm
2-1/16"
52mm
3/4"
19mm
1-3/4"
44mm
4-1/4"
110mm
6-1/4"
159mm
3-3/16"
80mm
5"
127mm
1-15/16"
49mm
7/16"
11mm
1-3/4"
44mm
6032i/6032cf 6032si
R E F E R E N C E
6032i
6032cf
6032si
6032gr
Declaration of Conformity
We, Harman International, Consumer Division
2, route de Tours
72500 Château du Loir
France
declare in own responsibility that the products described in this owner’s
manual are in compliance with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
Klaus Lebherz
Harman Consumer Group, Inc.
Château du Loir, France 1/09
6032i 6032cf 6032si
BL (T-m) 4.00 4.00 4.30
DCR (ohms) 2.30 2.30 2.30
Mms (g) 12.98 12.98 12.69
Sd (sq cm) 132.7 132.7 132.7
Cms (μm/N) 277 277 221
Vas (l) 6.85 6.85 5.47
Fs (Hz) 83.9 83.9 95.0
Qes 0.98 0.98 0.94
Qms 6.16 6.16 7.89
Qt 0.85 0.85 0.84
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
SPECIFICATIONS
6032i 6032cf 6032si 6032gr
Type: 6-1/2” (160mm) 6-1/2” (160mm) 6-1/2” (160mm) GRILLE ONLY
2-Way 2-Way Shallow-Mount for 6-1/2” (160mm)
NO GRILLE 2-Way
Impedance: 2 Ohms 2 Ohms 2 Ohms
Power Handling, RMS: 60W 60W 50W
Power Handling, Peak: 180W 180W 150W
Frequency Response: 53Hz – 21kHz 53Hz – 21kHz 53Hz – 21kHz
Sensitivity (2.83V, 1m): 93dB 93dB 93dB
Grilles are included with the “i” version; they are optional for the “cf” and “si” versions
(use Reference model 6032gr).
WARRANTY:
Reference Series speakers are warranted against defects.
The duration of the speaker’s warranty depends on the laws in the country in which it
was purchased. Your local Infinity car audio retailer can help you determine the length
of your warranty. To register your product, please visit us at www.infinitysystems.com.
Designed and engineered in the USA. Conception et design aux É.U.A.
A valid serial number is required for warranty coverage. Un numéro de série valable est exigé pour la couverture de la garantie.
Features, specifications and appearance are subject to change without notice.
Les dispositifs, les caractéristiques et l’aspect sont sujets au changement sans communication préalable.
Harman International, Consumer Division, 8500 Balboa Blvd., Northridge, CA 91329 USA
www.infinitysystems.com
¥(ARMAN)NTERNATIONAL)NDUSTRIES)NCORPORATED!LLRIGHTSRESERVED4OUSDROITSRÏSERVÏSs0ART.O2%&/-
Infinity is a trademark of Harman International Industries, Incorporated, registered in the United States and/or other countries.
Infinity est une marque commerciale de Harman International Industries, Incorporated, déposée aux États-Unis et/ou dans d’autres pays.
2x
6032gr
1x
2x2x 2x 2x
6032i/6032si
6032i/6032cf/6032si 6032i/6032cf
1x
6032cf
2x2x 2x
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
TWEETER-LEVEL
CONTROL
This speaker system is equipped with a
tweeter-level switch. The normal setting for
this switch is the “0dB” position, which pro-
vides an apparently “flat” response. Tweeter
output may be increased according to the
user’s preference, or to compensate for off-
axis placement (where the speaker does not
directly face the listening position), by set-
ting the switch to the “+3dB” position.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
ROTATING TWEETER
The Reference 6032i/cf includes a rotating,
angled tweeter mount, which is designed
to allow the tweeter to be aimed toward
the listening position. Since the tweeter’s
output becomes directional at extremely
high frequencies, aiming the tweeter toward
the listening position will improve high-
frequency response and stereo imaging.
Before securing the grille,
grasp the tweeter
housing around the edge and rotate the
tweeter assembly so that the tweeter faces
the listener as directly as possible. Then the
grille may be permanently secured.
Tuotetiedot
Merkki: | Infinity |
Kategoria: | Kaiutin |
Malli: | Reference 6032si |
Tarvitsetko apua?
Jos tarvitset apua merkille Infinity Reference 6032si esitä kysymys alla ja muut käyttäjät vastaavat sinulle
Kaiutin Infinity Käyttöohjeet
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
Kaiutin Käyttöohjeet
- Kaiutin Aiwa
- Kaiutin LG
- Kaiutin Vonyx
- Kaiutin Grundig
- Kaiutin Sharp
- Kaiutin Hama
- Kaiutin AOC
- Kaiutin Philips
- Kaiutin IKEA
- Kaiutin Edifier
- Kaiutin Fender
- Kaiutin Kogan
- Kaiutin Soundcore
- Kaiutin Turbosound
- Kaiutin Sony
- Kaiutin GoGEN
- Kaiutin Pro-Ject
- Kaiutin Yamaha
- Kaiutin Morel
- Kaiutin Axis
- Kaiutin Extron
- Kaiutin Media-tech
- Kaiutin Pioneer
- Kaiutin EarFun
- Kaiutin Ecler
- Kaiutin Audac
- Kaiutin Audio-Technica
- Kaiutin Toa
- Kaiutin Pyle
- Kaiutin Sencor
- Kaiutin Bose
- Kaiutin Orava
- Kaiutin Kanto
- Kaiutin JVC
- Kaiutin Sharper Image
- Kaiutin Kicker
- Kaiutin Auna
- Kaiutin OSD Audio
- Kaiutin Fenton
- Kaiutin MB Quart
- Kaiutin Aplic
- Kaiutin Advance
- Kaiutin Sonance
- Kaiutin AXESS
- Kaiutin Artsound
- Kaiutin Denon
- Kaiutin Yorkville
- Kaiutin V-Tac
- Kaiutin Braun
- Kaiutin JBL
- Kaiutin Majority
- Kaiutin Helix
- Kaiutin Genesis
- Kaiutin Klipsch
- Kaiutin Muse
- Kaiutin Ground Zero
- Kaiutin Karma
- Kaiutin Glemm
- Kaiutin Match
- Kaiutin Speed-Link
- Kaiutin Renkforce
- Kaiutin Definitive Technology
- Kaiutin QSC
- Kaiutin Q Acoustics
- Kaiutin GoldenEar
- Kaiutin Pyramid
- Kaiutin FoneStar
- Kaiutin Monitor Audio
- Kaiutin Canton
- Kaiutin Sven
- Kaiutin PSB
- Kaiutin Vizio
- Kaiutin Polk
- Kaiutin ESX
- Kaiutin Omnitronic
- Kaiutin MEE Audio
- Kaiutin Monacor
- Kaiutin ModeCom
- Kaiutin Hercules
- Kaiutin Electro-Voice
- Kaiutin Wharfedale
- Kaiutin Boss
- Kaiutin Tannoy
- Kaiutin Mount-It!
- Kaiutin GMB Audio
- Kaiutin Mad Dog
- Kaiutin Samson
- Kaiutin Memphis Audio
- Kaiutin Focal
- Kaiutin Alpine
- Kaiutin Boompods
- Kaiutin Kramer
- Kaiutin Genelec
- Kaiutin Bazooka
- Kaiutin Lamax
- Kaiutin Aiaiai
- Kaiutin RCF
- Kaiutin N-Gear
- Kaiutin Vimar
- Kaiutin Phoenix Gold
- Kaiutin Aconatic
- Kaiutin Bogen
- Kaiutin Atlas
- Kaiutin PowerBass
- Kaiutin Harman Kardon
- Kaiutin Yamazen
- Kaiutin Lexibook
- Kaiutin Ibiza Sound
- Kaiutin Creative
- Kaiutin REL Acoustics
- Kaiutin Phonic
- Kaiutin Apart
- Kaiutin Magnat
- Kaiutin Boston Acoustics
- Kaiutin Crest Audio
- Kaiutin AudioSource
- Kaiutin Taga Harmony
- Kaiutin SoundTube
- Kaiutin Ruark Audio
- Kaiutin MB
- Kaiutin Antelope
- Kaiutin M-Audio
- Kaiutin SureFire
- Kaiutin Berker
- Kaiutin Denon DJ
- Kaiutin Nikkei
- Kaiutin HK Audio
- Kaiutin Eve Audio
- Kaiutin Delvcam
- Kaiutin Grimm Audio
- Kaiutin Cerwin-Vega
- Kaiutin Revel
Viimeisimmät Kaiutin Käyttöohjeet
25 Joulukuuta 2024
25 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
24 Joulukuuta 2024
23 Joulukuuta 2024
23 Joulukuuta 2024
